IKEDA YKD9122 FHD 108
Reference: 1600062053133
Ultrasonic, Optical, Electronic Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Video System Center
GoldHealth Medical redefines simplicity in the operating room with an all-in-one video system center. This innovative solution combines a high-performance camera, LED light source, medical-grade monitor, and processor into a single, streamlined unit. Designed for intuitive operation, the touch panel interface ensures seamless control without interrupting procedures.
Key Features and Specifications:
- Camera:
- 1/2.8-inch Full HD SONY CMOS sensor
- Image size: 1920x1080P
- Frame rate: 60fps at 1080P
- Progressive scanning system
-
2.1MP resolution with exceptional clarity
-
Light Source:
- 80W cold LED light source
- Color temperature: 5100-7000K
- Luminous flux: ≥800lm
-
Color rendering index: ≥90 for accurate color reproduction
-
Monitor:
- 22-inch medical-grade HD display
-
Rich, accurate colors with deeper contrasts and crisp detail
-
Video Output:
- DVI, HDMI, CVBS outputs for versatile connectivity
-
Built-in USB for FHD imaging storage
-
Performance:
- Minimum illuminance: 0.5LUX for low-light precision
- Signal-to-noise ratio: 50dB (±20%) for clear, noise-free imaging
-
IPX8 waterproof camera for durability and reliability
-
Design and Usability:
- Compact dimensions: 528x105x370mm
- Weight: 9.85kg for portability
- Intuitive controls for white balance, hue, brightness, sharpness, saturation, contrast, gamma settings, zoom, screen freeze, and more
Unique Selling Points:
- 4-in-1 Integration: Combines a 2.1MP camera, LED light source, monitor, and HD recorder into one compact system.
- Advanced White Balance: Auto white balance (AWB) and manual white balance (MWB) ensure optimal color accuracy for every procedure.
- Versatility: Compatible with both rigid and flexible endoscopes, including laparoscopes, hysteroscopes, cystoscopes, arthroscopes, and more.
- Optional Aluminum Crate: Enhances portability and reduces shipping costs.
Applications:
GoldHealth Medical’s video system is designed for a wide range of medical fields, including:
- Arthroscopy
- ENT (Ear, Nose, and Throat)
- Percutaneous transforaminal endoscopic discectomy (PTED)
- Cystoscopy
- Urology
- Gynecology
- Plastic surgery
- Thoracoscopy
- Minimally invasive procedures
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering cutting-edge imaging solutions that enhance diagnostic accuracy and surgical precision. Our systems provide rich, realistic colors and deeper contrasts, ensuring the smallest details are captured with clarity. By integrating advanced technologies, we aim to achieve laparoscopic visibility equivalent to open surgery, empowering healthcare professionals to deliver exceptional patient care.
With decades of expertise in medical imaging, GoldHealth Medical supports endoscopists in every procedure, every day. Our mission is to revolutionize the detection, characterization, and sampling of medical disorders through innovative, easy-to-use technologies.
Technical Highlights:
- Full HD Imaging: Crisp 1080P resolution for unparalleled clarity.
- Customizable Settings: Adjust brightness, sharpness, saturation, contrast, and more to suit specific procedural needs.
- Durable Design: IPX8 waterproof camera ensures high performance in demanding environments.
GoldHealth Medical’s video system center is the ultimate choice for hospitals, clinics, research institutions, and rehabilitation centers seeking reliable, high-performance imaging solutions.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical proudly presents the Medical Endoscopy Equipment, a cutting-edge solution designed for precision and reliability in modern medical environments. This portable endoscope camera is engineered to deliver exceptional performance for urological and surgical applications, ensuring optimal outcomes for both practitioners and patients.
Key Features and Specifications
- Application: Specifically designed for urology and surgical procedures, offering versatility and precision.
- Instrument Classification: Class II medical device, ensuring compliance with rigorous safety and performance standards.
- Power Source: Electric, providing consistent and reliable operation.
- Material: Durable metal construction for enhanced longevity and hygiene.
- Display: Equipped with a high-resolution 22-inch display for clear and detailed imaging.
- Weight: Lightweight at just 10.5kg, ensuring portability and ease of use in various settings.
- Shelf Life: 2 years, maintaining optimal functionality and performance.
Quality Assurance
- Certified with CE and ISO standards, guaranteeing adherence to global quality benchmarks.
- Backed by a 2-year warranty, reflecting our confidence in the product's durability and reliability.
After-Sales Support
- Complimentary spare parts included to ensure uninterrupted usage and peace of mind.
Why Choose GoldHealth Medical?
Our Medical Endoscopy Equipment combines advanced technology, robust design, and user-centric features to meet the demands of hospitals, clinics, research institutions, and home healthcare providers. With its portable design and superior imaging capabilities, this device is an indispensable tool for modern medical professionals.
Applications
- Hospitals and clinics
- Research laboratories
- Rehabilitation centers
- Home healthcare settings
GoldHealth Medical is committed to empowering healthcare providers with innovative tools that enhance patient care and streamline medical procedures.
