Medical Stainless Steel Autoclave Steam Sterilizer 100L
Reference: 10000018594514
Sterilization Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Product Introduction and Application
GoldHealth Medical presents a cutting-edge pulse vacuum autoclave designed for use in dental and ophthalmology departments, operating rooms, and various medical institutions. This autoclave is ideal for sterilizing wrapped or unwrapped solid instruments, A-class cavity instruments such as dental hand-pieces and endoscopes, implantable instruments, dressing fabrics, and rubber tubes.
Introduction
Our pulse vacuum autoclave achieves superior sterilization by extracting vacuum and filling the chamber with steam multiple times. This process ensures the sterilization chamber reaches a specific vacuum level before filling with saturated steam to achieve the desired pressure and temperature, effectively sterilizing the contents.
Features
- Sterilization Data Output: Equipped with a standard micro printer for seamless data output without external connections.
- Advanced Display: A 7-inch color LCD touch screen provides real-time information on temperature, pressure, operational status, fault alerts, cause analysis, and solutions.
- Powerful Drying System: Achieves a vacuum level of up to -92kPa, ensuring residual humidity remains below 0.25% for devices and 1% for dressings.
- Sterile Environment: Maintains a sterile chamber atmosphere to prevent re-contamination.
- Easy Maintenance: Quick-release side and top covers facilitate effortless maintenance and cleaning.
- Programmable Control: Utilizes micro-controller technology for precise programmable control.
- Safety Features: Full protective door cover prevents burns, while a self-expanding sealing ring ensures reliable and stable sealing performance.
- Secure Closure: Multi-point pressing structure of the radiation rod ensures safe and reliable closure.
- Automated Operation: Connects directly to a water source, eliminating the need for manual refills. The equipment autonomously manages the entire process from water injection to drying.
- Completion Alerts: Audible notifications signal the completion of the sterilization cycle.
- Built-in Steam Generator: High-speed steam generator eliminates the need for an external steam source, saving time and effort.
- Mobile Temperature Sensor: Meets specialized laboratory requirements.
- Comprehensive Safety: Pressure, mechanical, and electronic three-layer safety interlock devices provide over-temperature and over-pressure protection, mitigating all safety risks.
Product Parameters
- Capacity Options: 150L, 200L, 300L, 360L
- Maximum Designed Pressure: -0.1/0.3MPa
- Working Pressure: 0.23MPa
- Working Temperature Range: 105 to 134Β°C
- Noise Level: β€85dB
- Vacuum System: Water circulating vacuum pump
- Chamber Material: S30408
- Power Supply: 380V/50HZ
- Power Consumption: 20kVA
- External Dimensions (WDH):
- 11909401780 mm
- 14009401780 mm
- 157011701980 mm
- 157011701980 mm
- Chamber Dimensions:
- Ο500*780 mm
- Ο500*1020 mm
- Ο650*980 mm
- Ο650*1130 mm
- Package Dimensions (WDH):
- 138511102080 mm
- 158511102080 mm
- 175513302270 mm
- 175513302270 mm
- Gross Weight:
- 520 kg
- 600 kg
- 755 kg
- 770 kg
Additional Products
GoldHealth Medical offers a range of advanced autoclaves and sterilization solutions tailored to meet diverse medical needs, ensuring reliability and precision in every application. Our products have earned recognition from the World Health Organization and are trusted by medical professionals worldwide.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical presents a cutting-edge solution in gas sterilization, designed to meet the rigorous demands of modern healthcare and research environments. This Class II medical instrument combines precision engineering with advanced sterilization technology, ensuring unparalleled performance and reliability for hospitals, clinics, laboratories, and more.
Key Features and Specifications
- Sterilization Capacity: 150 liters, ideal for high-volume sterilization needs.
- Pressure Performance:
- Maximum Designed Pressure: -0.1/0.3MPa
- Working Pressure: 0.23MPa
- Temperature Range: Operates efficiently between 105Β°C and 134Β°C, ensuring effective sterilization across diverse applications.
- Noise Level: Engineered for quiet operation with noise levels β€85dB, maintaining a peaceful environment.
- Chamber Material: Constructed from premium S30408 stainless steel for exceptional durability and hygiene.
- Power Supply: 380V/50HZ, optimized for consistent and reliable performance.
- Energy Consumption: 20kVA, balancing power efficiency with robust functionality.
Packaging Details
- Package Dimensions: 138.5 x 111 x 208 cm
- Gross Weight: 520 kg, ensuring secure and stable transportation.
Warranty and Support
- Warranty Period: 1 year, reflecting our confidence in product quality and longevity.
- After-Sales Service: Comprehensive online technical support to address any operational or technical queries promptly.
Why Choose GoldHealth Medical?
Our gas sterilization equipment is meticulously crafted to deliver superior sterilization results while maintaining user safety and operational ease. Designed for professionals who demand precision, reliability, and efficiency, this product stands as a testament to GoldHealth Medical's commitment to innovation and excellence in healthcare solutions.
