SYH0042 Portable 3Channel Digital ECG
Reference: 1601369809633Household Medical Devices
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Single Channel ECG Machine by GoldHealth Medical
Product Overview
GoldHealth Medical introduces a cutting-edge single-channel ECG machine designed for precision and reliability in diverse medical environments. This device is engineered to deliver exceptional performance, making it an ideal choice for hospitals, clinics, research labs, and home healthcare.
Key Features and Technical Specifications
- Input Mechanism: Floating input with defibrillation protection ensures patient safety during critical procedures.
- Patient Leak Current: Safeguarded at less than 10µA for enhanced protection.
- Sampling Rate: High-fidelity data capture at 1000Hz for accurate waveform analysis.
- A/D Conversion: 12-bit resolution for detailed signal processing.
- Frequency Response: Optimized range of 0.05Hz to 150Hz (-3dB, +0.4dB) for precise ECG readings.
- Common Mode Rejection Ratio (CMRR): Exceeds 60dB, reaching >100dB with an added filter for superior noise reduction.
- Polarization Voltage Endurance: ±300mV for consistent performance under varying conditions.
- Noise Level: Exceptionally low, ensuring clear and reliable signals.
- Display Options: Supports 3/6/12-lead ECG visualization with customizable print modes, sensitivity, paper speed, and filter states.
- Memory Capacity: Built-in storage for up to 1000 cases, enabling efficient data management.
- Power Supply: Versatile AC/DC power options:
- AC: 100V~240V (50/60Hz)
- DC: 7.4V/3500mAh rechargeable lithium battery for uninterrupted mobility.
- Dimensions: Compact design measuring 315mm(L) x 215mm(W) x 77mm(H).
- Classification: Class II medical instrument for assured safety and compliance.
Unique Selling Points
- Advanced Defibrillation Protection: Ensures uninterrupted operation and safeguards both patients and equipment during emergencies.
- High Sampling Rate and Resolution: Delivers unparalleled accuracy in ECG signal acquisition and analysis.
- Extensive Memory Storage: Facilitates seamless case management and retrieval for enhanced workflow efficiency.
- Dual Power Options: Provides flexibility for use in various settings, from clinical environments to remote locations.
- Compact and Portable Design: Combines functionality with portability, making it suitable for diverse applications.
Applications
This ECG machine is tailored for a wide range of users, including hospitals, clinics, research institutions, rehabilitation centers, and home healthcare providers. Its versatility and precision make it indispensable for pathological analysis and diagnostic procedures.
Commitment to Quality
GoldHealth Medical is dedicated to delivering innovative and reliable medical solutions. With over eight years of expertise in the medical equipment industry, we have established partnerships with clients across more than 60 countries. Our rigorous quality assurance processes include pre-production samples and final inspections to ensure every product meets the highest standards.
After-Sales Support
We provide comprehensive online technical support to ensure uninterrupted performance and address any queries or concerns promptly.
Environmental and Safe Packaging
To safeguard your investment, we offer professional, eco-friendly, and efficient packaging solutions tailored to ensure the safe delivery of your equipment.
GoldHealth Medical is committed to advancing healthcare through innovation and excellence. Let us empower your practice with tools that redefine precision and reliability.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: Single Channel ECG Machine
Brand Name: GoldHealth Medical
Product Overview
The Single Channel ECG Machine by GoldHealth Medical is a state-of-the-art diagnostic tool designed for precision and reliability. Engineered to meet the needs of modern healthcare environments, this compact and versatile device delivers exceptional performance for both clinical and home use. With advanced features like 3/6/12-lead ECG display, built-in memory for up to 1000 cases, and a rechargeable lithium battery, it ensures seamless operation in any setting.
Key Features
- Advanced Display Options: Supports 3/6/12-lead ECG with customizable print modes, sensitivity, paper speed, and filter settings.
- Built-In Memory: Stores up to 1000 patient cases, ensuring efficient data management and accessibility.
- Dual Power Supply: Operates on AC (100V~240V, 50/60Hz) or DC (7.4V/3500mAh rechargeable lithium battery), providing flexibility and uninterrupted performance.
- Compact Design: Dimensions of 315mm(L) x 215mm(W) x 77mm(H) make it portable and easy to integrate into any workspace.
- Plug-and-Play Functionality: Simplifies setup and operation, ideal for both professional and home environments.
Technical Specifications
- Instrument Classification: Class II
- Application: Suitable for home use, clinics, hospitals, and research institutions.
- Shelf Life: 1 year
- Atmospheric Pressure: Operates under standard atmospheric conditions.
- Quality Certification: CE-certified for safety and reliability.
Unique Selling Points
- Unmatched Portability: Its lightweight and compact design make it an ideal choice for mobile healthcare providers and remote diagnostics.
- Long-Lasting Battery: The rechargeable lithium battery ensures extended operation without frequent recharging.
- Comprehensive Data Storage: Built-in memory allows for extensive case storage, reducing the need for external devices.
- Global Compatibility: Wide voltage range (100V~240V) ensures reliable performance across different regions.
Warranty and Support
- Warranty: 1-year comprehensive warranty for peace of mind.
- After-Sale Service: Access to online technical support ensures quick resolution of any issues.
GoldHealth Medical’s Single Channel ECG Machine is more than just a diagnostic tool—it’s a reliable partner in delivering accurate and efficient healthcare solutions.
