Advanced Portable Insulin Infusion Pump for Diabetes Management
Reference: 60455058161
Disposable Infusion Pump
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Insulin Infusion Pump
Experience the next generation of diabetes care with GoldHealth Medical's advanced insulin infusion pump. Designed for precision, safety, and ease of use, this portable device is tailored to meet the needs of both healthcare professionals and patients.
Key Features
- Intuitive Menu Interface: A simple, user-friendly design ensures effortless navigation and operation.
- Customizable Bolus Infusion: Adjustable infusion speed with multiple modes, including pulse-type bolus administration. Intelligent meal modes and dose guidance help optimize blood glucose regulation.
- Fast Basal Rate Setting: Pre-stored basal plans with automatic correction based on glucose deviations. Clear charts provide accurate and easy adjustments.
- Automatic Screw Rewind: Eliminates manual air exhaust, calculates precise liquid amounts, and minimizes human error.
- Compact and Portable Design: A large, 4-line display offers clear visibility, while its small size ensures convenience and portability.
- Cost-Effective Operation: Powered by a single AAA alkaline battery with a standard luer port, ensuring affordability without compromising performance.
- Enhanced Safety Protocols: Dual CPU system and password-protected dose adjustments ensure secure and reliable operation.
- Advanced Waterproofing: IPX8-rated reservoir and IPX7-rated pump allow for worry-free use and cleaning.
Technical Specifications
- Dimensions: 78x52x20 mm
- Weight: 55g
- Basal Segments: 24/48 basal rates
- Infusion Frequency: 2~60 times/hour
- Least Increment: 0.1/0.05 u
- Infusion Modes: Basal infusion, temporary basal infusion, bolus infusion (intelligent mode/meal mode), square wave infusion
- Basal Infusion Range: General: 0~2u; Doctor: 0~5u
- Temporary Basal Infusion Range: Speed: 0~200u; Time: 0~24 hours
- Bolus Infusion Range: General: 0~40u; Doctor: 0~85u
- Daily Total Range: General: 60u; Doctor: 200u
- Insulin Filling Method: Auto-reset screw driven by motor with automatic insulin calculation
- Alarming Features: Alerts for blockages, low energy, low reservoir, empty reservoir, excessive force, and meal reminders
- CPU Configuration: Dual CPU
- Reservoir Volume: 3.0 ml
- Infusion Set Connection: Standard luer lock connector
- Battery: 1.5V AAA alkaline battery
- Waterproof Rating: IPX8
- Operating Conditions:
- Temperature: 5~40°C
- Relative Humidity: ≤93%
- Pressure: 8.6kpa~106kpa
- Storage Conditions:
- Temperature: -20°C~50°C
- Relative Humidity: ≤93%
- Pressure: 8.6kpa~106kpa
Why Choose GoldHealth Medical?
GoldHealth Medical is a trusted leader in diabetes care solutions, offering innovative and reliable medical devices designed to enhance quality of life. With over 15 years of expertise, our commitment to research, development, and quality ensures cutting-edge products that meet global standards. Partner with us to deliver exceptional care and achieve better health outcomes.
Experience the difference with GoldHealth Medical’s insulin infusion pump—where precision meets simplicity.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Company Name: GoldHealth Medical
Product Introduction:
The GoldHealth Medical Diabetes Pump is a cutting-edge solution designed to provide precise insulin delivery for individuals managing diabetes. With its advanced dual-CPU system and IPX8-rated reservoir, this device ensures unparalleled accuracy, safety, and reliability. Its sleek, compact design combines functionality with aesthetics, making it ideal for both professional healthcare settings and personal use.
Key Features and Specifications:
- Instrument Classification: Class III medical device
- Color Options: Black & Deep Green
- Warranty: 4 years of comprehensive coverage
- Power Supply: Operates on a single AAA alkaline battery for extended convenience
- Insulin Reservoir Capacity: 305 units, ensuring fewer refills and uninterrupted therapy
- CPU Configuration: Dual-CPU system for enhanced precision and reliability
- Reservoir Protection: IPX8 waterproof rating, safeguarding against moisture and environmental factors
- Infusion Frequency: Fully customizable with a range of 1-60 times per hour to meet individual needs
- Compact Size: 78x52x20 mm, offering portability and discreet wearability
Additional Details:
- Place of Origin: Guangdong, China
- Packaging: Export carton designed for secure and efficient shipping
- Delivery Time:
- Sample orders: 1-3 days
- Bulk orders: 5-7 days
- Port of Shipment: Shenzhen
- Supply Ability: 1000 units per month, with OEM and ODM services available to meet specific requirements
Unique Selling Points:
- Advanced dual-CPU technology ensures unmatched accuracy in insulin delivery.
- IPX8-rated reservoir provides superior protection, making the device reliable in diverse environments.
- Compact and stylish design enhances user comfort and confidence.
- Customizable infusion settings cater to individual patient needs, promoting personalized care.
GoldHealth Medical is committed to delivering innovative solutions that empower healthcare professionals and patients alike. The Diabetes Pump exemplifies our dedication to quality, precision, and patient-centric design.
