Economical Digital Infusion Pump for Medical Use
Reference: 1600709538887
Emergency & Clinics Apparatuses
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical presents the Advanced Digital Infusion Pump for both animal and human use.
This cutting-edge volumetric infusion pump is engineered to deliver unparalleled precision in controlling infusion rates and volumes. Designed for long-term, high-accuracy, and continuous use, it caters to the diverse needs of modern clinical environments. With an emphasis on safety, ease of operation, and durability, this infusion pump ensures optimal therapeutic outcomes for veterinary and human patients alike.
Key Features: - Crystal-Clear Display: A 3.2" large, sharp screen provides excellent visibility from a distance. - Veterinary-Optimized Design: Tailored specifically for veterinary applications with user-friendly interfaces. - Dual CPU System: Ensures maximum safety and reliability during operation. - Precision Control: Accurately manages infusion rates and volumes with multiple infusion modes. - Enhanced Safety Measures: Anti-bolus system and comprehensive alarm protocols safeguard patients. - Extended Battery Life: Up to 10 hours of continuous use, ensuring uninterrupted performance.
Applications: Widely utilized in various medical settings such as ICU, CCU, veterinary hospitals, clinics, surgery rooms, operating theaters, and emergency departments for intravenous injections.
Technical Specifications: - Infusion Modes: Volume Mode, Time Mode, Drug Mode, Bolus Mode - Rate Units: ml/h, volume/time, d/min - IV Sets Compatibility: Standard single-use IV sets (10, 15, 20, 60d/mL, with diameter 3.4 ~ 4.5mm) - Flow Rate Range: 1.0ml/h to 1200ml/h; 1.0d/min to 400d/min - Increment Settings: 0.1ml/h for 1.0-99.9ml/h; 1ml/h for 100-1200ml/h - Accuracy: Flow rate deviation ≤±5% (after calibration) - VTBI: 0.1 to 9999.9 ml - Total Volume: 0 to 9999.9 ml - Time Settings: 1 minute to 99 hours 59 minutes - Purge Rate: 600ml/h with purge volume display - KVO: Adjustable from 0.1ml/h to 5.0ml/h - Keypad: Numeric keypad for user-friendly operation - Bolus Function: Adjustable flow rate - Night Mode: Automatically reduces LCD brightness after 5 minutes of inactivity - Occlusion Pressure Detection: 40 to 130KPa, adjustable across 0 to 9 levels - Air Bubble Detection: Ultrasonic detection for bubbles ≥50μL, adjustable sensitivity - Motor Anti-reverse Function: Prevents upstream flow - Self-Testing: Comprehensive self-testing at startup and during infusion - Alarm System: Alerts for air bubbles, occlusion, door open, infusion completion, battery status, and more - Power Supply: 3.2" LCD, AC 100V ~ 240V, 50Hz/60Hz, ≤ 25VA, Rechargeable Lithium battery DC11.1V, 3000mAh - Operating Conditions: Temperature 5°C to 40°C, Humidity 20% to 80%, Atmospheric pressure 70 to 106KPa - Dimensions & Weight: 145mm × 150mm × 200mm, 1.7kg
Package Includes: - 1 Advanced Veterinary Infusion Pump - 1 Versatile bracket - 1 Power cord - 1 User Manual
GoldHealth Medical’s infusion pump stands out with its precision engineering, advanced safety features, and versatile application capabilities, making it an indispensable tool in modern medical practice.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents the Veterinary Volumetric Infusion Pump – Precision Redefined for Modern Healthcare
-
Product Overview:
The Veterinary Volumetric Infusion Pump is meticulously engineered to deliver unparalleled accuracy and reliability in fluid delivery. Designed for use in critical environments such as hospital ICUs, veterinary clinics, and research laboratories, this device ensures optimal performance for both infusion and syringe applications. Its robust design and advanced functionality make it an indispensable tool for healthcare professionals. -
Key Features:
- Material: Constructed with high-grade ABS and metal components for enhanced durability and hygiene.
- Functionality: Dual-purpose operation supporting both infusion and syringe modes, adaptable to diverse clinical needs.
- Safety Standards: Compliant with EN 149-2001+A1-2009, ensuring the highest levels of safety and reliability.
-
Certifications: CE and ISO approved, guaranteeing adherence to international quality benchmarks.
-
Technical Specifications:
- Instrument Classification: Class II medical device.
- Power Source: Electric, designed for consistent and uninterrupted performance.
- Color: Sleek white finish for a professional and modern aesthetic.
-
Shelf Life: 1 year from the date of manufacture.
-
Package Contents:
- 1x Veterinary Volumetric Infusion Pump.
- 1x Versatile bracket for flexible installation.
- 1x Power cord for immediate setup.
-
1x User Manual for seamless operation.
-
Dimensions and Weight:
- Single package size: 35 x 25 x 15 cm.
-
Single gross weight: 3.000 kg.
-
After-Sale Support:
- Comprehensive 1-year warranty for peace of mind.
-
Access to online technical support, ensuring prompt resolution of queries.
-
Customization and Flexibility:
- OEM services available to meet specific branding or functional requirements.
- Minimum Order Quantity (MOQ): 1 piece, catering to both small-scale and large-scale needs.
GoldHealth Medical’s Veterinary Volumetric Infusion Pump combines cutting-edge technology with user-centric design, empowering healthcare providers to deliver exceptional care with confidence and precision.
