Medical equipment sourcing
Ultra Low Temp Freezer 86C MedLab Pro
Reference: 1601009752415Medical Cryogenic Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Vertical Ultra Low Temperature Freezer
GoldHealth Medical presents the Vertical Ultra Low Temperature Freezer, designed for medical-grade temperature-controlled storage and processing solutions. Ideal for pharmacies, blood banks, laboratories, and research facilities, this freezer offers unparalleled precision and reliability.
Key Features
Temperature Control
- Microcomputer-controlled temperature with an accuracy of 0.1°C.
- Adjustable temperature settings with customizable start-stop temperature differentials.
- User-defined alarm temperature thresholds.
Safety
- Equipped with brand compressors for consistent performance.
- Comprehensive alarm systems featuring buzzer alerts with light indicators.
- Alerts for high and low temperatures, sensor failure, and frequent start protection.
Refrigerating System
- Ultra-thick foam insulation and double-sealed doors for optimal temperature retention.
- Optimized evaporator and condenser layout for efficient cooling.
- LED display for clear temperature monitoring.
- CFC-free, environmentally friendly design.
Humanized Design
- Stainless steel shelves for easy cleaning and maintenance.
- Food-grade stainless steel inner tank, resistant to corrosion.
- Fixed casters paired with universal wheels for mobility.
- Rapid cooling technology ensures quick temperature adjustments.
- Wide voltage range compatibility (187V~242V).
- Operates effectively in ambient temperatures between 16-32°C.
- Optional remote monitoring system and temperature recorder.
Available Models
- 28L Capacity: External Dimensions: 505x520x1165 mm, Internal Dimensions: 270x265x400 mm, Temperature Range: -25/-40/-60/-86°C, Power: 270~400W, Net Weight: 6 kg.
- 58L Capacity: External Dimensions: 600x665x1145 mm, Internal Dimensions: 364x405x410 mm, Temperature Range: -25/-40/-60/-86°C, Power: 300~480W, Net Weight: 78 kg.
- 108L Capacity: External Dimensions: 700x730x1260 mm, Internal Dimensions: 460x460x510 mm, Temperature Range: -25/-40/-60/-86°C, Power: 300~480W, Net Weight: 107 kg.
- 158L Capacity: External Dimensions: 700x700x1580 mm, Internal Dimensions: 460x455x800 mm, Temperature Range: -25/-40/-60/-86°C, Power: 320~500W, Net Weight: 123 kg.
- 208L Capacity: External Dimensions: 810x730x1600 mm, Internal Dimensions: 570x485x800 mm, Temperature Range: -25/-40/-60/-86°C, Power: 350~550W, Net Weight: 142 kg.
- 308L Capacity: External Dimensions: 810x760x1810 mm, Internal Dimensions: 570x485x1140 mm, Temperature Range: -25/-40/-60/-86°C, Power: 400~580W, Net Weight: 160 kg.
- 408L Capacity: External Dimensions: 850x900x1780 mm, Internal Dimensions: 610x615x1120 mm, Temperature Range: -25/-40/-60/-86°C, Power: 450~950W, Net Weight: 200 kg.
- 508L Capacity: External Dimensions: 870x1030x1975 mm, Internal Dimensions: 570x710x1225 mm, Temperature Range: -25/-40/-60/-86°C, Power: 800~1050W, Net Weight: 255 kg.
- 608L Capacity: External Dimensions: 940x980x1920 mm, Internal Dimensions: 700x680x1255 mm, Temperature Range: -25/-40/-60/-8
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Product Name: Vertical Deep Freezer
Product Overview
The Vertical Deep Freezer by GoldHealth Medical is a cutting-edge solution designed for precise temperature control in medical and laboratory environments. Engineered with medical-grade refrigeration technology, this freezer ensures the safe storage of sensitive materials such as vaccines, biological samples, and pharmaceuticals. Its sleek design, advanced features, and robust performance make it an indispensable asset for hospitals, research institutions, and laboratories.
Key Features
- Temperature Range: -25°C to -86°C, offering unparalleled flexibility for diverse medical applications.
- Capacity Options: Available in multiple sizes ranging from 28L to 938L, with the 308L model being a popular choice.
- Refrigeration Type: Medical-grade refrigeration ensures consistent and reliable cooling performance.
- Display: Equipped with a high-visibility LED display for real-time temperature monitoring.
- Compressor: Powered by a premium brand compressor for energy efficiency and durability.
- Door Design: Ultra-thick foam insulation combined with a double-sealed door structure minimizes temperature fluctuations and enhances energy efficiency.
- Alarm System: Advanced high and low temperature alerts, along with sensor failure notifications, ensure maximum safety and peace of mind.
Applications
- Ideal for medical facilities, research labs, and pharmaceutical storage.
- Suitable for hospitals, clinics, rehabilitation centers, and home healthcare environments.
Additional Details
- Instrument Classification: Class I medical device, ensuring compliance with stringent safety and quality standards.
- Warranty: Backed by a comprehensive 1-year warranty for added reliability.
- After-Sales Support: Access to online technical support for seamless troubleshooting and maintenance.
Packaging Specifications
- Package Dimensions: 145 x 98 x 115 cm (Single item).
- Gross Weight: 175 kg.
GoldHealth Medical’s Vertical Deep Freezer combines precision engineering, innovative design, and user-centric features to deliver unmatched performance in critical storage applications. Choose GoldHealth Medical for a product that prioritizes safety, efficiency, and reliability.
