Automatic Chemistry Analyzer with Open Reagent System for Laboratory Testing Devices in Medical Instrument
Reference: 11000007238874
Clinical Analytical Instruments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical presents a cutting-edge Semi-Auto Chemistry Analyzer designed to elevate laboratory precision and efficiency.
Product Highlights
- Intuitive Interface: A vibrant 7-inch color LCD touch screen ensures effortless navigation and real-time data visualization.
- Advanced Incubation System: Equipped with 10 incubators operating at 37°C ±0.3°C, featuring 3 programmable timers for precise control.
- Versatile Testing Modes: Seamlessly switch between flow cell and cuvette testing modes, catering to diverse analytical needs.
- Energy-Saving Design: Includes a sleep mode to conserve energy during idle periods.
- Superior Connectivity: PC connectivity via RS-232 interface for seamless data transfer and enhanced workflow integration.
- Reliable Fluid Management: High-quality pump pipes imported from the United States ensure consistent performance and durability.
Technical Specifications
- Test Methods: Kinetic, Endpoint, Two-point, Absorbance.
- Absorbance Range: 0~4.500Abs with real-time curve display for accurate monitoring.
- Pre-Programmed Tests: 80 test items ready for immediate use.
- Data Storage: Memory capacity for up to 10,000 sample results.
- Wavelength Options: 7 standard filters (340nm, 405nm, 492nm, 510nm, 546nm, 578nm, 630nm) with 1 customizable position.
- Wavelength Precision: ±2nm, bandwidth ≤10nm.
- Absorbance Precision: External: 0.0001Abs, Internal: 0.00001Abs.
- Carry-Over Rate: <1% for minimal cross-contamination.
- Repeatability CV: <1% for consistent and reliable results.
- Incubator Settings: Adjustable temperatures (37°C, 30°C, 25°C) with precision of ±0.1°C.
- Sample Volume: 0~3000µL (500µL recommended).
- Quality Control: SD, CV%, and L-J quality control curves for every test item.
- Flow Cell: 32µL quartz glass with 10nm precision.
- Lamp: Long-life Philips 6V 10W halogen lamp.
- Processor: ARM series high-speed micro CPU for rapid data processing.
- Printer: Built-in thermal-sensitive printer for instant result documentation.
- Operating Environment: Temperature range 0°C~40°C, humidity up to 80%.
- Power Supply: 100~240VAC, 50-60Hz, 100VA.
- Dimensions: 340(L) x 270(W) x 160(H) mm.
- Weight: 5kg for portability and ease of placement.
Unique Advantages
- Unmatched Precision: With advanced absorbance and wavelength accuracy, this analyzer delivers unparalleled reliability for critical diagnostics.
- User-Centric Design: The intuitive touch screen and programmable settings make operation seamless for both novice and experienced users.
- Durability and Performance: High-quality components, including the imported pump pipes and long-life halogen lamp, ensure consistent performance over time.
- Comprehensive Data Management: Store up to 10,000 results and generate detailed quality control curves for every test item.
Applications
Ideal for hospitals, clinics, research laboratories, and veterinary practices, this analyzer is engineered to meet the rigorous demands of modern healthcare diagnostics.
GoldHealth Medical is committed to delivering innovative solutions that empower healthcare professionals with precision, efficiency, and reliability.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical proudly presents the Semi-Auto Chemistry Analyzer, a cutting-edge solution designed for precision and reliability in medical diagnostics. Engineered to meet the demands of modern laboratories, clinics, and healthcare facilities, this Class II medical instrument delivers exceptional performance in biochemical analysis. With its open reagent system and advanced optical technology, it ensures accurate and efficient testing for a wide range of applications, including blood glucose analysis.
Key Features and Specifications
- Brand Name: GoldHealth Medical
- Instrument Classification: Class II Medical Device
- Test Modes: Flow cell or cuvette for versatile testing options
- Absorbance Range: 0~4.500 Abs, ensuring high sensitivity and accuracy
- Carry-Over Contamination: < 1%, minimizing cross-contamination risks
- Repeatability (CV): < 1%, guaranteeing consistent and reliable results
- Wavelengths: 8 wavelengths for comprehensive biochemical analysis
- Reagent System: Open system, offering flexibility in reagent selection
Design and Build
- Material: High-quality electronic components and durable plastic construction
- Gross Weight: 8 kg, lightweight yet robust for easy handling
- Packing Size: 50 x 46 x 29 cm, compact and optimized for storage and transport
Performance Highlights
- Delivers rapid and precise results for critical tests such as blood glucose
- Advanced optical system with minimal carry-over and exceptional repeatability
- User-friendly interface designed for seamless operation by medical professionals
Support and Warranty
- Warranty: 12 months, ensuring peace of mind and long-term reliability
- After-Sales Service: Comprehensive online technical support to address any queries or concerns
Applications
Ideal for hospitals, clinics, research laboratories, and rehabilitation centers, this analyzer is a trusted tool for delivering accurate biochemical insights. Its versatility and precision also make it suitable for point-of-care testing and home healthcare environments.
Supply and Delivery
- Daily Supply Capacity: 50 units, ensuring timely availability for bulk orders
- Shipment Weight: 15 kg, securely packaged to protect the instrument during transit
GoldHealth Medical’s Semi-Auto Chemistry Analyzer combines innovation, precision, and reliability to empower healthcare providers with the tools they need to deliver exceptional patient care.
