Advanced 02T MRI Scanner with Film
Reference: 60629043438
Medical MRI Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical
With over a decade of expertise in the medical equipment industry, GoldHealth Medical offers premium, innovative solutions tailored to meet the needs of modern healthcare facilities and patients. Our commitment to quality and one-stop service ensures seamless integration of advanced technologies into your practice or institution.
Product Overview
Experience the future of diagnostic imaging with our state-of-the-art 0.2T MRI Scanner, designed to deliver exceptional precision and reliability. This compact yet powerful system is ideal for hospitals, clinics, research labs, and rehabilitation centers seeking high-quality imaging without compromising on space or budget.
Key Features and Technical Specifications
Magnet System
- Magnet Type: High-performance Nd-Fe-B magnet
- Operating Field Strength: 0.20T
- Homogeneity: ≤8ppm (Vp-p) within a 15cm DSV
Gradient System
- Gradient Strength: 20mT/m
- Slew Rate: <5% for an ellipsoid of 16cm x 16cm x 14cm
RF System
- Spectrometer: Fully digital channel
- Transmitter Amplifier Power: 1KW
- RF Coils: Includes transmitting coils and specialized small joint coils (elbow, wrist, knee, ankle)
Computer System
- Processor: Dual-core CPU with ≥2.8GHz speed
- Operating System: Windows XP
- Storage: ≥250GB hard disk, 2048MB RAM
- Monitor: 22-inch widescreen LCD (TFT) display
- Image Processing: Advanced tools for synchronization, enhancement, zoom, pan, cutting, negative imaging, automatic window adjustments, text annotation, distance measurement, and signal value distribution
- Image Transfer: DICOM3.0 compatibility for seamless integration with hospital PACS systems
Scan Sequences
- Spin Echo (SE)
- Fast Spin Echo (FSE)
- Gradient Echo (GR)
- Fat Suppression Sequences
- Water Suppression Sequences
- Proton Density-Weighted Imaging Sequences
- Orthopaedic Scanning Packages
Scanning Parameters
- Spatial Resolution: Modulation factor ≥0.47 for detailed structural imaging
- Maximum Matrix: 512x512
- Field of View (FOV): 90mm to 180mm
- Scan Levels: Multi-angle scanning (axial, sagittal, coronal, arbitrary slope, multi-angle)
- Image Types: T1-weighted, T2-weighted, T2*-weighted, proton density-weighted, and fat-suppressed images
Patient System
- Maximum Patient Load: 135kg
- Examination Chair: Triaxial design with lift, rotation, and control features for optimal patient positioning
- Communication: Two-way voice transmission system with background music and viewing window for enhanced patient comfort
Site Requirements
- Shielding: Modular shield design for easy installation
- Minimum Installation Area: 3m x 3m
- Power Supply: 220V AC, 50Hz, 3KV
Why Choose GoldHealth Medical?
- Precision and Reliability: Our MRI scanner delivers high-resolution images with advanced processing capabilities, ensuring accurate diagnostics.
- Compact Design: Optimized for smaller spaces without sacrificing performance.
- Patient-Centric Features: Designed for maximum comfort and ease of use, with thoughtful details like background music and a rotating examination chair.
- Seamless Integration: DICOM3.0 compatibility ensures smooth connectivity with existing hospital systems.
GoldHealth Medical is dedicated to empowering healthcare providers with cutting-edge technology that enhances patient care and operational efficiency. Explore the possibilities with our advanced MRI solutions today.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical proudly presents the 0.2T MRI Machine, a cutting-edge solution designed for precision, reliability, and versatility in medical imaging. Engineered to meet the demands of modern healthcare environments, this MRI system delivers exceptional image quality while maintaining operational efficiency. Whether for hospitals, clinics, research institutions, or home healthcare, this device sets a new benchmark for accessibility and performance.
Key Features and Specifications
- Magnet Type: Advanced Nd-Fe-B magnet for superior magnetic field stability.
- Operating Field Strength: 0.20T, ensuring high-resolution imaging for accurate diagnostics.
- Homogeneity: Exceptional uniformity with ≤8ppm (Vp-p) over a 15cm DSV, guaranteeing consistent image clarity.
- Gradient Strength: 20mT/m for enhanced spatial resolution and faster imaging.
- Slew Rate: Optimized at 16cm x 16cm x 14cm, enabling precise and rapid gradient switching.
- Spectrometer: Fully digital channel design for advanced signal processing and minimal noise interference.
- Power of Transmitter Amplifier: 1KW, ensuring robust and reliable performance during operation.
- Ellipsoid Coverage: <5%, minimizing distortion and maximizing imaging accuracy.
- Computer Type: Dual-core CPU processor for seamless operation and efficient data handling.
Instrument Classification and Standards
- Classified as Class II medical equipment, ensuring compliance with rigorous safety and performance benchmarks.
- Designed with a focus on user safety and operational reliability.
Additional Details
- Power Source: Electric, offering stable and energy-efficient operation.
- Shelf Life: 1 year, with optimal performance maintained under recommended conditions.
- Packaging: Securely packed in a durable wooden case to ensure safe transportation.
- Place of Origin: Guangdong, China, reflecting GoldHealth Medical’s commitment to quality manufacturing.
After-Sales Support
GoldHealth Medical provides comprehensive support to ensure uninterrupted service:
- Warranty: 1-year coverage for peace of mind.
- After-Sale Service: Access to online technical support, ensuring prompt assistance whenever needed.
Supply Capability
With a robust production capacity of 1000 sets per month, GoldHealth Medical is equipped to meet the growing demands of global healthcare providers.
Why Choose GoldHealth Medical?
Our 0.2T MRI Machine combines innovative engineering with user-centric design, making it an ideal choice for diverse medical applications. From its advanced Nd-Fe-B magnet to its fully digital spectrometer, every component is crafted to deliver unparalleled performance. Partner with GoldHealth Medical to experience the future of medical imaging technology.
