Advanced 300W Monopolar Electrosurgical Unit with High
Reference: 1600195473515
Medical High-Frequency Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Electrosurgical Generator
GoldHealth Medical presents an advanced electrosurgical generator designed to redefine precision and safety in surgical procedures. Engineered with cutting-edge technology, this device offers unparalleled versatility and reliability for a wide range of clinical applications.
Key Features
- Powerful Performance: Delivers up to 300W with both mono-polar and bipolar functionality, ensuring optimal performance across diverse surgical needs.
- Seven Working Modes: Includes pure cut, blend1, blend2, spray coag, forced coag, bipolar coag, and macro bipolar modes, providing flexibility for various surgical techniques.
- Wide Clinical Applications: Ideal for general surgery, thoracic surgery, orthopedic surgery, cardiology, gynecology, urology (underwater TUR), oncology, neurosurgery, and more.
- Advanced Control System: Microprocessor-controlled with an intuitive LCD touch screen display, offering audible and visual indicators along with error codes during operation.
- Enhanced Safety Features: Equipped with a Return Electrode Monitoring system and Power Peak System to minimize tissue damage risks. Both hand and foot controls are available for seamless operation.
- Customizable Outputs: Separate power display and outlet sockets for mono-polar cut, mono-polar coag, macro bipolar, and bipolar coag, allowing each output to be individually configured.
- Smart Memory Function: Automatically remembers the last settings when powered off and includes remote control functionality for precise adjustments via the ESU pencil.
- Compatibility: Can be connected with laparoscopes and endoscopes, expanding its utility in minimally invasive procedures.
- Robust Protection: Features protection against over-voltage, over-current, and defibrillation. Utilizes convection refrigeration without a ventilator for reliable cooling.
- Mobility and Standards: Optionally mounted on a four-wheel cart for easy transport. Meets international safety standards EN60601-1 and EN60601-2.
Specifications
- Power Supply: 220V ± 22V, 50Hz ± 1Hz (110V ± 11V, 60Hz)
- Operating Frequency: 416KHz
- Power Rating: 1100VA ± 10%
Mono-polar Cut
- Pure Cut: 1W ~ 300W (Load 800Ω)
- Blend1: 1W ~ 250W (Load 800Ω)
- Blend2: 1W ~ 200W (Load 800Ω)
Mono-polar Coag
- Spray Coag: 1W ~ 80W (Load 800Ω)
- Forced Coag: 1W ~ 120W (Load 800Ω)
Bipolar
- Bipolar Coagulation: 1W ~ 50W (Load 200Ω)
- Macro Bipolar: 1W ~ 120W (Load 200Ω)
Why Choose GoldHealth Medical?
GoldHealth Medical's electrosurgical generator stands out with its innovative design, comprehensive safety features, and adaptability to various medical fields. Whether you're in a hospital, clinic, or research lab, this device ensures precision, efficiency, and reliability, making it an indispensable tool for modern medical professionals.
Experience the future of surgical technology with GoldHealth Medical.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: High-Frequency Electrosurgical Unit
Brand Name: GoldHealth Medical
Product Overview
The High-Frequency Electrosurgical Unit by GoldHealth Medical is a cutting-edge device designed to deliver precision, safety, and versatility in surgical procedures. Engineered for both clinical and research environments, this Class II medical instrument combines advanced technology with user-friendly features to meet the demands of modern healthcare professionals.
Key Features
- Intuitive Interface: Equipped with an LCD touch screen for seamless operation and real-time monitoring.
- Nine Working Modes: Offers unparalleled flexibility to adapt to diverse surgical requirements.
- Remote Control Functionality: Enhances convenience and operational efficiency during procedures.
- Dual Operating Frequencies:
- Monopolar: 512KHz
- Bipolar: 1024KHz
- Power Rating: 1100VA±10%, ensuring consistent performance under varying conditions.
Technical Specifications
- Power Source:
- 220V±22V, 50Hz±1Hz (or 110V±11V, 60Hz for regions with different electrical standards).
- Shelf Life: 3 years from the date of manufacture.
- Quality Certification: CE-certified for safety and reliability.
- Instrument Classification: Class II medical device.
Applications
This electrosurgical unit is ideal for use in hospitals, clinics, research laboratories, rehabilitation centers, and home healthcare settings. Its precision and adaptability make it suitable for a wide range of surgical procedures.
Warranty & Support
- Warranty: 1-year comprehensive warranty for peace of mind.
- After-Sales Service: Access to online technical support to ensure uninterrupted performance and address any queries.
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering innovative, high-quality medical solutions that empower healthcare providers worldwide. Our High-Frequency Electrosurgical Unit exemplifies our dedication to precision engineering, patient safety, and operational excellence.
Transform your surgical capabilities with GoldHealth Medical’s High-Frequency Electrosurgical Unit – where technology meets trust.
