Iray 17x17 Wireless Vet Flat Panel Detector
Reference: 1601291051307
Medical Nuclide Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Veterinary Flat Panel Detector
Product Highlights
- Revolutionary Imaging Technology: Engineered with amorphous silicon and a Cesium Iodide (CsI) scintillator, this wireless flat panel detector delivers exceptional image clarity while minimizing radiation exposure.
- Precision Redefined: Featuring a 139 μm pixel pitch and 16-bit ADC, it captures intricate details with remarkable accuracy, ensuring superior diagnostic outcomes.
- Smart Workflow Integration: Equipped with iSync+ Automatic Exposure Detection (AED) for seamless operation and dual-band Wi-Fi (2.4G/5G) for effortless data sharing.
- Durability Meets Versatility: Designed to handle static loads of up to 150 kg uniformly, making it robust enough for diverse veterinary applications.
- Compact and Lightweight: Weighing just 4.6 kg, its portable design ensures ease of use in clinics, labs, or field settings.
Key Specifications
- Active Area: 427 x 427 mm²
- Pixel Matrix: 3072 x 3072
- Resolution: 3.6 lp/mm
- Full Image Time: Typically 5 seconds
- Operating Temperature: 10°C to 90% humidity
- Storage & Transport Humidity: 5% to 95%
- Wireless Connectivity: Dual-band Wi-Fi (2.4G/5G) IEEE802.11 a/b/g/n/ac
- Battery Life: Optimized for extended use with intelligent power management
Unique Selling Points
- ISO 4090 Compliance: Fits seamlessly into existing bucky systems, ensuring compatibility with standard veterinary equipment.
- Direct Deposition CsI: Enhances image quality while reducing radiation dose, prioritizing safety for both animals and operators.
- Long-Lasting Performance: Reliable battery life and rugged construction ensure uninterrupted service in demanding environments.
Related Products
- Portable Veterinary Anesthesia Machine with Isoflurane/Sevoflurane Evaporator
- Intelligent ICU Incubator for Dog/Puppy Veterinary Care
- Multi-Parameter Veterinary Patient Monitor for Clinics
- Portable Fluorescence Imaging System for Veterinary Use
- 360-Degree Rotating Canine Artificial Insemination Device
- Automatic Air Warming System for Animal Surgery
- Veterinary IV Infusion Pump for Surgical Procedures
- CE-Approved Ultrasound Machine for Animals
- Portable Pet Hair Dryer with Three-Speed Settings
GoldHealth Medical is committed to delivering cutting-edge veterinary solutions that empower healthcare professionals to provide the highest standard of care. Explore our range of products designed to enhance efficiency, precision, and patient outcomes.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical presents a cutting-edge medical imaging solution designed to deliver unparalleled precision and reliability. Engineered for versatility, this device is ideal for hospitals, clinics, research institutions, and home healthcare environments. With advanced detector technology and robust construction, it ensures exceptional performance in diagnostic and therapeutic applications.
Key Features and Specifications
- Detector Technology: Utilizes state-of-the-art Amorphous Silicon with Csl Scintillator for superior image clarity and accuracy.
- Active Area: 427mm x 427mm, providing a wide scanning area for comprehensive diagnostics.
- Pixel Matrix: 3072 x 3072, delivering high-definition imaging with intricate detail.
- Resolution: 3.6 Ip/mm, ensuring sharp and precise visualization of anatomical structures.
- Power Source: Fully electric operation for consistent and reliable performance.
- WIFI Connectivity: Dual-band support (2.4G and 5G) with IEEE802.11 a/b/g/n/ac standards for seamless data transfer.
- Trigger Mode: Supports both AED and software-based triggering for flexible operation.
- Static Loading Capacity: Engineered to withstand up to 150kg uniformly distributed weight, ensuring durability in demanding environments.
- Ingress Protection: IPX1-rated design safeguards against water ingress, enhancing reliability in various settings.
Materials and Construction
Crafted with premium materials including metal, plastic, and steel, this device combines strength with lightweight portability. Its robust build ensures long-term durability and stability.
Safety and Compliance
- Complies with GB15979-2002 safety standards, guaranteeing adherence to rigorous quality benchmarks.
- Certified with CE/ISO quality certifications, reflecting GoldHealth Medical’s commitment to excellence and patient safety.
Instrument Classification: Class II medical device, designed for professional and home healthcare use.
Shelf Life: 3 years, ensuring extended usability and value.
Warranty and Support
- Backed by a 1-year warranty, offering peace of mind and assurance of quality.
- Comprehensive online technical support ensures uninterrupted service and assistance whenever needed.
Place of Origin: Proudly manufactured in Guangdong, China, leveraging advanced engineering and production expertise.
Packaging Details
- Selling Units: Single item
- Single package size: XX cm
- Single gross weight: XX kg
GoldHealth Medical’s imaging solution redefines precision and reliability, empowering healthcare professionals and patients alike with advanced diagnostic capabilities.
