280L Horizontal Autoclave with Printer
Reference: 1600802058539
Sterilization Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Horizontal Cylindrical Pressure Steam Sterilizer
Experience unparalleled sterilization with GoldHealth Medical's advanced Horizontal Cylindrical Pressure Steam Sterilizer. Designed for precision and ease of use, this state-of-the-art equipment is engineered to meet the highest standards in medical sterilization.
Key Features:
- Automated Sterilization: Achieve consistent results with fully automatic sterilization control, ensuring ease of operation and reliability.
- Integrated Drying Function: Perfect for drying dressings efficiently, enhancing workflow in busy environments.
- Advanced Safety Mechanisms: Equipped with over-temperature and over-pressure auto-protection devices for maximum safety.
- Secure Door Operation: The door cannot be opened until chamber pressure reduces to 0.027MPa, and operation is disabled if the door isn't properly closed.
- Automatic Safety Valve: Releases steam into the water tank when internal pressure exceeds 0.24MPa, ensuring user safety.
- Water Level Monitoring: Automatically cuts off power, stops water flow, and triggers an alarm in case of low water levels.
- Durable Construction: Fully stainless steel structure for long-lasting performance and hygiene.
- Built-in Printer: Document sterilization cycles with precision for quality assurance and compliance.
Specifications:
- Sterilizing Chamber Volume:
- 150L: φ440×1000
- 200L: φ515×1000
- 280L: φ600×1000
- Working Pressure: 0.22MPa
- Working Temperature: 134℃
- Temperature Adjustment Range: 40℃ to 134℃
- Sterilization Time: Adjustable from 0 to 99 minutes
- Drying Time: Adjustable from 0 to 99 minutes
- Temperature Uniformity: ≤±2℃
- Power Requirements:
- 9KW, 380V, 50Hz (150L and 200L models)
- 12KW, 380V, 50Hz (280L model)
- Dimensions (mm):
- 150L: 1400x650x1600
- 200L: 1400x750x1700
- 280L: 1520x910x1900
- Exterior Package Dimensions (mm):
- 150L: 1560x820x1820
- 200L: 1560x910x1880
- 280L: 1680x1080x2100
- Weight (G.W/N.W):
- 150L: 430/340Kg
- 200L: 436/350Kg
- 280L: 570/462Kg
Why Choose GoldHealth Medical?
GoldHealth Medical’s Horizontal Cylindrical Pressure Steam Sterilizer combines cutting-edge technology with user-centric design. Its robust safety features, precision engineering, and versatility make it ideal for hospitals, clinics, research labs, and rehabilitation centers. Elevate your sterilization processes with a device that prioritizes efficiency, safety, and reliability.
For inquiries, please contact GoldHealth Medical directly.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Product Name: Horizontal Cylindrical Pressure Steam Sterilizer
Product Overview
The Horizontal Cylindrical Pressure Steam Sterilizer by GoldHealth Medical is a cutting-edge Class II medical instrument designed for precision, reliability, and efficiency. Engineered to meet the rigorous demands of modern healthcare environments, this sterilizer ensures unparalleled performance in hospitals, clinics, laboratories, and research facilities. Its robust stainless steel construction guarantees durability, while its advanced temperature and pressure controls deliver consistent, high-quality sterilization results.
Key Features
- Sterilizing Volume Options: 150L, 200L, 280L – tailored to meet diverse operational needs.
- Precision Temperature Control: Adjustable range of 40°C to 134°C with a heat uniformity of ≤ ±2°C for optimal sterilization.
- Efficient Working Parameters: Operates at a working pressure of 0.22Mpa and a maximum temperature of 134°C.
- Customizable Timing: Sterilization time adjustable from 0 to 99 minutes; drying time adjustable from 0 to 99 minutes.
- Durable Build: Constructed from premium-grade stainless steel for long-lasting performance and corrosion resistance.
Technical Specifications
- Instrument Classification: Class II
- Type: Horizontal Autoclave
- Working Pressure: 0.22Mpa
- Working Temperature: 134°C
- Temperature Adjustment Range: 40°C to 134°C
- Sterilization Time Range: 0 to 99 minutes
- Drying Time Range: 0 to 99 minutes
- Heat Uniformity: ≤ ±2°C
Packaging and Delivery
- Packaging Details: Each unit is meticulously packed in a standard export-grade thick carton, reinforced with protective foam to ensure safe transit.
- Package Dimensions: 168 x 108 x 210 cm
- Gross Weight: 570.000 kg
- Ports: Shanghai, Guangzhou, Shenzhen, and other major ports in China
Supply and Support
- Supply Ability: Up to 1000 units per month to meet high-volume demands.
- Warranty: Comprehensive 1-year warranty for peace of mind.
- After-Sale Service: Dedicated online technical support to ensure seamless operation and address any concerns.
GoldHealth Medical’s Horizontal Cylindrical Pressure Steam Sterilizer combines innovation, precision, and reliability to redefine sterilization standards. Whether for medical, laboratory, or research applications, this product is engineered to deliver exceptional results consistently.
