Mini POC Portable Oxygen Generator for Home Travel
Reference: 1601171923237
Oxygen Concentrator
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Revolutionary Portable Oxygen Concentrator by GoldHealth Medical
Experience the future of respiratory care with GoldHealth Medical’s Portable Oxygen Concentrator, designed to deliver unparalleled performance and user-centric features. Engineered for both clinical precision and everyday convenience, this device is your ultimate solution for oxygen therapy.
Key Features
- Six Pulse Flow Settings: Delivers up to 1470ml of oxygen per minute, ensuring optimal therapy for a wide range of patients.
- Intuitive Interface: A large, vibrant color LCD display provides clear, easy-to-read information at a glance.
- Advanced Sensitivity: Equipped with cutting-edge trigger technology to detect even the slightest breathing effort at lower pressures.
- Comprehensive Audible Alerts: Alerts for power failure, low battery, low oxygen output, flow irregularities, no breath detected in PulseDose mode, high temperature, and unit malfunction ensure safety and reliability.
- Versatile Power Options: Operates seamlessly on AC power, DC power, or rechargeable batteries, offering flexibility for any environment.
- Dual Battery Configurations: Choose between single or double battery packages to extend usage time.
- 24/7 Reliability: Designed for continuous use, whether at home or on the go.
- Compact and Portable: Comes with a convenient carry bag for effortless mobility.
Technical Specifications
- Oxygen Prescription Settings: Adjustable from 1 to 6.
- Operating Temperature Range: 5°C to 40°C (41°F to 104°F).
- Operating Humidity Range: 10% to 90%, non-condensing.
- Operating Atmospheric Pressure Range: 70kPa to 106kPa (0-10,000 ft / 0-3048 m).
- Transport & Storage Temperature Range: -13°F to 158°F (-25°C to 70°C).
- Transport & Storage Humidity Range: 5% to 90%, non-condensing.
- Maximum Limited Pressure: 30 psi.
- Maximum Breathing Rate: 40 BPM.
- Sound Level: Less than 50 dBA at setting 2 and 21 BPM.
- Device Classification: Class II, Type BF Applied Part, IP21.
- DC Input: 12 to 16.8 VDC.
- AC Mains Input: 100-240 VAC, 50/60 Hz.
- OSD Set Points: ≥82% displays a green normal oxygen symbol; <82% triggers a yellow low oxygen symbol with an audible alert.
- Dimensions:
- Host (excluding battery): 187 x 88 x 184 mm.
- Host (including 8-core battery): 187 x 88 x 217 mm.
- Host (including 16-core battery): 187 x 88 x 237 mm.
- Weight:
- Host only: 1.64 kg.
- With 8-core battery: 2.16 kg.
- With 16-core battery: 2.58 kg.
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering innovative, high-quality medical solutions that empower healthcare providers and improve patient outcomes. Our Portable Oxygen Concentrator combines advanced engineering with user-friendly design, making it the ideal choice for hospitals, clinics, research institutions, and home care environments.
This device is more than just a tool—it’s a lifeline. With its robust build, intelligent features, and portability, it redefines what’s possible in oxygen therapy. Elevate your standards with GoldHealth Medical.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical: Precision Oxygen Therapy Redefined
- Instrument Classification: Class II medical device, engineered for reliability and safety in clinical and home environments.
- Oxygen Concentration: Delivers ≥ 90% pure oxygen, ensuring consistent therapeutic performance for patients with respiratory conditions.
- Noise Level: Operates at ≤ 50 dB(A), offering a whisper-quiet experience ideal for use in hospitals, clinics, and residential settings.
- Oxygen Flow Settings: Features 1-6 adjustable prescription settings, providing tailored oxygen delivery to meet individual patient needs.
- Maximum Oxygen Output: Capable of delivering up to 1470 ml/min, ensuring optimal support for even the most demanding therapy requirements.
Design and Usability
- Compact and lightweight design with a single package size of 39 x 27 x 11 cm and a gross weight of just 5.000 kg, making it highly portable and easy to integrate into any medical or home environment.
Warranty and Support
- Backed by a 1-Year Warranty and complimentary spare parts as part of our after-sales service, ensuring uninterrupted performance and peace of mind.
Place of Origin: Proudly crafted in Jiangsu, China, combining advanced engineering with meticulous quality control to deliver a product that meets global healthcare standards.
Why Choose GoldHealth Medical?
Our oxygen concentrator is designed to empower healthcare providers and patients alike, offering precision, durability, and ease of use. Whether for clinical applications, rehabilitation centers, or home care, this device sets a new benchmark for oxygen therapy solutions.
- Key Features at a Glance:
- ≥ 90% oxygen purity for effective therapy
- Whisper-quiet operation at ≤ 50 dB(A)
- Adjustable flow settings (1-6) for personalized care
- Maximum output of 1470 ml/min for high-demand scenarios
- Lightweight and portable design for versatile use
Experience the GoldHealth Medical difference – where innovation meets patient-centered care.
