Rayto RT6900 ELISA Microplate Reader for Clinical
Reference: 1601272850730
Clinical Analytical Instruments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Microplate Reader
Experience precision and efficiency with the GoldHealth Medical Microplate Reader, designed to elevate your diagnostic and research capabilities. Featuring a vibrant 7" color LCD touch screen and an integrated printer, this device offers seamless operation and immediate results.
Key Features:
- Advanced Optical System: Equipped with an 8-channel optical fiber system, delivering rapid readings in just 5 seconds for a full plate.
- Flexible Measurement Options: Supports both single and dual wavelength measurements to suit diverse assay requirements.
- Customizable Plate Shaking: Adjustable speed and frequency ensure optimal mixing for accurate results.
- Extensive Storage Capacity: Store up to 100 programs and 10,000 sample results, ensuring comprehensive data management.
- Multi-Assay Capability: Perform up to 12 different assays on a single plate, maximizing throughput and versatility.
- Smart Power Management: Automatic self-check on startup and data-saving functionality in the event of a power outage.
- Enhanced Control Settings: Random positive and negative control settings for reliable quality assurance.
- Lamp Saving Mode: Extends the life of the halogen lamp, reducing maintenance needs.
Technical Specifications:
- Absorbance Range: 0-4.000Abs
- Resolution: 0.001Abs (displayed), 0.0001Abs (calculated)
- Light Source: Halogen lamp 6V/19W
- Optical System: 8-channel optical fiber system
- Wavelengths: Standard filters at 405nm, 450nm, 492nm, 630nm; 3 additional optional filters
- Wavelength Accuracy: ±2nm
- Band Width: 8±2nm
- Calculation Methods: ABS, Cut-off, Multi-percent, Percent log, Linear, Exponential, Index, 4PL Regression, and more
- Methodologies: End-point, Fixed-time, Kinetic
- Microplate Compatibility: Standard 96-well plates or other microplates and strips
- Reading Speed: 5 seconds for a 96-well plate (single wavelength)
- Memory: Up to 100 programs and 10,000 sample results storage
- Printer: Built-in thermal printer; external printer optional
- Dimensions: 425(L) x 310(W) x 215(H) mm
- Weight: 12kg
GoldHealth Medical's Microplate Reader is engineered to deliver unparalleled accuracy and reliability, making it an indispensable tool for hospitals, clinics, research labs, and more. Elevate your operations with a device that combines cutting-edge technology with user-centric design.
