Neurosurgery Microscope 610 5A with Assistant Bin
Reference: 60770078074
Nerve and cardiovascular surgical instruments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Precision Redefined in Surgical Microscopy
GoldHealth Medical is dedicated to delivering cutting-edge optical and mechanical perfection for modern medical needs. Our surgical microscopes are engineered to provide unparalleled performance, comfort, and adaptability, empowering healthcare professionals across diverse specialties.
Product Highlights
- Superior Optical Performance: Designed for ENT, neurosurgery, and dentistry, our microscopes deliver consistent, high-quality visualization during all phases of surgery. The advanced achromatism system ensures true-to-life color reproduction, while the 3x-16x continuous magnification identifies even the smallest details with precision.
- Enhanced Comfort: Featuring wide-angle eyepieces (12.5x/10x) with a large field of view and 3D stereoscopic imaging, our microscopes provide an ergonomic experience. Adjustable diopter settings (+6D to -6D) and customizable eye cup height ensure comfort for users with or without glasses.
- German-Engineered Precision: Equipped with imported gas springs, the microscope’s optimized force structure allows smooth, precise adjustments to any working angle, enhancing operational efficiency.
- Digital Integration: Seamlessly integrate your workflow with our modular imaging solutions. Compatible with digital SLR cameras, video cameras, and CCD adapters, the system supports 1080p full HD image quality for efficient documentation and intuitive patient communication.
Key Features and Specifications
- Magnification:
- Manual continuous zoom (1:6)
-
Total magnification: 3x to 16x
-
Focusing System:
-
Motorized focusing with a 50mm range controlled via foot switch
-
Binocular Tube:
-
High-brightness 90° binocular tube
-
Eyepiece:
-
12.5x / 10x wide-angle eyepieces
-
Objective Lens:
-
F 300mm (optional: 175mm, 250mm, 350mm)
-
Field of View:
-
Φ95mm to Φ16mm
-
Illumination System:
- Direct illumination with halogen lamp
- Light intensity adjustable in 10 steps (0-60,000 lux)
-
Single fiber optic illumination with a field diameter of Φ70mm
-
Mobility and Stability:
- Floor stand with maximum arm extension of 1100mm
- Height from objective to floor: 800mm
- Base size: 680mm x 680mm
-
Four-wheel brake system for stability
-
Foot Switch:
-
Waterproof design with two functional steps
-
Power and Safety:
- Input voltage: 220V (+10%/-15%) 50Hz or 110V (+10%/-15%) 60Hz
- Power consumption: 180VA
-
Safety class: Class I
-
Environmental Conditions:
- Operating temperature: +10°C to +40°C
- Relative humidity: 30% to 75%
-
Atmospheric pressure: 500 mbar to 1060 mbar
-
Weight:
-
107kg
-
Accessories:
- CCD camera system, beam splitter, CCD adapter, display, mobile phone adapter
- Integrated video adapter compatible with SONY/CANON cameras
- 360-degree rotatable assistant tube
Why Choose GoldHealth Medical?
GoldHealth Medical combines decades of expertise with innovative design to create surgical microscopes that meet the evolving demands of modern healthcare. Our products are crafted with meticulous attention to detail, ensuring durability, precision, and reliability.
From hospitals and clinics to research institutions and rehabilitation centers, our microscopes are trusted by professionals worldwide. Experience the GoldHealth Medical difference—where precision meets innovation.
Applications
- ENT surgeries
- Neurosurgery
- Dentistry
- Microsurgical procedures
- Research and diagnostics
GoldHealth Medical is committed to advancing life science and medical microscopy with products that deliver exceptional value and performance.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical proudly presents the Neurosurgical Microscope, a cutting-edge instrument designed for precision and reliability in neurosurgery, ENT procedures, and neuro-spinal surgeries. Engineered with advanced optical technology and ergonomic design, this microscope delivers unparalleled clarity and control, empowering medical professionals to achieve exceptional outcomes.
Key Features
- Magnification Range: 2x to 12.5x, offering versatile zoom capabilities for intricate surgical procedures.
- Built-in Illumination: Equipped with a 12V/100W Halogen Lamp, ensuring consistent and bright illumination for enhanced visibility.
- Motorized Focusing: Provides smooth and precise adjustments, reducing operator fatigue during lengthy procedures.
- Optical Excellence: Features a 250mm objective lens and 12.5x eyepiece for superior image quality and depth perception.
- Durable Design: Crafted with a sleek white and blue finish, combining aesthetics with functionality.
Technical Specifications
- Instrument Classification: Class II medical device.
- Compliance: Meets IEC 60601 standards, ensuring safety and performance.
- Certifications: ISO-certified for quality assurance.
- Applications: Ideal for neurosurgery, ENT, and neuro-spinal surgery with zoom functionality.
Product Highlights
- Advanced optical system tailored for high-precision surgical tasks.
- Ergonomic design for ease of use and operator comfort.
- Reliable motorized focusing system for seamless operation.
Packaging and Delivery
- Securely packed in durable cartons to ensure safe transportation.
- Ships from Chengdu, China, with a supply capacity of 25 sets per month.
After-Sale Support
- Comprehensive warranty coverage exceeding 5 years for long-term peace of mind.
- Access to online technical support, ensuring prompt assistance whenever needed.
GoldHealth Medical is committed to delivering innovative solutions that redefine medical excellence. The Neurosurgical Microscope is a testament to our dedication to precision, quality, and patient care.
