SYA027 Portable Color Doppler 3D4D
Reference: 1600965761609Medical Ultrasound Instruments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Revolutionizing Ultrasound Technology
Product Overview
GoldHealth Medical presents a cutting-edge Full Digital Color Doppler Ultrasound system, designed for versatility and precision in medical diagnostics. This state-of-the-art device is engineered to meet the needs of diverse medical applications, including abdomen, maternity, urology, superficial tissues, peripheral vascular, small organs, cavities, and interventional procedures. With its advanced imaging capabilities and user-friendly interface, this ultrasound system is ideal for hospitals, clinics, research institutions, and home healthcare.
Key Features and Benefits
- Advanced Imaging Technology: Delivers high-resolution images with lateral resolution ≤ 2mm and longitudinal resolution ≤ 1mm, ensuring unparalleled clarity.
- Versatile Probe Options: Includes convex array, linear array, heart, and cavity probes, with optional pediatric cardiac, transesophageal, laparoscopic, and intraoperative probes.
- Customizable Display: Supports multiple display modes (B/M, B/D, B/CD, etc.) with adjustable M-type and PWD icon sizes for optimal visualization.
- Harmonic Imaging: Equipped with second harmonic imaging and ≥ 2 harmonic function groups for enhanced image quality.
- Dynamic Range: Offers a system dynamic range of ≥ 140dB, enabling detailed imaging at depths of ≥ 240mm.
- Real-Time Processing: Features anatomical M-imaging techniques with 360-degree sampling flexibility and a frame rate of ≥ 120/s.
Technical Specifications
- Frequency Range: 2.0-14MHz
- Probe Specifications:
- Abdomen convex array probe: 2.0-5.0MHz
- Linear array probe: 5-14MHz, scan angle: 60°
- Intracavity convex array probe: 4-8MHz, scanning angle ≥ 135°
- Image Modes: Two-dimensional B-mode, M-mode, pulsed PW, color CFM/power Doppler, and direction energy PDM.
- Measurement and Analysis: Includes general measurements (distance, perimeter, area, etc.) and specialized gynecology/obstetrics software for fetal gestational age, EDC, and weight estimation.
- Color Doppler: Speed dispersion, energy display, and adjustable sample volume (0.5-20mm). Maximum blood flow velocity: PWD ≥ 6m/s, continuous Doppler ≥ 10m/s.
- Display: ≥ 15-inch high-resolution progressive-scan LCD.
- Storage: Built-in hard disk ≥ 160GB, real-time hard drive storage, and DVD recording capabilities.
- Interfaces: PAL-D, USB, RS-232, VCR, RGB, VGA, and more.
Why Choose GoldHealth Medical?
- Unmatched Quality: Our products are trusted by medical professionals worldwide, serving regions such as South America, Southeast Asia, North America, and Africa.
- Comprehensive Support: From video tutorials to real-time online training, we ensure seamless integration and operation.
- Warranty and Service: Enjoy a warranty of 12-60 months with responsive after-sales support, guaranteeing assistance within 8 hours.
- Safety and Reliability: Each device undergoes a one-to-one inspection before delivery, ensuring safety and precision.
Applications
This ultrasound system is designed for a wide range of medical uses, including:
- Abdominal diagnostics
- Maternity and fetal monitoring
- Urological assessments
- Superficial tissue evaluations
- Peripheral vascular studies
- Small organ and cavity examinations
- Interventional screening and therapeutic procedures
Upgradeable System
Future-proof your investment with a system that supports software and hardware upgrades, ensuring long-term usability and adaptability to evolving medical needs.
GoldHealth Medical is committed to delivering innovative, reliable, and affordable ultrasound solutions that empower healthcare providers to deliver exceptional patient care.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents a cutting-edge Doppler Ultrasound Equipment designed to redefine precision and reliability in medical diagnostics.
- Type: Advanced Doppler Ultrasound Equipment
- Display Modes: Multiple professional imaging options including B, B/B, B/M, and M modes for enhanced diagnostic clarity
- Scan Angle: Wide 60-degree field of view for comprehensive imaging
- Probe Array Element: High-density array with ≥ 128 elements, ensuring exceptional image resolution
- Detecting Depth: Penetrates up to ≥ 240mm, enabling deep tissue analysis with remarkable accuracy
- System Dynamic Range: Superior ≥ 140dB dynamic range for unparalleled contrast and detail
Key Features and Certifications:
- Material: Durable, high-grade metal construction for long-lasting performance
- Instrument Classification: Class II medical device, engineered for safety and precision
- Safety Standard: Compliant with GB15979-2002, ensuring rigorous quality benchmarks
- Quality Certification: CE-certified, meeting international standards for medical equipment
Additional Details:
- Power Source: Reliable electrical operation for consistent performance
- Shelf Life: 2-year product longevity, ensuring sustained usability
- Place of Origin: Proudly manufactured in Guangdong, China, combining innovation with expertise
Warranty and Support:
- Warranty: Comprehensive 2-year coverage for peace of mind
- After-Sale Service: Complimentary spare parts provided to minimize downtime and maximize efficiency
GoldHealth Medical’s Doppler Ultrasound Equipment is meticulously crafted to meet the needs of hospitals, clinics, research institutions, and home healthcare providers. With its advanced technology, robust design, and unwavering reliability, this device sets a new standard in medical imaging excellence.
