GoldHealth Medical Portable Ultrasound System

Product Overview

GoldHealth Medical introduces a revolutionary portable ultrasound system designed for versatility and precision. This innovative device seamlessly transitions between a professional ultrasound system and a fully functional laptop, empowering healthcare providers with unmatched flexibility.

Key Features

• Lightweight Design: Weighing less than 5 kg, it is effortlessly portable, making it ideal for on-the-go medical professionals.
• Extended Battery Life: Equipped with a built-in battery offering over 3 hours of continuous operation, enabling use in remote locations without access to power sources.
• Large Display: Features a 15-inch LED display with a 175-degree viewing angle for superior image clarity.
• Advanced Imaging: Supports multiple imaging modes including 2D and free-hand 3D, ensuring detailed visualization.
• Comprehensive Connectivity: Includes 2 USB ports, Discom 3.0 port, and projector port for seamless integration with archives, PACS, and training environments.

Technical Specifications

• Display: Full digital, 15-inch LED with 175-degree viewing angle
• Probes:
• 3.5MHz R60/R50 convex probe (2.0MHz to 5.0MHz)
• 7.5MHz L40 linear probe (5.0MHz to 10.0MHz)
• 6.5MHz R10/R13 transvaginal probe (5.0MHz to 8.0MHz)
• 3.5MHz R20 cardiac probe (2.0MHz to 5.0MHz)
• Beam Forming: DBF, RDA, DRA, DRF, DFS with dynamic frequency scanning from 2.0 to 12.0MHz
• Display Modes: B, 2B, 4B, B/M, M
• Dynamic Range: ≥100dB with 4-step switching functions
• Image Processing: Controllable frame correlation, gamma correction, edge enhancement, image smoothing, denoising, automatic gain adjustment, and more
• Image Magnification: Stepless magnification and dynamic real-time PIP local zoom functions
• Cine Loop: 512 frame auto/manual cine loop with multi-screen capabilities
• Image Management: Comprehensive system for archiving, browsing, comparing, saving, printing, and transferring images
• Measurement and Calculation: Automatic calculations for perimeter, area, body surface area, volume, and more
• Assist Tools: Puncture guide, histogram, sectional drawing
• Menu Interface: Real-time online support, navigation clues, image presets, and one-key optimization
• Body Marks: Multi-tens options
• Patient Database: Save, search, and manage all patient data
• Specialty Applications: General, OB/GYN, vascular, cardiology, urinary, small organs, etc.
• 3D/4D Software: Optional 4D software for advanced imaging
• Extended Ports: VGA, S-Video, TV video port, USB2.0, 2G saving card, RJ-45 network port

Unique Selling Points

• Versatility: Functions as both an ultrasound system and a laptop, enhancing its utility in diverse medical settings.
• Precision and Clarity: Advanced imaging technologies and a large, high-resolution display ensure accurate diagnostics.
• Comprehensive Connectivity: Multiple ports and compatibility with various printers and recorders facilitate seamless data management.
• Extensive Measurement Capabilities: Automated measurement tools and a robust database system streamline clinical workflows.

Applications

• General Imaging: Detailed visualization for a wide range of medical assessments.
• OB/GYN: Comprehensive tools for obstetric and gynecological evaluations, including fetal growth tracking and physiological grading.
• Cardiology: Advanced cardiac measurements and calculations for precise diagnostics.
• Small Organs and Urology: Specialized tools for thyroid, hip joint, prostate, and other small organ assessments.

GoldHealth Medical’s portable ultrasound system is designed to meet the needs of modern healthcare providers, offering unparalleled flexibility, precision, and ease of use.
