SYO003 Medical Touch Screen Dialyzer Reprocessor for
Reference: 60314405056Transfusion, Dialysis & Circulation Machines
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Dialyzer Reprocessing Machine
Revolutionizing dialyzer reprocessing with precision engineering and intelligent design, GoldHealth Medical presents a state-of-the-art solution for healthcare facilities and research institutions. This advanced machine is meticulously crafted to clean, sterilize, and test both high and low flux dialyzers while offering seamless integration into clinical workflows.
Key Features
- Intelligent Self-Testing: Ensures operational readiness with automated system diagnostics.
- Comprehensive Data Storage: Simplifies operation by securely storing detailed dialyzer information.
- Intuitive Touchscreen Interface: Designed for ease of use with a user-centric layout.
- Optimized Back Rinse: Delivers superior cleaning performance.
- Precision Monitoring: Automatically verifies the accuracy of blood volume and pressure sensors.
- Versatile Compatibility: Processes various types of hollow fiber dialyzers, including hemodialysis, hemodiafiltration, and hemofiltration.
- Eco-Friendly Design: Features water-saving technology and low inflow pressure to reduce resource consumption.
- Power Outage Protection: Retains data during unexpected power interruptions.
- Advanced Maintenance Interface: Provides real-time monitoring of all valves and pumps for optimal performance.
Safety Assurance
- Disinfectant Concentration Sensor: Ensures effective disinfection by maintaining the required concentration, preventing medical incidents.
- Smart Alarm System: Alerts operators to tube clogging or kinking, ensuring safe and efficient disinfection.
- Automated Fluid Management: Prepares cleaning solutions and disinfectants, followed by thorough rinsing and filling of the dialyzer.
Technical Specifications
- Dimensions: 480x430x560mm
- Weight: 25 Kg
- Voltage: AC220V
- Ambient Temperature: 5~40℃
- Relative Humidity: 10~80%
- Dialyzer Testing:
- Pressure Test: Applies 290±10mmHg to the blood chamber.
- Pressure Loss Test:
- Low-Flux Dialyzer: <0.83mmHg/sec
- High-Flux Dialyzer: <1.25mmHg/sec
- Volume Test Range: 0~150mL (±3% tolerance)
- Water Requirements:
- Temperature: 10~30℃
- Quality: RO water meeting HD standards
- Inlet Pressure: 0.15~0.35MPa
- Inlet Flow: >1600mL/min
- Rinsing Durations:
- Single Dialyzer: 11 min (Standard), 14 min (Intensive)
- Dual Dialyzers: 22 min (Standard), 27 min (Intensive)
- Machine Rinse: 3 min (Single), 4 min (Dual)
- Machine Cleaning Time: 8 min
- Water Consumption: 8L per dialyzer
- Recommended Disinfectants: 12~15% peracetic acid or 100% RenaLin
Printer Specifications
- English: 6x8 dot matrix
- Chinese: 12x12 dot matrix
- Print Rate: 1.5 sec/line
Why Choose GoldHealth Medical?
- Unmatched Quality: Rigorous quality control ensures reliability and performance.
- Exceptional Service: Building long-term partnerships through dedication and expertise.
- Customization Options: Tailor the machine to your brand with OEM services.
- Competitive Pricing: High performance at an unbeatable value.
- Timely Delivery: Orders shipped promptly upon completion.
GoldHealth Medical is committed to empowering healthcare providers with innovative solutions that enhance patient care and operational efficiency. Let us partner with you to elevate your dialysis services to the next level.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Brand Name: GoldHealth Medical
Product Name: Dialyzer Reprocessing Machine
Product Overview
The Dialyzer Reprocessing Machine by GoldHealth Medical is a cutting-edge solution designed to deliver precision, reliability, and efficiency in dialysis care. Engineered for healthcare facilities, research labs, and home use, this machine ensures optimal performance while maintaining the highest standards of safety and hygiene. Its advanced features and user-friendly interface make it an indispensable tool for modern medical environments.
Key Features
- Touch Screen Interface: Intuitive and responsive control for seamless operation.
- Compact Design: Dimensions of 480x430x560mm and a weight of 25kg ensure portability and space efficiency.
- Precision Testing: Volume test range of 0~150mL with a tolerance of ±3% for accurate measurements.
- Adaptable Operating Conditions: Functions effectively in ambient temperatures of 5~40°C and relative humidity of 10~80%.
- Optimized Water Handling: Operates within a water temperature range of 10~30°C and inlet pressure of 0.15~0.35MPa.
Technical Specifications
- Voltage: AC220V
- Instrument Classification: Class I
- Type: Compatible with Dialysis Powder & Dialysis Solution
- Packaging: Secure wooden case with standard export packing
Warranty & After-Sales Support
- Comprehensive Warranty: 1-year coverage for peace of mind.
- Free Spare Parts: Ensures uninterrupted performance and long-term reliability.
Supply Capacity
- Monthly Supply: Up to 50 sets available per month to meet high demand.
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering innovative, high-quality medical solutions that empower healthcare providers and improve patient outcomes. The Dialyzer Reprocessing Machine exemplifies our dedication to precision engineering, user-centric design, and uncompromising quality.
Packaging Details
- Single Package Size: 20x20x20 cm
- Single Gross Weight: 15.000 kg
- Ports: Available for shipment from Guangzhou, Shenzhen, or any port in China.
Elevate your dialysis care with the Dialyzer Reprocessing Machine—where precision meets performance.
