AED Pro Portable Defibrillator Machine
Reference: 1600996231769
First-Aid Devices
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Advanced Defibrillator and ECG Monitoring System
Product Overview
GoldHealth Medical presents a cutting-edge defibrillator and ECG monitoring system designed for precision, reliability, and ease of use. Engineered to meet the demands of modern healthcare environments, this device combines advanced technology with intuitive controls, ensuring optimal performance in critical situations.
Key Features and Specifications
- Display and Screen
- High-resolution TFT color display with a diagonal screen size of 7 inches (17.7cm).
- Sweep speed options: 12.5/25/50mm/sec.
-
Resolution: 800x480 pixels for crystal-clear visualization.
-
ECG Monitoring
- Supports 3-lead or 5-lead ECG cables and paddles.
- Lead selection displayed on monitor: I, II, III, AVR, AVL, AVF, V.
- ECG size adjustable: 2.5, 5, 10, 20, 30 mm/mV.
- Heart rate range: 20-350 BPM.
-
Real-time heart rate, lead, and alarm status displayed.
-
Defibrillation
- Biphasic waveform technology for efficient energy delivery.
- Manual external synchronous/asynchronous defibrillation modes.
- Charge time: Less than 10 seconds to reach 360 Joules.
- Energy selection: 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 Joules.
- Voice and visual prompts guide users through the defibrillation process.
-
Monitor displays both selected and delivered energy levels.
-
Safety and Durability
- Withstands 4000V AC/50Hz isolation voltage.
-
Resistant to interference from electrosurgical knives and defibrillation procedures.
-
Battery Performance
- Equipped with dual Li-ion batteries (11.1Vdc, 4000mAh each).
- Standard capacity: Up to 10 hours of ECG monitoring or 60 full-energy discharges.
- Low battery indicator: Flashing icon on display and panel.
-
Recharge rate: 80% in 3 hours, 100% in 5 hours.
-
Built-in Recorder
- Thermal paper width: 50mm.
- High-resolution thermal print head for detailed outputs.
- Records date, time, sweep speed, waveform gain, heart rate, energy (joules), and ECG waveform.
-
Print modes include HR exceed limits alarm recording, auto-timed recording, real-time recording, and defibrillation discharge trigger recording.
-
Power Supply
- AC-DC dual-use: Operates on AC100V~240V, 50/60Hz or battery power.
- Optional vehicle voltage support: DC 12V.
-
Maximum power: 600W.
-
Portability and Design
- Compact and portable design with dimensions: L320xW205xH410mm.
-
Lightweight at 7.5kg for easy transport.
-
Optional Features
- Pulse Oximeter: Displays SpO2 value, waveform, and pulse rate.
- Probe: Standard adult finger clip.
- Range: 0-99% for adult, pediatric, and neonatal patients.
- AED Mode: Voice and screen prompts with programmable energy sequences:
- 200, 300, 360 Joules.
- 150, 150, 200 Joules.
- 50, 75, 100 Joules.
- 30, 30, 50 Joules.
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering innovative medical solutions that empower healthcare professionals. Our defibrillator and ECG monitoring system stands out with its: - Precision Engineering: Advanced biphasic waveform technology ensures effective defibrillation. - User-Centric Design: Intuitive interface with voice and visual prompts simplifies operation. - Unmatched Reliability: Built to withstand extreme conditions and deliver consistent performance. - Versatility: Suitable for hospitals, clinics, research labs, and home care environments.
Experience the GoldHealth Medical difference—where innovation meets excellence.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Power Source: Electric
Shelf Life: 1 Year
Quality Certification: CE
Product Overview
GoldHealth Medical presents a cutting-edge Manual External Synchronous Defibrillator, meticulously engineered to deliver precision, reliability, and ease of use in critical medical scenarios. Designed for hospitals, clinics, research institutions, and home care environments, this device combines advanced technology with user-centric features to ensure optimal patient outcomes.
Key Features
- Energy Selection: Fully adjustable energy levels at 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, and 360 joules, providing tailored treatment for diverse patient needs.
- Rapid Charge Time: Achieves full charge to 360 joules in less than 10 seconds, ensuring swift response during emergencies.
- Waveform Technology: Utilizes advanced biphasic waveform technology for enhanced defibrillation efficacy and patient safety.
- Heart Rate Monitoring: Accurate heart rate detection ranging from 20 to 350 BPM, ensuring precise diagnostics and treatment.
Display and Interface
- Screen Size: 7-inch TFT colour display for clear, real-time visualization of critical data.
- Sweep Speed Options: Adjustable at 12.5, 25, and 50 mm/sec, offering flexibility for detailed waveform analysis.
Patient Connectivity
- Compatible with 3-lead ECG cables, 5-lead ECG cables, or paddles, ensuring seamless integration with existing medical equipment.
Instrument Classification
- Class II Medical Device, designed to meet the highest standards of safety and performance.
After-Sale Support
- Comprehensive 1-year warranty and online technical support, ensuring uninterrupted service and peace of mind.
Packaging Details
- Compact and secure packaging: Single package size of 35 x 24 x 45 cm, with a gross weight of 10 kg.
- Ships in a robust carton, ideal for safe transportation and storage.
Supply Capability
- Monthly supply capacity of 100 units, ensuring timely availability for bulk orders.
GoldHealth Medical’s defibrillator is more than just a device—it’s a lifeline. Engineered with precision and backed by reliability, it empowers healthcare professionals to act decisively and save lives.
