SYG056 Middle Ear Analyzer Pro
Reference: 1601367451577
Reflector Apparatus
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical OAE Hearing Screener
Product Overview
GoldHealth Medical introduces an advanced hearing screener that utilizes Otoacoustic Emission (OAE) technology. Designed for both Distortion Product Otoacoustic Emissions (DPOAE) and Transient Evoked Otoacoustic Emissions (TEOAE), this device is ideal for newborn hearing screening and a variety of clinical applications.
Key Features
-
Dual Testing Functionality
Seamlessly switch between DPOAE and TEOAE modes, or use both simultaneously for comprehensive assessments. -
Exceptional Anti-Interference Capability
Engineered to deliver reliable results in diverse environments, including clinics, office spaces, and medical wards. -
Automated Testing
Experience rapid and precise measurements with automated testing protocols, ensuring accuracy and efficiency. -
Sleek and Portable Design
A lightweight, ergonomic design makes this device easy to carry and operate, enhancing usability across settings. -
Advanced Display and Storage
Equipped with a color TFT-LCD monitor, the device provides crystal-clear visualization of menus and test results. -
Instant Printing via Bluetooth
Results can be printed immediately using wireless Bluetooth transmission technology. -
Innovative Probe Design
The integrated probe structure ensures fast and accurate testing, supporting multiple advanced functions: - Tympanogram testing (automatic and manual modes)
- Stapes muscle reflex testing
- Acoustic reflex latency testing
- Acoustic reflection attenuation testing
-
Comprehensive eustachian tube functionality testing (for intact and perforated membranes)
-
Quick Test Mode
Generate two customizable quick tests with a duration of less than 60 seconds. -
Live View Feature
Monitor the progress of your tests in real-time on a connected computer screen for enhanced precision. -
Intuitive Interface
Operate effortlessly with a color touch screen and touch-sensitive buttons designed for seamless interaction.
Technical Specifications
- Probe Tone Frequency: 226Hz (85dB SPL), with optional frequencies of 678Hz, 800Hz, and 1000Hz.
- Pressure Range: -600 to +400 daPa.
- Pump Pressure Velocity: Adjustable from 200daPa/s ±50daPa/s.
- Test Modes:
- Acoustic admittance (Y)
- Acoustic susceptance (B)
- Acoustic conductance (G)
- Stimulation Levels:
- Ipsilateral and contralateral: 500Hz, 1000Hz, 2000Hz, 4000Hz.
- Maximum sound intensity: 110dB HL.
- Acoustic Admittance Measurement Range:
- Tympanogram: 0.2cm³ to 5cm³.
- Tympanic compensation diagram: 0cm³ to 2cm³.
- Total Harmonic Distortion: Less than 1% at 226Hz (85dB SPL).
- Acoustic Reflex Testing:
- Fixed strength, automatic threshold, increasing strength, and manual modes.
- Broadband noise (BBN), low-pass noise (LPN), and high-pass noise (HPN) options.
- Maximum Sound Intensity:
- Ipsilateral: 110dB HL.
- Contralateral: 120dB HL.
Unique Selling Points
- Precision and Reliability: Advanced algorithms ensure accurate and repeatable results.
- Versatility: Suitable for hospitals, clinics, research labs, and home healthcare.
- User-Centric Design: Combines portability, ease of use, and cutting-edge technology to meet the needs of medical professionals.
GoldHealth Medical is committed to delivering innovative solutions that empower healthcare providers worldwide. Explore the future of hearing diagnostics with our OAE Hearing Screener.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: Tympanometer Middle Ear Analyzer by GoldHealth Medical
Key Features:
- Advanced Testing Modes: Offers both automatic and manual tympanogram tests, ensuring flexibility and precision for every diagnostic need.
- Rapid Results: Delivers comprehensive test results in under 60 seconds, optimizing workflow efficiency in busy clinical environments.
- Wide Frequency Range: Equipped with ipsilateral and contralateral stimulus tones at 500Hz, 1000Hz, 2000Hz, and 4000Hz for accurate middle ear assessments.
- High Sensitivity Probe: Features a 226Hz probe tone (85dB SPL) for reliable and consistent measurements.
- Dynamic Pressure Range: Covers -600 to +400 daPa with a pump pressure velocity of 200daPa/s ±50daPa/s, ensuring precise pressure control.
- Maximum Sound Intensity: Capable of delivering up to 110dB HL for comprehensive auditory evaluations.
Technical Specifications:
- Measurement Range (Planar Tympanogram): 0.2cm³ to 5cm³
- Outer Ear Volume Measurement: 0cm³ to 2cm³
- Power Source: Electric
- Instrument Classification: Class II medical device
Quality Assurance:
- Backed by GoldHealth Medical’s commitment to excellence, this tympanometer is CE-certified, guaranteeing compliance with international safety and performance standards.
Warranty & Support:
- Includes a 1-year warranty for peace of mind.
- Access to online technical support, ensuring uninterrupted performance and expert assistance whenever needed.
Why Choose GoldHealth Medical?
GoldHealth Medical’s tympanometer is designed to meet the rigorous demands of modern healthcare environments. Its intuitive operation, combined with advanced diagnostic capabilities, makes it an indispensable tool for hospitals, clinics, research labs, and rehabilitation centers. Whether used for pediatric assessments or geriatric care, this device delivers unparalleled accuracy and reliability, empowering healthcare professionals to provide the best possible care.
Place of Origin: Guangdong, China
Shelf Life: 1 year
