HospitalGrade Anesthesia Machine with Ventilator
Reference: 1601181777279
Anesthesia Equipments & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical presents the Multifunctional Anesthesia Machine
A cutting-edge solution designed for precision, reliability, and versatility in modern medical environments. Engineered to meet the needs of both adult and pediatric patients, this anesthesia machine is a cornerstone of safety and efficiency in clinical settings.
Key Features
- Advanced Control System: Pneumatically driven and electrically controlled for seamless operation.
- Integrated Ventilator: Ensures consistent and accurate respiratory support.
- 5.4" LCD Display: Provides clear, real-time monitoring of critical parameters.
- Flexible Working Modes: Supports Closed, Semi-Closed, and Semi-Open configurations to adapt to diverse clinical requirements.
Technical Specifications
- Gas Requirements:
- Medical oxygen and nitrous oxide with a pressure range of 0.32~0.6 MPa.
-
4-tube flowmeters for precise control: O₂ & N₂O, adjustable from 0.1L/min to 10L/min.
-
Oxygen Flush: Delivers 25~75L/min for rapid oxygenation.
-
Respiration Modes:
-
A/C, IPPV, SIPPV, IMV, SIMV, MANUAL.
-
Tidal Volume:
- Display range: 50~1500ml.
-
Adjustable range: 0~1500ml.
-
I/E Ratio: Configurable from 4:1 to 1:10 for optimal ventilation.
-
Vaporizer Compatibility:
- Supports Enflurane, Isoflurane, Sevoflurane (Halothane optional).
-
Vaporizer setting range: 0.5%~5%.
-
Respiration Frequency: Adjustable from 1~99 bpm.
-
Pressure Range (Ptr): -1.0kPa to 1.0kPa.
-
CO₂ Absorber Capacity: 1kg for extended use.
Safety and Monitoring
- Comprehensive Alarm Parameters:
- Upper/lower limits of airway pressure.
- Tidal volume exceedance or absence.
- Apnea detection.
- AC power malfunction alerts.
- Low battery warnings.
Optional Enhancements
- Integrated patient monitor for real-time tracking of vital signs.
Why Choose GoldHealth Medical?
- Unmatched Precision: Designed with meticulous attention to detail for optimal performance.
- Superior Safety: Equipped with advanced alarm systems to ensure patient well-being.
- Customizable Solutions: Tailored configurations to meet your specific clinical needs.
- Commitment to Excellence: Backed by a team of experienced engineers and a dedication to customer satisfaction.
GoldHealth Medical’s Multifunctional Anesthesia Machine is more than a device—it’s a trusted partner in delivering exceptional care. Elevate your practice with a solution that combines innovation, reliability, and precision.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Product Name: Single Vaporizer Anesthesia Machine
Product Overview
The Single Vaporizer Anesthesia Machine by GoldHealth Medical is a cutting-edge solution designed for precision, reliability, and ease of use in medical environments. Engineered to meet the demands of modern healthcare, this Class II medical instrument ensures exceptional performance with advanced safety features and intuitive controls. Whether in hospitals, clinics, or research facilities, this machine delivers consistent results while prioritizing patient safety and operational efficiency.
Key Features
- High-Resolution Display: Equipped with a 5.4-inch TFT display for clear, real-time monitoring of critical parameters.
- Advanced Flowmeter Range: Oxygen (O2): 0.1-10L/min; Nitrous Oxide (N2O): 0.1-10L/min, ensuring precise gas delivery.
- Multiple Ventilation Modes: Supports IPPV, SIPPV, IMV, SIMV, and MANUAL modes to accommodate diverse clinical needs.
- Extended Backup Power Supply: Provides at least 4 hours of operation during power outages, ensuring uninterrupted care.
- Customizable Respiratory Settings: Adjustable respiratory rate (1-99bpm) and Inspiratory/Expiratory (I:E) ratio (4:1 to 1:10) for tailored ventilation.
- Intelligent Pressure Triggering: Electronically controlled inspiratory pressure trigger (-10 to 10cmH2O) for enhanced patient comfort and safety.
- SIGH Functionality: Automatically delivers 1 sigh breath every 80-160 breaths to prevent atelectasis and improve lung function.
Technical Specifications
- Power Source: Electric
- Oxygen Supply Flow Rate: 25~75L/min
- Shelf Life: 3 years
- Material: Durable metal and high-grade plastic construction for long-lasting performance
- Safety Standard Compliance: IEC 62321:2008
- Quality Certification: CE
Warranty and Support
- Warranty Period: 3 years, providing peace of mind and long-term reliability.
- After-Sales Service: Comprehensive online technical support to ensure seamless operation and address any concerns.
Applications
This anesthesia machine is ideal for a wide range of settings, including hospitals, clinics, research laboratories, rehabilitation centers, and home care environments. Its versatility and precision make it an indispensable tool for medical professionals seeking dependable and innovative solutions.
GoldHealth Medical is committed to advancing healthcare technology, and the Single Vaporizer Anesthesia Machine exemplifies our dedication to excellence, safety, and patient-centered design.
