Olympus CX Series LED Microscopes for Lab Classroom Use
Reference: 1600994042661
Ultrasonic, Optical, Electronic Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Microscope
Engineered for precision and durability, the GoldHealth Medical Microscope is designed to meet the rigorous demands of modern medical and laboratory environments. Its robust construction and advanced optical system deliver unparalleled clarity and reliability, making it an indispensable tool for professionals in hospitals, clinics, research institutions, and more.
Key Features and Specifications
Optical Excellence
- Infinity Optical System: Provides exceptional clarity and precision for accurate diagnostics.
- Binocular Observation Tube: Anti-fungal design with 30Β° tube inclination and interpupillary distance adjustment (48β75 mm).
- Eyepieces:
- Standard 10X eyepiece with a field number (FN) of 20.
- Optional 15X eyepiece (FN: 12) for enhanced magnification.
- Objectives: Anti-fungal plan achromat lenses for superior image quality:
- 4X (NA 0.1, W.D. 27.8 mm)
- 10X (NA 0.25, W.D. 8.0 mm)
- 40X (NA 0.65, W.D. 0.6 mm)
- 100X oil immersion (NA 1.25, W.D. 0.13 mm)
Illumination and Condenser
- Built-in Transmitted Illumination System: Energy-efficient LED with a power consumption of just 0.5W (nominal value).
- Abbe Condenser (NA 1.25): Equipped with a built-in aperture iris diaphragm for precise light control.
Focusing System
- Stage Height Movement: Smooth and precise adjustments for optimal positioning.
- Coarse Movement Stroke: 15 mm with a limit stopper to prevent damage.
- Torque Adjustment: Customizable coarse adjustment knob for user comfort.
- Fine Focus Knob: Minimum adjustment gradations of 2.5 ΞΌm for meticulous focusing.
Stage and Mechanical Design
- Wire Movement Mechanical Fixed Stage: Durable and precise with the following specifications:
- Size: 174 mm Γ 89 mm
- Traveling Range: 76 mm Γ 30 mm
- Includes a specimen holder and position scale for accurate sample placement.
- Fixed Quadruple Nosepiece: Inward tilt design for stability and ease of use.
Build Quality
- Aluminum Die-Cast Metal Frame: Ensures long-lasting durability.
- Protective Plastic Covering: Shields the microscope from environmental damage.
Dimensions and Weight
- Compact Design: 198 mm Γ 398 mm Γ 386 mm (W Γ D Γ H).
- Lightweight: Approximately 5.9 kg for easy portability.
Electrical Specifications
- Rated Voltage/Electric Current: AC 100β240 V, 50/60 Hz, 0.4 A.
- Power Consumption: Less than 2 W for energy efficiency.
Optional Accessories
- Reflection mirror for enhanced versatility.
- Eyepiece micrometer for precise measurements.
- Dust cover to protect the microscope during storage.
- Darkfield stop and field diaphragm for specialized applications.
- Dedicated wooden case for secure transportation.
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to advancing healthcare through innovative and reliable equipment. Our microscopes are designed with cutting-edge technology and meticulous attention to detail, ensuring they meet the highest standards of performance and durability. Whether for clinical diagnostics, research, or education, our products are tailored to empower professionals with the tools they need to succeed.
Experience the GoldHealth Medical differenceβwhere precision meets reliability.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents the CX Series Biological Microscope
A cutting-edge solution designed for precision, durability, and versatility in medical, laboratory, and research environments.
Key Features
- Advanced Optical System: Equipped with an infinity optical system for unparalleled clarity and precision in biological observations.
- Robust Build: Aluminum die-cast metal frame with a protective plastic covering ensures long-lasting durability and stability.
- Anti-Fungal Objectives: Includes Plan Achromat lenses (4X, 10X, 40X, 100X Oil) designed to resist fungal growth, maintaining optical integrity over time.
- Efficient Illumination: Built-in transmitted illumination system delivers consistent and bright lighting for accurate sample analysis.
- Ergonomic Design: Fixed quadruple nosepiece with an inward tilt reduces strain during prolonged use, enhancing user comfort.
Technical Specifications
- Instrument Classification: Class II
- Power Source: Electricity (AC 100β240 V, 50/60 Hz, 0.4 A)
- Power Consumption: Less than 2 W
- Dimensions (W x D x H): 198 mm x 398 mm x 386 mm
- Weight: Approximately 5.9 kg
- Shelf Life: 1 year
- Quality Certification: CE
Packaging Details
- Single Package Size: 52 x 38 x 43 cm
- Single Gross Weight: 9.000 kg
After-Sale Support
- Warranty: 1 year
- Service: Online technical support to ensure seamless operation and address any queries.
Applications
Ideal for hospitals, clinics, research institutions, laboratories, and educational settings, the CX Series microscope is engineered to meet the demands of modern biological analysis with reliability and precision.
Experience the next level of optical excellence with GoldHealth Medicalβs CX Series Biological Microscope.
