Mars 1417V Wireless DR Flat Panel Detector for Veterinary
Reference: 1600470828516
Veterinary Diagnostic Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Revolutionary Wireless Veterinary DR Panel by GoldHealth Medical
GoldHealth Medical presents a cutting-edge wireless veterinary DR panel designed to redefine imaging precision and efficiency in medical diagnostics. Engineered with state-of-the-art technology, this panel delivers unparalleled performance for veterinarians, researchers, and healthcare professionals.
Key Features and Technical Specifications:
- Detector Technology: Advanced Amorphous Silicon for superior image quality.
- Full Image Capture Time: Achieves complete imaging in just 5 seconds, ensuring rapid diagnostics.
- Scintillator: Utilizes Cesium Iodide (CsI) for enhanced sensitivity and clarity.
- Dimensions: Compact design at 384 x 460 x 15 mm, offering versatility in various clinical settings.
- Active Imaging Area: Generous 14 × 17 inches, accommodating diverse patient sizes.
- Weight: Lightweight at only 3.3 kg, ensuring portability and ease of use.
- Pixel Matrix: High-resolution 2304 × 2800 matrix for detailed imaging.
- Static Loading Capacity: Supports up to 150 kg uniformly, ensuring durability and reliability.
- Pixel Pitch: 150 μm for exceptional spatial resolution.
- Ingress Protection: IPX1-rated, safeguarding against water drips in challenging environments.
- Spatial Resolution: Impressive 3.4 lp/mm for sharp and precise imaging.
- Operating Temperature Range: Functions optimally between 5°C and 35°C.
- AD Conversion: 16-bit for accurate digital signal processing.
- Storage & Transport Temperature: Withstands extreme conditions from -20°C to 55°C when packaged.
- Battery Life: Offers 8 hours of autonomy, enabling extended use without interruptions.
- Operating Humidity: Operates reliably in 10% to 90% RH (non-condensing).
- Wireless Connectivity: Dual-band Wi-Fi (2.4G and 5G) with IEEE802.11 a/b/g/n/ac standards for seamless data transfer.
- Storage & Transport Humidity: Resilient in 5% to 95% RH (non-condensing) when packaged.
- Trigger Modes: Supports AED (optional) and software-based triggering for flexible operation.
- Target Angle: Optimized at 15° for precise positioning.
- Light Source Activation Time: 30 seconds for consistent illumination.
- Communication Interfaces: Equipped with RS232 and Bluetooth for versatile connectivity.
Why Choose GoldHealth Medical?
GoldHealth Medical specializes in advanced veterinary medical solutions, including imaging systems, surgical equipment, anesthesia machines, and diagnostic tools. Our products are meticulously designed to meet the needs of modern veterinary practices, research labs, and healthcare facilities.
Unmatched Quality Assurance
- Rigorous pre-production sample testing ensures consistency.
- Comprehensive final inspections guarantee product reliability before delivery.
Tailored Packaging for Safety
Our professional, eco-friendly packaging solutions ensure your equipment is protected during transit, combining convenience with environmental responsibility.
GoldHealth Medical is committed to delivering innovative, high-performance medical technologies that empower healthcare providers worldwide. Experience the future of veterinary diagnostics with our wireless DR panel.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Product Name: Digital X-Ray Flat Panel Detector
Key Features:
- Revolutionary Imaging Technology: Utilizes advanced Amorphous Silicon detector technology combined with a Cesium Iodide (CsI) scintillator for unparalleled image clarity and precision.
- High-Resolution Imaging: Boasts a pixel matrix of 2304 x 2800, delivering sharp, detailed radiographic images essential for accurate diagnostics.
- Wireless Freedom: Offers seamless wireless functionality, enabling flexible positioning and reducing clutter in clinical environments.
- Rapid Image Capture: Achieves full image acquisition in just 5 seconds, ensuring swift workflows and minimizing patient discomfort.
- Compact and Lightweight Design: With dimensions of 384 x 460 x 15 mm and a weight of only 9 kg, it is easy to handle and integrates effortlessly into existing setups.
Applications:
- Designed for veterinary diagnostic equipment, this detector is ideal for use in hospitals, clinics, research labs, and rehabilitation centers.
Technical Specifications:
- Size: 1417
- Detector Technology: Amorphous Silicon
- Scintillator Type: CsI
- Pixel Matrix: 2304 x 2800
- Full Image Time: 5 seconds
- Dimensions (mm): 384 x 460 x 15
- Package Size: 40 x 46 x 15 cm
- Gross Weight: 9.000 kg
Why Choose GoldHealth Medical?
GoldHealth Medical’s Digital X-Ray Flat Panel Detector redefines diagnostic imaging with its cutting-edge technology, portability, and precision. Designed to meet the demands of modern healthcare, it ensures superior performance and reliability for both professional and home healthcare environments.
