B129A Sperm Microcirculation Microscope
Reference: 1601000131504
Medical Imaging Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Microscope Series
Product Overview
GoldHealth Medical presents a meticulously engineered series of microscopes designed to deliver unparalleled precision and reliability. This advanced series is crafted for professionals in hospitals, clinics, research labs, and more, offering exceptional optical performance and user-friendly features.
Key Components and Features
- Objective Lens Case and Nosepiece
- Precision-engraved objective lenses with detailed specifications: magnification, mechanical tube length, and cover slip thickness.
- Example: 40X objective lens (40/0.65; 160/0.17) indicates 40X magnification, 160mm tube length, and 0.17mm cover slip thickness.
- 100X oil immersion lens marked with "oil" for enhanced clarity.
-
Quadruple revolving nosepiece ensures seamless rotation and precise alignment.
-
Eyepiece
- Equipped with WF10X wide-field eyepieces for an expansive field of view.
-
Binocular tube spacing adjustable between 55mm and 75mm for personalized comfort.
-
Stage
-
Low-position coaxial knobs enable effortless operation and precise control.
-
Condenser
- ABBE condenser with N.A. = 1.25 and an iris diaphragm for optimal illumination.
- Optional kosher illumination for specialized applications.
-
Smooth vertical movement with factory-calibrated precision—designed not to be disassembled by users.
-
Focusing Adjustment
- Coarse and fine focusing range of 20mm, located on both sides for ergonomic access.
- Rapid adjustments via the coarse handwheel and ultra-fine precision with the micro handwheel.
-
Micro handwheel features indexed markings, with each division representing 0.002mm for exact positioning.
-
Base
- Robust foundation with four rubber feet for enhanced stability and vibration resistance.
Specifications
- Warranty: 1 year
- Customization: OEM support available
- Origin: Designed and manufactured in China
- Application: Biological microscopy
Why Choose GoldHealth Medical?
GoldHealth Medical is a trusted name in the medical equipment industry, renowned for delivering cutting-edge solutions. With over 8 years of experience, we specialize in a wide range of medical devices, including X-ray machines, ultrasound scanners, ECG systems, patient monitors, ICU equipment, and laboratory tools. Our commitment to quality ensures every product undergoes rigorous pre-production and final inspections.
Applications
This microscope series is ideal for:
- Hospitals and clinics
- Research institutions and laboratories
- Rehabilitation centers and nursing homes
- Educational institutions and home users
Standout Features
- Superior optical clarity with precision-engineered lenses
- Ergonomic design for extended use
- Customizable configurations to meet specific needs
- Reliable performance backed by a 1-year warranty
GoldHealth Medical is dedicated to empowering healthcare professionals with tools that redefine accuracy and efficiency. Explore our range and elevate your diagnostic capabilities today.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical: Revolutionizing Precision with the Bio-Microscope
-
Product Overview:
The GoldHealth Medical Bio-Microscope is a cutting-edge Class I medical instrument designed for unparalleled precision and reliability in diagnostic and research applications. Engineered to meet the needs of hospitals, clinics, laboratories, and research institutions, this microscope delivers exceptional clarity and performance for professionals who demand accuracy. -
Key Features:
- Optical Excellence: Equipped with a high-quality binocular or trinocular tube for superior visualization and adaptability.
- Advanced Illumination: Includes a spare halogen lamp (6V 20W) or LED lighting, ensuring consistent brightness and energy efficiency.
- Comprehensive Accessories: Comes with cedar wood oil (0.3ml/bottle), a dust cover, and a detailed operation manual for seamless setup and maintenance.
-
Compact and Durable Design: Packaged in a robust carton or wooden case, ensuring safe transportation and long-lasting use.
-
Technical Specifications:
- Mainframe of bio-microscope: 1 set
- Binocular or Trinocular tube: 1 pc
- Cedar wood oil: 0.3ml/bottle
- Spare halogen lamp: 6V 20W/LED
- Dust cover: 1 pc
-
Operation Manual: 1
-
Packaging Details:
- Single package size: 35 x 30 x 40 cm
-
Single gross weight: 6.000 kg
-
Supply and Support:
- Warranty: Comprehensive 1-year warranty for peace of mind.
- After-Sales Service: Access to online technical support for prompt assistance.
-
Supply Ability: Capable of delivering 2000 sets per month to meet high-volume demands.
-
Place of Origin: Proudly crafted in Guangdong, China, ensuring world-class quality and innovation.
GoldHealth Medical is committed to empowering healthcare professionals with tools that redefine precision and reliability. Elevate your diagnostic capabilities with our state-of-the-art bio-microscope.
