BIOBASE BDF86H50 Lab Refrigerator Free
Reference: 1601296377304
Medical Cryogenic Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical -86°C Ultra-Low Temperature Freezer
Introducing the GoldHealth Medical -86°C Ultra-Low Temperature Freezer, a state-of-the-art solution meticulously engineered to meet the most demanding requirements for safe and reliable sample preservation. This advanced freezer provides an ultra-cold environment, ensuring the integrity and longevity of your valuable biological and research specimens.
Product Parameters
- Capacity:
- 50L
-
118L
-
Refrigeration Type: Direct refrigeration
-
Defrosting Type: Manual
-
Refrigerant:
- R600a: 96g (50L), 114g (118L)
- R290: 16g (50L), 19g (118L)
- R1150: 29g (50L), 34g (118L)
-
R14: 21g (50L), 25g (118L)
-
Noise: 55dB(A)
-
Ambient Temperature: 10~32℃
-
Temperature Range: -40℃ to -86℃
-
Evaporator: Built-in coil, copper pipe
-
Condenser: Copper tube and aluminum fin
-
Sensor: PT1000
-
Thermostat: Electronic thermostat
-
Display: LED
-
Power Supply: 110~220V/50~60Hz
-
Power:
- 295W (50L)
-
536W (118L)
-
Current:
- 2.2A (50L)
-
3.6A (118L)
-
Internal Material: S.S. 304
-
External Material: Spray cold-rolled steel plate
-
Lagging: Foamed polyurethane cyclopentane
-
Audible and Visual Alarm:
- High and low temperature alarm
- Power fault alarm
- Thermostat fault alarm
-
Door switch alarm
-
Net Weight:
- 83kg (50L)
-
103kg (118L)
-
Gross Weight:
- 125kg (50L)
-
150kg (118L)
-
Internal Size (WDH):
- 400×400×355mm (50L)
-
540×400×580mm (118L)
-
External Size (WDH):
- 695×740×985mm (50L)
-
1140×730×930mm (118L)
-
Package Size (WDH):
- 810×830×1180mm (50L)
- 1240×800×1065mm (118L)
Unique Selling Points
-
Precision Temperature Control: Our electronic thermostat and PT1000 sensor ensure precise temperature regulation within the range of -40℃ to -86℃, maintaining the integrity of sensitive samples.
-
Advanced Refrigeration System: Utilizes a combination of high-efficiency refrigerants (R600a, R290, R1150, R14) to achieve and sustain ultra-low temperatures reliably.
-
Durable Construction: Built with S.S. 304 internal material and a robust spray cold-rolled steel plate exterior, ensuring long-lasting performance and resistance to wear and tear.
-
Comprehensive Alarm System: Equipped with audible and visual alarms for high and low temperatures, power faults, thermostat issues, and door switches, providing peace of mind and immediate alerts to potential problems.
-
Optimized Design: Features a built-in coil evaporator and copper tube with aluminum fin condenser for efficient cooling and energy conservation.
-
Quiet Operation: Designed to operate at a noise level of just 55dB(A), making it suitable for use in noise-sensitive environments like laboratories and hospitals.
Choose GoldHealth Medical for unparalleled reliability and performance in ultra-low temperature storage solutions.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Company Name: GoldHealth Medical
Product Name: -86 Degree Ultra-Low Temperature Freezer
Product Overview
The -86 Degree Ultra-Low Temperature Freezer by GoldHealth Medical is engineered to deliver unparalleled performance for the most demanding cold storage needs. Designed with precision and reliability in mind, this freezer is ideal for preserving biological samples, vaccines, enzymes, and other temperature-sensitive materials. Its robust construction and advanced features make it a trusted choice for hospitals, research labs, and biotech facilities worldwide.
Key Features
- Temperature Precision: Maintains an exceptional accuracy of ±0.1°C, ensuring consistent and reliable storage conditions.
- Wide Temperature Range: Operates between -40°C and -86°C, offering flexibility for diverse applications.
- Durable Interior: Constructed with premium 304 stainless steel for superior corrosion resistance and hygiene.
- LED Display: Intuitive and easy-to-read interface for real-time temperature monitoring.
- Manual Defrosting: Provides control over defrost cycles to suit specific operational needs.
- Spacious Design: Includes 2 adjustable shelves, maximizing storage capacity within its 50L interior.
Technical Specifications
- Capacity: 50 liters
- Shelves: 2 (adjustable)
- Temperature Range: -40°C to -86°C
- Temperature Accuracy: ±0.1°C
- Defrosting Type: Manual
- Display Type: LED
- Internal Material: 304 Stainless Steel
- Package Dimensions (WDH): 810 x 830 x 1180 mm
- Gross Weight: 125 kg
Warranty & Support
- Warranty: Comprehensive 1-year warranty for peace of mind.
- After-Sales Service: Access to online technical support, ensuring uninterrupted performance and quick resolution of queries.
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering cutting-edge solutions that redefine standards in medical equipment. Our -86 Degree Ultra-Low Temperature Freezer combines innovative engineering with user-centric design, making it the ultimate choice for professionals who demand precision, durability, and reliability.
Applications
- Hospitals and clinics
- Research laboratories
- Biotechnology and pharmaceutical industries
- Blood banks and diagnostic centers
- Long-term sample preservation
Invest in the GoldHealth Medical -86 Degree Ultra-Low Temperature Freezer and experience the perfect blend of innovation, quality, and performance.
