Hemadialysis Reprocessor 168b Dialy
Reference: 1601227628607
Transfusion, Dialysis & Circulation Machines
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Revolutionizing Dialyzer Reprocessing with GoldHealth Medical
GoldHealth Medical proudly introduces its cutting-edge Dialyzer Reprocessing Machines, engineered to redefine efficiency, safety, and precision in hemodialysis treatment. Designed for hospitals, clinics, and research institutions, these machines are the epitome of advanced technology and professional expertise.
Product Overview
GoldHealth Medical’s Dialyzer Reprocessing Machines are the world’s first fully automatic systems for sterilizing, cleaning, testing, and priming reusable dialyzers. With a dual workstation option, these machines deliver unparalleled performance, ensuring compliance with the highest standards of safety and stability.
Key Features
- Advanced Automation: Equipped with a PC workstation, the system allows for creating, saving, and searching patient databases, while enabling automatic operation through a simple scan of a code.
- Dual Processing Capability: Efficiently reprocess single or double dialyzers simultaneously, optimizing workflow and saving time.
- Cost-Effective Compatibility: Compatible with multiple brands of disinfectants, ensuring flexibility and reducing operational costs.
- Precision and Safety: Automatic disinfectant dilution and anti-cross infection controls ensure accurate and safe reprocessing.
- Comprehensive Record-Keeping: Built-in and optional external printers provide detailed reprocessing data, including patient information, date, and time.
- Intuitive Design: A user-friendly touch control LCD interface simplifies operation, allowing full automation with just a single tap.
Technical Specifications
- Dimensions:
- Single Workstation: 470mm × 380mm × 480mm (L × W × H)
- Dual Workstation: 480mm × 380mm × 580mm (L × W × H)
- Weight:
- Single Workstation: 30KG
- Dual Workstation: 35KG
- Power Supply: AC 220V ± 10%, 50Hz–60Hz, 2A
- Input Power: 150W
- Water Input Pressure: 0.15–0.35 MPa (21.75–50.75 P.S.I.)
- Water Input Temperature: 10°C–40°C
- Minimum Water Flow Rate: 1.5L/min
- Reprocessing Time: Approximately 12 minutes per cycle
- Operating Environment: Temperature 5°C–40°C, relative humidity ≤ 80%
- Storage Conditions: Temperature 5°C–40°C, relative humidity ≤ 80%
Why Choose GoldHealth Medical?
- Pulsating Current Oscillation Technology: Utilizes forward and reverse rinsing and ultrafiltration to eliminate residue and restore cell volume, extending dialyzer lifespan.
- Accurate Testing: Precise TCV and blood leak tests ensure reprocessing safety and reliability.
- Customizable Processes: Rinse, clean, test, and disinfect functions can be performed individually or in sequence, catering to diverse needs.
- Smart System Settings: Includes machine disinfection, debugging, and evacuation before affusion to prevent disinfectant redilution.
- Concentration Detection: Ensures accurate disinfectant levels for safe and effective sterilization.
- Ergonomic Design: Intuitive touch controls and automated operations simplify use.
- Efficient Water Usage: Advanced engineering reduces water consumption to less than 8L per dialyzer.
- Real-Time Alerts: Troubleshooting tips and alarms provide immediate feedback to operators.
Unique Selling Points
- Proven Reliability: Backed by over 41 patents, these machines have been trusted globally for nearly a decade without any quality complaints.
- Global Reach: Exported to more than 168 countries, including the Philippines, Indonesia, Pakistan, Nigeria, and Sudan.
- Innovation-Driven: Continuous research and development result in the launch of over five new models annually.
- Certified Excellence: CE and ISO certifications ensure compliance with international standards.
- Premium Components: Key parts are sourced from Germany and Japan, guaranteeing durability and performance.
Contraindications
This machine is exclusively designed for reusable dialyzers. It is not suitable for: - Dialyzers used by patients with hepatitis B, hepatitis C, HIV, or other blood-borne infections. - Dialyzers used by patients allergic to the disinfectants employed during reprocessing.
Commitment to Quality
GoldHealth Medical offers: - One-Year Warranty: Extendable to 24 months for select components, with lifelong support and a 12-hour response time for issues. - Original Products: All devices
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Instrument Classification: Class II
Type: Body Fluids Processing Equipment
Product Overview
GoldHealth Medical presents a cutting-edge solution for body fluids processing, designed to deliver precision, reliability, and efficiency in demanding medical environments. This advanced equipment is engineered to meet the rigorous standards of modern healthcare facilities while ensuring user-friendly operation and consistent performance.
Key Features
- Efficient Reprocessing: Achieves a complete cycle in approximately 12 minutes, optimizing workflow and reducing downtime.
- Robust Performance: Operates with an input power of 150W, ensuring stable and reliable functionality.
- Optimal Water Handling: Designed for water input pressure of 0.15~0.35 MPa (21.75 P.S.I.~50.75 P.S.I.) and temperatures ranging from 10℃ to 40℃.
- Consistent Flow Rate: Maintains a minimum water inlet flow of 1.5L/min for uninterrupted operation.
Specifications
- Weight:
- F168-A: 30KG
- F168-B: 35KG
- Input Power: 150W
- Water Input Pressure: 0.15~0.35 MPa (21.75 P.S.I.~50.75 P.S.I.)
- Water Input Temperature: 10℃~40℃
- Minimum Water Inlet Flow: 1.5L/min
- Reprocessing Time: Approximately 12 minutes per cycle
Warranty and Support
- Comprehensive Warranty: Backed by a 1-year warranty for peace of mind.
- After-Sale Service: Includes free spare parts to ensure long-term reliability and performance.
GoldHealth Medical’s body fluids processing equipment is the ideal choice for hospitals, clinics, laboratories, and other healthcare settings, offering unparalleled precision and durability to meet the evolving needs of medical professionals.
