Viatom Checkme Pro DoctorGrade Home ECG Pulse
Reference: 62488078152
Reflector Apparatus
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical presents the Checkme Pro Doctor – Your Ultimate Home and Professional ECG Solution
Revolutionize cardiac monitoring with the Checkme Pro Doctor, a state-of-the-art Bluetooth-enabled ECG machine designed for precision, convenience, and versatility. Whether you're a healthcare professional or an individual seeking reliable self-monitoring, this device delivers unparalleled accuracy and comprehensive insights into heart health.
Key Features and Technical Specifications
- ECG Capabilities
- Lead Type: Lead I, Lead II
- Display Gain Options: 1.25 mm/mV, 2.5 mm/mV, 5 mm/mV, 10 mm/mV, 20 mm/mV
- Bandwidth: 0.05 to 40 Hz
- Sweep Speed: 25 mm/s
-
Electrode Offset Potential Tolerance: ±300 mV
-
Measurement Precision
- Accuracy: ±2 bpm or ±2%, whichever is greater
- Sampling Rate: 500 Hz
- Heart Rate Measurement Range: 30 to 250 bpm
- ST Measurement Range: -0.5 to +0.5 mV
-
Sampling Accuracy: 16-bit resolution
-
Advanced Analysis
- Heart Rate (HR)
- QRS Duration
- ST Segment Analysis
- QT/QTc Measurements
- Rhythm Analysis: Regular ECG Rhythm, High/Low Heart Rate, High/Low ST Value, Irregular ECG Rhythm, and more
-
Comprehensive diagnostic summaries and detailed waveform images
-
Versatile Monitoring Modes
- Episode Mode: Capture specific events
-
Continuous Mode: Monitor heart activity over extended periods
-
Integrated and External Options
- Built-in ECG electrodes for seamless self-testing
- External ECG cable and electrodes for professional use
Why Choose the Checkme Pro Doctor?
- Unmatched Precision: With a sampling rate of 500Hz and 16-bit accuracy, this device ensures every heartbeat is captured with meticulous detail.
- Comprehensive Insights: From heart rate variability to ST segment analysis, the Checkme Pro Doctor provides a complete diagnostic overview, empowering healthcare providers and users alike.
- Dual Functionality: Equipped with both integrated and external electrodes, it seamlessly transitions from home self-testing to professional clinical use.
- User-Friendly Design: Intuitive operation and Bluetooth connectivity make it accessible for all users, whether in a hospital, clinic, or home setting.
Elevate your cardiac monitoring standards with the Checkme Pro Doctor by GoldHealth Medical – where innovation meets reliability.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: Bluetooth ECG Machine by GoldHealth Medical
Application: Advanced vital signs monitor designed for personal health management and professional use
Key Features
- Multi-Parameter Monitoring: Combines ECG recording, pulse rate monitoring, and blood oxygen measurement for comprehensive health insights
- Exceptional Accuracy: Delivers precise readings with an accuracy rate of up to 99%, ensuring reliable data for informed decisions
- Compact and Portable Design: Lightweight and easy to carry, making it ideal for home self-testing, clinics, and on-the-go health monitoring
Technical Specifications
- Instrument Classification: Class I medical device
- Power Source: Electric
- Material: High-quality, durable plastic
- Shelf Life: 1 year from the date of manufacture
- Certifications: ISO13485, CE
Functions
- Pulse Rate Monitor: Tracks heart rate with precision
- ECG Recorder: Captures detailed electrocardiogram data for analysis
- Blood Oxygen Measurement: Monitors SpO2 levels for better respiratory health assessment
Applications
- Personal health monitoring at home
- Professional use in hospitals, clinics, and laboratories
- Ideal for research institutions, rehabilitation centers, and elderly care facilities
Packaging Details
- Each unit is individually boxed for protection
- Carton specifications: 16 units per carton, dimensions 53.2 x 39.2 x 41.8 cm
- Net Weight: 17.10 kg, Gross Weight: 18.15 kg
Supply and Delivery
- Port of Shipment: Shenzhen
- Supply Capacity: Up to 5,000 units per month
Warranty and Support
- Warranty Period: 1 year, ensuring peace of mind for users
- After-Sale Service: Dedicated online technical support to assist with any queries or troubleshooting
GoldHealth Medical’s Bluetooth ECG Machine is engineered to empower healthcare professionals and individuals alike, offering cutting-edge technology in a user-friendly format. With its robust design, clinical-grade accuracy, and versatile functionality, this device sets a new standard for personal and professional health monitoring.
