LHRW1000 Ophthalmic Ultrasound AB Scan for
Reference: 1600374923750
Ultrasonic, Optical, Electronic Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Ophthalmic Ultrasound System
GoldHealth Medical presents an advanced digital ophthalmic ultrasound system designed to redefine precision in eye diagnostics. This intelligent system combines cutting-edge digital software with versatile imaging capabilities, empowering medical professionals to achieve unparalleled accuracy in their diagnoses.
Key Features and Benefits
-
Unmatched Precision: Capture and analyze critical measurements with ease. The system allows for adjustable parameters on frozen and stored images, ensuring optimal clarity and detail.
-
Comprehensive A-Scan Functionality:
- Measures essential ocular dimensions such as anterior chamber depth, lens thickness, and axial length.
- Automatically calculates intraocular lens (IOL) power using advanced formulas like SRK-T, SRKII, HOLLADAY, BINKHORST-II, HOFFER-Q, and HAIGIS.
-
Delivers highly accurate results with a measurement error of ≤±0.05mm and a range of 5mm to 40mm.
-
Advanced B-Scan Imaging:
- Provides clear, intuitive cross-sectional images of the eye.
- Enables detailed observation of internal structures and detection of conditions such as cataracts, vitreous disorders, retinal detachment, macular diseases, and intraocular tumors.
- Supports confident diagnosis with tools for area, length, marking, and annotation.
Technical Specifications
A-Scan Parameters
- Probe Frequency: 10MHz
- Measurement Method: Touch
- Measuring Range: 5mm–40mm
- Measurement Error: ≤±0.05mm
- Measurement Type: Axial length with automatic calculation and result analysis
- Image Freeze Options: Automatic, Automatic + Save, Manual
- Gain Adjustment: 20–110dB
- Time Gain Adjustment: 0–30dB
B-Scan Parameters
- Probe Frequency: 10MHz
- Detection Depth: ≥50mm
- Axial Resolution: ≤0.2mm
- Horizontal Resolution: ≤0.3mm
- Gain Adjustment: 20–110dB
- Time Gain Adjustment: 0–30dB
- Operation Modes: Eye cups, gels, water pouches
- Post-Processing Tools: Area, length, marking, annotation
- Playback Function: Supports playback and freezing of up to 100 images
General Specifications
- Dimensions: 340mm (L) x 320mm (W) x 115mm (H)
- Weight: 10kg
- Power Supply: 100–240V, 50/60Hz
Why Choose GoldHealth Medical?
- Engineered for Excellence: Our system is meticulously calibrated before shipment to ensure peak performance.
- Tailored Solutions: Whether you need portable or advanced systems, we offer a range of configurations to meet your specific needs.
- Global Reach, Local Support: Backed by experienced engineers and a commitment to customer satisfaction, we ensure seamless integration and operation.
- Proven Reliability: Trusted by over 85% of our clients as repeat customers, with a 95% positive feedback rate.
GoldHealth Medical is dedicated to advancing eye care diagnostics with innovative, reliable, and user-friendly solutions. Elevate your practice with a system that delivers precision, clarity, and confidence in every scan.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents an advanced ophthalmic A/B scan device, designed to deliver precision, reliability, and ease of use for a wide range of medical professionals.
- Instrument Classification: Class II medical device, engineered for safety and accuracy in critical diagnostic applications.
- Power Source: Electric, with a universal voltage range of 100-240V at 50/60Hz, ensuring compatibility across global healthcare facilities.
- Material: Durable, high-quality plastic construction for long-lasting performance and lightweight portability.
- Shelf Life: 1 year, maintaining consistent functionality and reliability throughout its lifecycle.
- Quality Certification: CE-certified, meeting rigorous international standards for safety and performance.
Technical Specifications
- Probe Frequency: Equipped with both A-mode and B-mode probes operating at 10MHz for exceptional imaging clarity.
- Measurement Method: Advanced touch-based technology for intuitive operation.
- Measurement Error: Precision-engineered with an error margin of ≤±0.05mm, ensuring highly accurate diagnostic results.
- Measurement Type: Specialized for eye axis length measurement, featuring automatic calculation and result analysis for streamlined workflows.
- Playback Functionality: Capable of storing, playing back, and freezing up to 100 images for detailed review and analysis.
Design and Dimensions
- Device Size: Compact design measuring 340mm x 320mm x 115mm, ideal for space-constrained environments.
- Weight: Lightweight at just 10kg, offering effortless mobility and setup.
- Packaging Details: Ships in a robust standard export package, with single-item dimensions of 55cm x 55cm x 35cm and a gross weight of 18kg.
Performance and Supply
- Power Efficiency: Optimized for consistent performance in diverse clinical settings.
- Supply Ability: Monthly production capacity of 20 sets, ensuring timely delivery to meet your needs.
GoldHealth Medical’s ophthalmic A/B scan device is a trusted solution for hospitals, clinics, research labs, and rehabilitation centers, offering unparalleled precision and user-friendly features to elevate diagnostic capabilities.
