Eldere LCD Digital ELISA Microplate Reader Photometer for Research
Reference: 1601224670774
Blood Testing Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Microplate Reader
Experience precision and reliability with the GoldHealth Medical Microplate Reader, designed to elevate your laboratory's performance. This advanced microplate reader combines cutting-edge technology with user-focused features, ensuring accurate and efficient results for a wide range of applications.
Key Features and Specifications:
- Light Source: Powered by a 6V 10W Quartz Halogen Lamp, delivering consistent and high-intensity illumination for optimal performance.
- Wavelength Range: Broad spectrum coverage from 340nm to 750nm, enabling versatile analysis across multiple wavelengths.
- Filters: Equipped with four standard filters (405nm, 450nm, 492nm, 630nm) and an eight-position filter wheel for seamless adaptability to various assays.
- Absorbance Range: Measures from 0.000 to 4.000Abs, providing exceptional dynamic range for diverse testing requirements.
- Resolution Ratio: Achieves a resolution of 0.001Abs, ensuring precise and detailed readings.
- Linearity:
- (0, 2.0) ≤ ±1%
- [2.0, 4.0) ≤ ±2%
- Wavelength Accuracy:
- Indication Error: ≤ ±3nm
- Repeatability: ≤ ±1.5nm
- Repeatability:
- [0, 3.0) ≤ 0.3%
- [3, 4.0) ≤ 1%
- Stability:
- [0, 3.0) ≤ 0.3%
- [3.0, 4.0) ≤ 1%
- Accuracy:
- [0, 2.0) ≤ 0.005A
- [2.0, 3.0) ≤ 1%
- [3.0, 4.0) ≤ 1.5%
- Sensitivity: Exceptional sensitivity ≥ 0.010, ensuring detection of even the faintest signals.
- Channel Variation: < 0.01A (1.0Abs standard filters), guaranteeing uniformity across measurements.
- Measurement Speed:
- Single Wavelength: < 10 seconds per 96-well plate
- Dual Wavelength: < 16 seconds per 96-well plate (normal mode)
- Dimensions: Compact design with dimensions of 280mm (W) x 432mm (D) x 220mm (H), saving valuable lab space.
- Weight: Lightweight at just 10kg, offering portability and ease of placement.
GoldHealth Medical’s Microplate Reader is engineered to meet the demands of modern laboratories, delivering unmatched accuracy, speed, and versatility. Whether you're conducting clinical diagnostics, research, or high-throughput screening, this device is your trusted partner in achieving reliable results.
Choose GoldHealth Medical for innovation that empowers your work.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents a cutting-edge solution for laboratory and clinical environments, designed to deliver precision, reliability, and versatility in blood testing applications. This Class II medical instrument is engineered with advanced technology to meet the demands of healthcare professionals and researchers alike.
Product Highlights
- Light Source: Equipped with a durable 6V 10W Quartz Halogen Lamp, ensuring consistent and high-quality illumination for accurate testing.
- Wavelength Range: Broad spectrum coverage from 340nm to 850nm, enabling comprehensive analysis across various testing parameters.
- Filter System: Includes four standard filters (405nm, 450nm, 492nm, 630nm) with an eight-position filter wheel for enhanced flexibility and precision.
- Absorbance Range: Wide detection range of 0.000-4.000Abs, providing exceptional sensitivity for diverse applications.
- Resolution Ratio: High resolution of 0.001Abs ensures detailed and reliable measurements.
- Linearity: Exceptional accuracy with ≤±1% in the range (0, 2.0) and ≤±2% in the range [2.0, 4.0).
- Wavelength Precision: Indication error ≤±3nm and repeatability ≤±1.5nm for consistent performance.
- Repeatability: Outstanding stability with ≤0.3% in the range [0, 3.0) and ≤1% in the range [3.0, 4.0).
- Stability: Reliable operation with ≤0.3% stability in the range [0, 3.0) and ≤1% in the range [3.0, 4.0).
Technical Specifications
- Power Source: Electric, designed for seamless integration into laboratory setups.
- Weight: Compact and portable at 10kg, making it easy to position and relocate as needed.
- Shelf Life: 1 year, ensuring long-term usability and reliability.
- Quality Certification: Backed by MSDS certification for safety and compliance.
Packaging Details
- Package Dimensions: 28 x 43 x 22 cm, optimized for secure and efficient transport.
- Gross Weight: 10.000 kg, balancing durability with ease of handling.
Support and Warranty
- Warranty: Comprehensive 1-year warranty for peace of mind.
- After-Sale Service: Access to online technical support, ensuring uninterrupted performance and assistance whenever required.
Engineered for excellence, this blood testing equipment from GoldHealth Medical is the ideal choice for hospitals, clinics, research institutions, and laboratories seeking unparalleled accuracy and efficiency. Elevate your diagnostic capabilities with a device that combines innovation, precision, and reliability.
