Portable Veterinary XRay Machine Prices Accessories
Reference: 1600513027791Radiology Equipment & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical presents a cutting-edge X-ray solution designed for precision, reliability, and versatility in medical imaging. Engineered to meet the demands of modern healthcare environments, this system delivers exceptional performance with advanced features tailored for hospitals, clinics, research institutions, and more.
Key Features and Specifications
- Power and Performance
- Voltage: AC220V ± 22V, Frequency: 50/60 Hz ±1Hz
- Input Power Capacity: ≥5kVA
- Inner Resistance: ≤0.5Ω
- Maximum Output Power: 110kV × 36mA = 4kW
Nominal Power: 100kV, 40mA, 0.1s, 4kW
Advanced Adjustability
- Frequency: ≥40kHz
- KV Range: 40kV–110kV (step adjustment of 1 kV)
- mA Range: 36mA–70mA
- mAs Range: 1mAs–200mAs (shifted adjustment)
S Range: 0.04s–3.2s
X-Ray Tube Specifications
- Focus: 0.6/1.5mm
Anode Heating Capacity: 76kHU
Compact and Portable Design
- Dimensions: 290 × 260 × 230 mm
- Weight: 18.8kg
Included Accessories
- Remote control
- Aluminum case
Why Choose GoldHealth Medical?
- Precision Engineering: Achieve unparalleled accuracy with step-by-step KV adjustments and a wide mA range, ensuring optimal imaging for diverse diagnostic needs.
- High-Frequency Technology: With a frequency of ≥40kHz, this system minimizes noise and enhances image clarity, setting a new standard in diagnostic imaging.
- Compact and Lightweight: Designed for portability without compromising performance, making it ideal for both stationary and mobile applications.
- Durability and Reliability: Built with robust materials and advanced thermal management, ensuring consistent performance under demanding conditions.
GoldHealth Medical’s X-ray system is the ultimate choice for professionals seeking innovation, precision, and efficiency in medical imaging. Transform your diagnostic capabilities with a solution that combines cutting-edge technology with user-centric design.
Experience the future of medical imaging with GoldHealth Medical.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Portable X-ray System by GoldHealth Medical
Product Overview
The Portable X-ray System from GoldHealth Medical is a cutting-edge solution designed for precision, reliability, and versatility in medical imaging. Engineered to meet the demands of modern healthcare environments, this system is ideal for hospitals, clinics, research labs, and even home healthcare settings. Its compact design and advanced functionality make it an indispensable tool for accurate diagnostics.Key Features and Specifications
- Power Source: Operates on AC220V ± 22V, ensuring consistent performance across diverse settings.
- kV Range: Adjustable from 40kV to 110kV for optimal imaging adaptability.
- mA Range: Supports 20mA to 100mA, providing flexibility for various diagnostic needs.
- mAs Range: Precise control with a range of 0.2mAs to 200mAs.
- Working Frequency: High-efficiency operation at ≥40kHz.
- Power: Robust 5kW output for reliable performance.
- Exposure Time: Adjustable from 0.01 seconds to 4 seconds for accurate imaging.
- Anode Heat Storage: Advanced thermal management with 56KHU capacity.
Display: Equipped with a 10.4-inch interface for clear and intuitive operation.
Design and Build Quality
- Constructed with durable materials, including high-grade metal and premium plastic components.
Compact and portable design ensures ease of use in confined spaces.
Instrument Classification: Class II medical device, ensuring safety and compliance with industry standards.
Packaging and Delivery
- Package Dimensions: 68 x 50 x 40 cm.
- Gross Weight: 37.000 kg.
Standard packaging ensures secure transportation.
Supply and Support
- Supply Capacity: Up to 10,000 units per month, ensuring availability for large-scale orders.
- Warranty: Comprehensive 1-year warranty for peace of mind.
After-Sale Service: Access to online technical support for seamless operation and troubleshooting.
Applications
Designed for a wide range of medical environments, including hospitals, clinics, rehabilitation centers, and research laboratories. Its portability and precision make it suitable for both professional and home healthcare use.
GoldHealth Medical’s Portable X-ray System redefines diagnostic imaging with its innovative design, advanced features, and unwavering reliability. Elevate your medical practice with a system built to deliver exceptional results.
