Portable HD USB Endoscope Camera System with Light Source HDMI 108
Reference: 1600953692338
Medical Imaging Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Endoscope Camera System
GoldHealth Medical proudly presents a state-of-the-art Portable USB Endoscope Camera System, designed to deliver unparalleled imaging performance for medical professionals. This advanced system combines cutting-edge technology with exceptional portability, making it an ideal choice for hospitals, clinics, research labs, and home healthcare.
Key Features
- Precision White Balance Adjustment: Achieve accurate color reproduction with one-touch white balance calibration, ensuring image quality that rivals or exceeds leading brands.
- Universal Compatibility: Seamlessly integrates with all rigid endoscopes and supports couplers for Olympus or Pentax flexible endoscopes upon request.
- High-Resolution Imaging: Equipped with a 1/2.8" CMOS sensor, this system delivers 1200 TV lines of superior clarity and ultra-high sensitivity of 0.1 lux.
- Simultaneous Output Options: Supports USB, AV, and BNC outputs, offering versatile connectivity for diverse applications.
Technical Specifications
- Sensor: 1/2.8" CMOS
- Pixels: 2,100,000
- Output Interfaces: HDMI, SDI, VGA, DVI, CVBS
- Output Resolution:
- HDMI: 1920x1080 at 60FPS
- USB: 1920x1080 at 30FPS
- White Balance: Auto (Lock)
- Image Freeze: Supported
- Brightness Adjustment: Supported
- Signal-to-Noise Ratio (SNR): >50dB
- Scanning Mode: Progressive Scanning
- Digital Noise Reduction: Auto
- Backlight Compensation: Auto
- Lens: F22mm
- Cable Length: 2.4m
- Power Supply: DC5V
- Dimensions:
- Camera: 78mm x 32mm x 18mm
- System Unit: 298mm x 214mm x 86mm
- Net Weight: 2.5Kg
Versatile Connectivity
- USB Output: Powered directly by the computer, eliminating the need for an external adapter. Includes free capture software compatible with Windows, Mac OS, Linux, and Android 7.0 or later.
- AV/BNC Output: Connects to HD monitors via HDMI, powered by any DC 5V source such as power banks or mobile chargers, enhancing portability.
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering innovative, reliable, and cost-effective medical solutions. With over a decade of experience, we ensure every product meets the highest quality standards, backed by certifications and rigorous testing. Our dedication to customer satisfaction ensures timely delivery, comprehensive after-sales support, and tailored solutions to meet your specific needs.
Applications
- ENT (Ear, Nose, and Throat) procedures
- Laparoscopy
- Urology
- Veterinary medicine
- Laboratory research
GoldHealth Medical’s Portable USB Endoscope Camera System redefines precision and convenience in medical imaging. Experience the future of endoscopy with a system designed to meet the demands of modern healthcare professionals.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Company Name: GoldHealth Medical
Product Name: Portable USB Endoscope Camera System
Product Overview:
The Portable USB Endoscope Camera System by GoldHealth Medical is a state-of-the-art diagnostic tool designed for precision and versatility in medical and veterinary applications. Engineered with cutting-edge imaging technology, this system delivers exceptional clarity and reliability, making it indispensable for modern healthcare environments.
Key Features and Specifications:
- Applications:
- ENT (Ear, Nose, Throat)
- Urology
- Gynecology
-
Laparoscopy
-
Imaging Excellence:
- Resolution: Full HD 1080p for crystal-clear visuals
- Camera: High-definition camera with 2.1 megapixels (2,100,000 pixels)
- Sensor: Advanced 1/2.8" Sony CMOS sensor for superior image quality
- White Balance: Automatic with lock feature for consistent color accuracy
-
Signal-to-Noise Ratio (SNR): >50dB for minimal noise interference
-
Video Output Options:
- HDMI
- SDI
- VGA
- DVI
-
CVBS
-
Portability and Design:
- Compact and lightweight design for maximum mobility
-
USB-powered system for seamless integration and ease of use
-
Packaging Details:
- Dimensions: 30 x 20 x 10 cm
- Gross Weight: 5.000 kg
-
Shock-absorption materials ensure safe transportation
-
Instrument Classification: Class I Medical Device
-
Supply Capability:
- Up to 1,000 units per month to meet high-demand requirements
Why Choose GoldHealth Medical?
GoldHealth Medical’s Portable USB Endoscope Camera System is meticulously crafted to deliver unparalleled performance in diagnostic procedures. With its advanced imaging capabilities, versatile applications, and robust build quality, this system is the ideal choice for hospitals, clinics, research institutions, and home healthcare providers.
Unique Selling Points:
- Superior image quality with Full HD resolution and Sony CMOS technology
- Versatile applications across multiple medical specialties
- Lightweight, portable design for enhanced usability
- Reliable performance backed by Class I medical device certification
GoldHealth Medical is committed to empowering healthcare professionals with innovative tools that elevate patient care and diagnostic precision.
