Super Silent 80 KVA Diesel Generator Set
Reference: 1601242888989Emergency & Clinics Apparatuses
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Introducing the GoldHealth Medical Diesel Generator – Powering Critical Environments with Precision and Reliability
Engineered for demanding medical, research, and care environments, the GoldHealth Medical Diesel Generator combines advanced engineering with exceptional durability. Designed to deliver consistent, low-emission power, this generator is ideal for hospitals, clinics, laboratories, and rehabilitation centers.
Key Features and Specifications
1. Engine: Advanced Performance and Efficiency
- Direct Injection + Turbocharged Intercooling Technology: Ensures optimal air intake, complete combustion, and reduced fuel consumption.
- Mechanical Fuel Injection System: Guarantees stable operation, precise transient speed regulation, and robust load-handling capabilities.
- High-Quality Alloy Cast Iron Cylinder Block: Features a reinforced rib structure for enhanced strength and reliability.
- Proprietary Carbon Scraping Self-Cleaning Technology: Minimizes oil consumption and extends engine life.
- Electric Pre-Oil Supply System: Protects moving parts during startup, enhancing durability.
- One Cylinder, One Head Design: Simplifies maintenance and ensures long-term reliability.
- Performance Standards: Meets G3 performance level requirements (GB2820), with a large power reserve and extended service life.
2. Generator: Stable and Precise Power Output
- 2/3 Winding Pitch: Suppresses excessive neutral current for smoother operation.
- Maintenance-Free Sealed Bearings: Ensures long-lasting performance with minimal upkeep.
- IP23 Protection Level: Safeguards against environmental factors.
- EVR308 AVR and Permanent Magnet Excitation: Delivers ±0.5% voltage regulation for stable output.
- Output Specifications: 400/230V, 3-phase, 50Hz, 1500 RPM.
3. Cooling System: Superior Heat Dissipation
- Enhanced Radiator Design: Meets heat dissipation needs in ambient temperatures up to 50°C.
- Corrosion-Resistant Materials: Adapts to various water qualities and ensures long-term reliability.
- Compact and Lightweight: Easy to disassemble and maintain, with a safety shield for full protection.
4. Control System: Intelligent and User-Friendly
- Microprocessor-Based Core: Allows flexible parameter settings via intuitive panel buttons.
- Comprehensive Monitoring: Displays battery voltage, engine speed, water temperature, oil pressure, and runtime.
- Programmable Throttle: Supports multiple sensor types for oil pressure and temperature.
- DIN72 Standard Housing: Ensures secure connections with pin-type locking terminals for easy maintenance.
5. Chassis Structure: Durable and Silent Design
- Human-Centric Design: Compact, lightweight, and aesthetically pleasing with stable performance.
- Silent Enclosure: Made from corrosion-resistant cold-rolled steel, ensuring rainproof and moisture-proof operation.
- Noise Reduction: Meets ISO3744 and GB2820-90 standards, reducing noise to 65-75 dB(A).
- Advanced Ventilation: Prevents heat buildup and ensures optimal operating temperatures.
- Shock Absorption: Balances operation and minimizes vibrations.
6. Accessories: Comprehensive and Ready-to-Use
- Includes floating charging power supply, circuit breaker, oil-resistant pipes, starting wires, filters, mufflers, and specialized tools.
Technical Parameters
- Engine Type: Four-stroke, water-cooled, in-line, direct injection, dry cylinder liner.
- Rated Power/Speed: 72 kW / 1500 RPM.
- Intake Type: Turbocharged.
- Number of Cylinders: 4.
- Bore × Stroke: 105 × 135 mm.
- Idle Speed: 600 ± 50 RPM.
- Exhaust Temperature: ≤550°C.
- Fuel Consumption Rate: ≤193 g/kW·h.
- Displacement: 4.726 L.
- Cooling Method: Closed water cooling.
- Lubrication Method: Pressure and splash compound.
- Starting Method: Electric start.
- Oil Pressure: 580-648 kPa (idle ≥100 kPa).
- Fuel Supply Advance Angle: 18° ± 1°.
- Minimum Stable Operating Speed: 945 RPM.
- Tilt Angles: Long-term (10° vertical / 15° horizontal), short-term (30° vertical / 30° horizontal).
Why Choose GoldHealth Medical?
- Unmatched Reliability: Built to withstand diverse environmental conditions with minimal maintenance.
- **Low Noise,
