6C Multifunctional Ophthalmology Neurosurgery Microscope
Reference: 1999529000
Nerve and cardiovascular surgical instruments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical presents a cutting-edge multifunctional operating microscope designed for ophthalmology, microsurgery, and neurosurgery. This advanced microscope is uniquely equipped with a double assistant binocular system, offering unparalleled optical precision and the largest depth of field in its class. Its versatility makes it ideal for a wide range of applications, including neurosurgery, ophthalmology, dentistry, and more.
Key Features and Specifications:
- Double Assistant Binocular System: Enhanced with a new changing diaphragm for superior depth of field.
- Eyepieces:
- Magnification: 12.5x
- Pupil Distance Adjustable Range: 55mm to 75mm
- Diopter Adjustment Range: +5D to -5D
- Focus of Second Object Lens: 180mm
- Binocular Tube:
- Variable Angle: 30° to 90°
- New Pupil Distance Adjustment Feature
- Magnification:
- 6:1 Zoom, Motorized
- Magnification Range: 4.5x to 27x
- Field of View: Φ45mm to Φ7.5mm
- Coaxial Assistant’s Binocular Tube:
- Manual 3-Step Changer
- Total Magnification: 6.4x, 10.8x, 17.3x
- Field of View: Φ31mm, Φ19mm, Φ12mm
- Coaxial Illumination:
- Illumination Diameter of Light Spot: Φ50mm
- Illumination Intensity: 100,000 lux
- Objectives:
- Standard Focal Length: 200mm (Optional: 175mm, 250mm, 300mm, 350mm, 400mm)
- Focusing:
- Motorized
- Range: +/-25mm
- Speed: 33 seconds for full distance
- X-Y Translator:
- Motorized Movement in X-Y Direction
- Range: +/-25mm
- Maximum Arm Length: 1200mm
- Oblique Illumination:
- Illumination Range: 50mm
- Illumination Intensity: 30,000 lux
- Stand:
- Swing Angle of Carrier Arm: 0° to 300°
- Height from Objective to Floor: 800mm to 1250mm
- Foot Switch: Waterproof with 8 Function Steps
- Weight: 164kg
Why Choose GoldHealth Medical?
GoldHealth Medical is renowned for its commitment to innovation and precision. Our operating microscopes are developed with decades of expertise, leveraging advanced optical technologies to deliver exceptional performance. This microscope is not just a tool but a reliable partner in achieving surgical excellence.
Additional Details:
- Research & Development: Backed by extensive research and development since the 1970s, our products are crafted with insights from leading optical experts.
- Versatility: Suitable for various medical environments, including hospitals, clinics, research institutions, and rehabilitation centers.
- Precision Engineering: Every component is meticulously designed to ensure durability, reliability, and ease of use.
GoldHealth Medical's operating microscope stands out with its unique double assistant binocular system and superior optical capabilities, making it an indispensable asset for medical professionals seeking precision and reliability in their practice.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Product Name: Multifunctional Operating Microscope
Product Overview
The Multifunctional Operating Microscope by GoldHealth Medical is a state-of-the-art solution designed for precision and versatility in medical procedures. Engineered to meet the demands of modern healthcare, this microscope is ideal for ophthalmology, microsurgery, and neurosurgery applications. With its advanced features and ergonomic design, it ensures unparalleled clarity, comfort, and reliability for surgeons and medical professionals.
Key Features
- Magnification Range: 4.5x to 27x, providing exceptional detail and adaptability for intricate procedures.
- Binocular Tube Angle: Adjustable from 30° to 90°, offering optimal positioning and ergonomic comfort.
- Focusing Mechanism: Motorized focusing for smooth, precise adjustments during operations.
- Illumination System: Coaxial illumination ensures uniform lighting, enhancing visibility and reducing eye strain.
- Tube Configuration: Designed for three-person use, enabling collaborative procedures with ease.
- Objective Lens: 200mm focal length for a wide field of view and sharp imaging.
Applications
- Ophthalmology microsurgery
- Neurosurgery
- General microsurgical procedures
Certifications
- ISO-certified for quality and safety assurance
Packaging and Delivery
- Packaging Details: Securely packed in durable cartons to ensure safe transportation.
- Port of Origin: Chengdu, China
Supply Capacity
- Monthly Supply Ability: 25 sets per month, ensuring timely delivery for bulk orders.
Warranty and Support
- Warranty: Comprehensive 1-year warranty for peace of mind.
- After-Sales Service: Access to online technical support for seamless assistance and troubleshooting.
Instrument Classification
- Class I medical device, meeting stringent industry standards for safety and performance.
GoldHealth Medical’s Multifunctional Operating Microscope is more than just a tool—it’s a commitment to excellence in healthcare. Designed to empower medical professionals with precision and confidence, it is the ideal choice for hospitals, clinics, research institutions, and rehabilitation centers worldwide.
