SRC1201 Portable 12Lead ECG Machine
Reference: 1600924342773Pathological Analysis Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Portable Electrocardiograph
Experience precision and portability with the GoldHealth Medical Portable Electrocardiograph, designed to meet the needs of modern healthcare professionals. This advanced 12-lead ECG machine features a sleek design and cutting-edge technology, making it an indispensable tool for accurate cardiac diagnostics.
Key Features:
- 7-inch High-Resolution Touch Screen: A vibrant, intuitive interface ensures effortless navigation and precise data visualization.
- Full Alphanumeric Keyboard with Shortcut Keys: Streamline operations with a responsive keyboard designed for maximum efficiency.
- Simultaneous 12-Lead ECG Acquisition and Display: Capture comprehensive cardiac data in real-time for thorough analysis.
- Automatic ECG Measurements and Interpretation: Advanced algorithms provide reliable diagnostic support, saving time and enhancing accuracy.
- Internal Storage for Up to 1000 Cases: Effortlessly store, review, and analyze patient data for better clinical decision-making.
- Built-in Rechargeable Lithium Battery: Enjoy extended operation times with a high-capacity battery, ensuring uninterrupted performance.
- Seamless Data Transfer via USB: Easily transmit ECG data to a PC and manage reports using dedicated playback software.
Technical Specifications:
- Lead Configuration: Standard 12 leads
- Acquisition Mode: Simultaneous 12-lead acquisition
- Sampling Rate: 1000Hz
- A/D Converter: 24 bits
- Frequency Response: 0.05β160Hz (-3dB)
- Operation Modes: Manual, Auto, Rhythm (1 channel, 1 minute)
- Filters:
- AC Filter: 50Hz/60Hz
- EMG Filter: 25Hz/35Hz/45Hz/75Hz/100Hz/150Hz
- DFT Filter: 0.05Hz/0.5Hz
- CMRR: β₯100dB (with AC filter)
- Input Mode: Floating with defibrillation protection
- Input Impedance: β₯50MΞ© (at 10Hz)
- Input Circuit Current: β€0.05ΞΌA
- Input Dynamic Range: Β±10mVp-p
- Patient Leak Current: <10ΞΌA
- Calibration Voltage: 1mVΒ±2%
- Polarizing Voltage: β₯Β±300mV
- Time Constant: β₯3.2s
- Paper Specification: 210mm (W) x 30m (L)
- Recording Mode: Thermal printing system
- Noise Level: <15ΞΌVp-p
- Memory Capacity: 1000 cases
- Wave Gain/Sensitivity: 2.5mm/mV, 5mm/mV, 10mm/mV, 20mm/mV (standard: 10mm/mV)
- Wave/Paper Speed: 12.5mm/s, 25mm/s, 50mm/s (Β±3%)
- Power Supply:
- AC: 100β240V, 50/60Hz
- DC: 14.4V, 2500mAh, 36.00Wh (built-in lithium battery)
Standard Configuration:
- Main unit
- Patient cable
- Limb electrodes (set of 4)
- Chest electrodes (set of 6)
- Power cable
- Recording paper (210mm x 30m)
- Paper axis
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering innovative, reliable, and user-friendly medical devices. Our portable electrocardiograph combines precision engineering with a focus on usability, ensuring exceptional performance in any clinical setting. Whether you're in a hospital, clinic, or conducting home visits, this device empowers you to deliver superior patient care with confidence.
Unique Selling Points:
- Compact and Lightweight Design: Ideal for portability without compromising functionality.
- Advanced Diagnostic Capabilities: Automatic measurements and interpretation enhance diagnostic accuracy.
- Robust Storage and Connectivity: Store extensive patient data and seamlessly integrate with digital systems.
- Long-Lasting Battery Life: Reliable performance during extended use, even in remote locations.
GoldHealth Medical is dedicated to supporting healthcare professionals with tools that redefine standards in cardiac care. Elevate your practice with a device that combines precision, portability, and performance.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
GoldHealth Medical proudly presents the ECG Machine, a cutting-edge solution designed for precision and reliability in medical diagnostics. Engineered to meet the demands of modern healthcare, this Class II medical instrument is ideal for hospitals, clinics, laboratories, and home healthcare environments. With its advanced functionality and user-centric design, it delivers exceptional performance for early detection and accurate pathological analysis.
Key Features and Specifications
- Brand Name: GoldHealth Medical
- Product Name: ECG Machine
- Application: Medical Healthcare
- Functionality: Early detection of cardiovascular conditions through precise ECG readings
- Specimen Compatibility: Serum
- Format: Cassette-based system for seamless integration into workflows
- Power Source: Electricity
- Instrument Classification: Class II
Quality Assurance and Certifications
- Certified by CE and ISO standards, ensuring compliance with global healthcare regulations
- Backed by a 1-Year Warranty for peace of mind
- Supported by online technical support for uninterrupted service
Technical Details
- Shelf Life: 1 year
- Minimum Order Quantity (MOQ): 1 PCS
- Packaging: Securely packaged in a durable carton
- Single package size: 50 x 50 x 50 cm
- Single gross weight: 10.000 kg
Why Choose GoldHealth Medical's ECG Machine?
- Precision Engineering: Delivers accurate and reliable results for informed clinical decisions
- Versatile Application: Suitable for hospitals, research institutions, rehabilitation centers, and home healthcare
- User-Friendly Design: Simplifies operation while maintaining professional-grade performance
- Global Standards: Meets rigorous quality benchmarks for safety and efficacy
GoldHealth Medical is committed to empowering healthcare providers with innovative tools that enhance patient outcomes. The ECG Machine exemplifies our dedication to excellence in medical technology.
