Portable Bidirectional Vascular Doppler Ultrasound System
Reference: 1601107276211
Reflector Apparatus
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Portable Bidirectional Vascular Doppler
Experience precision and reliability with the GoldHealth Medical Portable Bidirectional Vascular Doppler, featuring a large color LCD screen. Designed for healthcare professionals, this device offers advanced functionality in a compact, portable design.
Key Features:
- Advanced Display Technology: Equipped with a vibrant TFT LCD screen, it provides real-time visualization of blood flow velocity waveforms and strength. Simultaneous printing of the blood flow curve ensures accurate monitoring.
- Versatile Detection: Utilizes an 8MHz probe to detect arterial and venous blood flow, including average velocity and post-operative vein status in fingers, toes, and other body parts.
- Intelligent Data Management: Powered by a built-in ARM microprocessor, it stores up to 50 detected waveforms for easy access and analysis.
- Seamless Connectivity: High-speed USB and RS-232 ports allow direct connection to computers for advanced waveform analysis, storage, and printing.
- Dual Display Modes: Offers both spectral and velocity views with an LCD cursor indicating blood flow speed for enhanced precision.
Technical Specifications:
- Operating Modes: Continuous work mode for uninterrupted performance.
- Frequency Range:
- Main Unit: 200±80Hz to 5000±1000Hz
- Probe: 350±80Hz to 2500±500Hz
- Ultrasonic Frequencies: 5.0MHz±10% and 8.0MHz±10% with an average intensity of <50mW/cm².
- Velocity Measurement: 0–100 cm/s with a test error of ≤20% (relative error).
- Sensitivity: >100dB for exceptional detection accuracy.
- Printing Speed: 40cm/min or 60cm/min, synchronized with the display.
- Display: 240x320 dots TFT LCD with dual display modes.
- Power Supply:
- Input: AC 110–240V, 50Hz/60Hz
- Output: DC 24V/1.5A
- Built-in Ni-MH rechargeable battery: 14.4V/1600mAh
- Power Consumption: <20W.
- Indicators:
- Power: Blue LED
- Charging: Yellow (charging), Green (fully charged)
- Alarm: Red LED for low battery or lack of paper.
- Dimensions: 210x220x105mm.
- Weight: 1.9kg.
- Environmental Conditions:
- Operating Temperature: +5°C to +40°C
- Humidity: <80%
- Atmospheric Pressure: 86kPa to 106kPa
- Storage Temperature: -10°C to +55°C
Unique Selling Points:
- Precision Engineering: Real-time waveform analysis ensures accurate diagnostics.
- Portability: Lightweight and compact design for use in various clinical settings.
- User-Friendly Interface: Intuitive controls and dual display modes simplify operation.
- Reliability: Built to meet rigorous safety and performance standards, ensuring consistent results.
GoldHealth Medical’s Portable Bidirectional Vascular Doppler is the ultimate tool for modern healthcare providers, offering unparalleled accuracy, versatility, and ease of use. Elevate your diagnostic capabilities with this cutting-edge device.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents the Bidirectional Vascular Doppler Machine – Precision Redefined for Advanced Vascular Diagnostics
-
Product Overview:
The Bidirectional Vascular Doppler Machine is a state-of-the-art diagnostic tool designed for unparalleled accuracy in vascular assessments. Engineered to meet the demands of modern healthcare, this device offers exceptional sensitivity, reliable performance, and user-friendly operation, making it an indispensable asset for medical professionals. -
Key Features and Specifications:
- Instrument Classification: Class III medical device, ensuring the highest standards of safety and reliability.
- Power Source: Electric, providing consistent and dependable performance.
- Shelf Life: 2 years, maintaining optimal functionality over time.
- Quality Certification: CE-certified, guaranteeing compliance with international safety and quality benchmarks.
-
Type: Reflector Apparatus, delivering precise and clear readings for vascular diagnostics.
-
Technical Parameters:
- Ultrasonic Frequency: Dual-frequency options of 5.0MHz ±10% and 8.0MHz ±10%, catering to diverse diagnostic needs.
- Ultrasonic Frequency Average Intensity: < 50mW/cm², ensuring safe and effective operation.
- Velocity Measurement Range: 0–100 cm/s, enabling comprehensive analysis of blood flow dynamics.
- Test Error: ≤20% (relative error), ensuring highly accurate and reliable results.
- Overall Sensitivity: > 100dB, capturing even the faintest signals for precise diagnostics.
- Printing Speed: 40cm/min or 60cm/min, with synchronized display and print functionality for seamless reporting.
- Emissive Waveform: Sine wave, providing consistent and clear signal output.
-
External Output: Equipped with a loudspeaker and a single-channel earphone jack (optional), offering flexibility in monitoring.
-
Materials:
Crafted from high-quality acrylic, metal, and plastic, ensuring durability and a sleek, professional design. -
Unique Selling Points:
- Advanced Diagnostic Capabilities: The dual-frequency ultrasonic technology and high sensitivity make this device ideal for detecting even subtle vascular abnormalities.
- User-Centric Design: Intuitive controls and optional earphone jack enhance usability in various clinical settings.
-
Reliable Performance: Backed by a 1-year warranty and online technical support, ensuring peace of mind for users.
-
Applications:
Perfectly suited for hospitals, clinics, research institutions, laboratories, rehabilitation centers, and home healthcare, this device supports a wide range of vascular diagnostic needs with precision and ease.
GoldHealth Medical is committed to empowering healthcare professionals with cutting-edge tools that elevate patient care and diagnostic accuracy. Experience the future of vascular diagnostics with the Bidirectional Vascular Doppler Machine.
