SP2000 Ophthalmic Ultrasound Biometer AB Scan
Reference: 1601279374325
Visual Acuity Examination Apparatus
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Ophthalmic Ultrasound System
GoldHealth Medical presents an advanced ophthalmic ultrasound system designed to elevate diagnostic precision and streamline clinical workflows. This cutting-edge device combines innovative engineering with user-centric features, making it an indispensable tool for eye care professionals.
Key Features
- Compact and Lightweight Design: Optimized for portability and ease of use in any clinical setting.
- Integrated All-in-One Platform: A seamless workstation that consolidates essential functions for maximum efficiency.
- USB Connectivity: Ensures effortless data transfer and system integration.
- Advanced Image Capture: Built-in capabilities for capturing high-resolution diagnostic images.
- Comprehensive Patient Management: Streamlines patient data handling and organization.
- Customizable Report Editing: Empowers users to create detailed and professional diagnostic reports.
- Optional High-Frequency Probes: Includes 20MHz probes tailored for anterior or posterior segment imaging.
Technical Specifications
Modules
- Ophthalmic Ultrasound B-Scan
- Ophthalmic Ultrasound A-Scan
A-Scan Features
- Scan Modes: Contact and Immersion
- Examination Modes: Normal, Dense Cataract, Aphakic, Pseudophakic (PMMA, Acrylic, Silicone)
- Measurements: AXL, ACD, Lens and Vitreous, Individual Segment Velocities, Average and Standard Deviations for AXL, ACD, Lens & Vitreous
- Clinical Accuracy: ±0.1mm
- Electrical Accuracy: 0.0375mm
- IOL Calculation: Increments of 0.5D
- IOL Formulas:
- Refractive: SRK-II, SRK-T, Binkhorst-II, Holladay, Hoffer-Q, Haigis
- Post-refractive: Latkany Myopic, Latkany Hyperopic, Double-K/SRK-T
A-Scan Probe
- Hand-held, Immersion, or Slit Lamp Mounted
B-Scan Features
- Scan Modes: B Mode, B+A Mode, B+B Mode
- Adjustable Zoom and Gain
- Variable Gain Control
- 256-Level Grayscale
- Frame and Cline Loop Capture
- Clinical Resolution: 0.2mm
- Probe Specifications:
- Transducer Frequency: 12.5MHz
- 53° Sector Scanning Method
- Optional Probes:
- 20MHz FD 13mm for Anterior Segment
- 20MHz FD 25mm for Posterior Segment
- Accuracy: 0.1mm
Why Choose GoldHealth Medical?
GoldHealth Medical’s ophthalmic ultrasound system is engineered to deliver unparalleled precision and reliability. Its modular design and advanced imaging capabilities ensure accurate diagnostics, while its intuitive interface simplifies operation for both novice and experienced users. Whether you’re conducting routine examinations or complex intraocular lens calculations, this system adapts to your needs with exceptional flexibility.
With a focus on innovation and quality, GoldHealth Medical is committed to providing healthcare professionals with tools that enhance patient outcomes and optimize clinical workflows.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical proudly presents a cutting-edge ophthalmic ultrasound system designed to deliver unparalleled precision and versatility for eye diagnostics. Engineered with advanced technology, this device is tailored for medical professionals seeking reliable, high-performance equipment for diverse clinical applications.
Key Features and Specifications
- Instrument Classification: Class II medical device, ensuring safety and efficacy in professional environments.
- Place of Origin: Crafted with precision in Jiangsu, China, reflecting GoldHealth Medical's commitment to quality manufacturing.
- Power Source: Electric, optimized for consistent performance.
- Voltage Compatibility: Operates seamlessly on 110V, making it adaptable for various settings worldwide.
Advanced Examination Capabilities
- Examination Modes: Offers multiple modes including Normal, Dense Cataract, Aphakic, and Pseudophakic, catering to a wide range of diagnostic needs.
- A-Scan Probe: Hand-held design with options for immersion or slit lamp mounting, providing flexibility and ease of use.
- B-Scan Modes: Includes B Mode, B+A Mode, and B+B Mode, enabling comprehensive imaging and analysis.
- Probe Specifications: Equipped with a transducer frequency of 12.5MHz and a 53° sector scanning method for high-resolution imaging.
Applications
Designed for use in hospitals, clinics, research institutions, and rehabilitation centers, this system is also suitable for specialized environments such as laboratories and home healthcare setups.
Material and Technology
Constructed with SP-2000 A/B Scan technology, ensuring accurate and reliable results for every diagnostic procedure.
Packaging Details
- Package Dimensions: 40x30x20 cm, compact and secure for easy transportation.
- Gross Weight: 8.000 kg, lightweight yet robust.
Quality Assurance and Support
- Warranty: Backed by a 1-year warranty, guaranteeing peace of mind for users.
- Certifications: CE-certified, meeting international standards for safety and performance.
- Customization Options: Supports OEM and ODM services, allowing tailored solutions to meet specific requirements.
- After-Sale Service: Comprehensive support, including online technical assistance, ensuring uninterrupted operation and user satisfaction.
GoldHealth Medical’s ophthalmic ultrasound system redefines diagnostic excellence, empowering healthcare providers with the tools they need to deliver exceptional patient care.
