Portable 12Channel ECG Machine with Large Screen and Interpretation
Reference: 1601377547761Pathological Analysis Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical presents a cutting-edge Medical Digital Portable ECG Machine designed to redefine precision and efficiency in cardiac diagnostics.
Product Highlights
- Revolutionary Design: Modern, lightweight, and compact, this device is engineered for portability without compromising performance.
- Advanced 12-Lead Acquisition: Simultaneous capture of all 12 leads with a full-screen display of ECG waveforms for unparalleled clarity.
- Intuitive Interface: A 10.2-inch color touch-screen supports both push-button and touch operation, ensuring seamless usability.
- Smart Diagnostic Assistance: Equipped with auto-analysis and auto-diagnostic features to reduce physician workload and enhance diagnostic accuracy.
- Precision Filters: Incorporates ADS, HUM, and EMG filters for optimal signal clarity, even in challenging environments.
- High-Resolution Thermal Printing: Delivers sharp, detailed outputs with a thermal-array printer (8 dots/mm) and synchronization printing on 215mm thermal paper.
- Extended Battery Life: Powered by a built-in rechargeable lithium-ion battery (14.8V/4400mAh), offering reliable performance during extended use.
Technical Specifications
- Frequency Response: Up to 150Hz for accurate waveform representation.
- Baseline Adjustment: Automatic baseline correction ensures optimal recording quality.
- CMRR: ≥ 100dB with AC filter for superior noise rejection.
- Calibrating Voltage: 1mV ± 3% for precise calibration.
- Input Circuit: Floating design with ≤ 0.1µA current for enhanced safety.
- Time Constant: > 3.2s for stable signal processing.
- Resolution: 12-bit/1000Hz for high-definition data capture.
- Operation Modes: Manual and Auto modes for flexible use.
- Noise Level: ≤ 15µVp-p for minimal interference.
- Filter Options: AC, EMG, and Anti-Drift System for comprehensive signal optimization.
- Paper Speed: Adjustable at 12.5, 25, and 50mm/s (± 3%) for tailored outputs.
- Input Impedance: > 50MΩ for reliable signal acquisition.
- Sensitivity: Adjustable at 5, 10, and 20mm/mV.
- Patient Safety: Current leakage < 10µA ensures patient protection.
- Recorder: High-resolution thermal printer for consistent, clear results.
- Battery: Built-in rechargeable Li-ion battery (14.8V/4000mAh) for uninterrupted performance.
- Power Supply: Adaptable to 100-240V, 50/60Hz AC power.
Key Features
- Waveform Freezing: Instantly freeze waveforms for detailed analysis.
- Historical Data Review: Access and print past ECG records and patient information effortlessly.
- Lead and Paper Detection: Alerts for lead disconnection and paper shortages ensure uninterrupted operation.
Why Choose GoldHealth Medical?
GoldHealth Medical’s ECG machine is designed to empower healthcare professionals with advanced tools that streamline workflows and deliver precise diagnostics. Its combination of portability, intuitive controls, and intelligent features makes it an indispensable asset for hospitals, clinics, research labs, and home care settings.
Applications
- Hospitals and Clinics
- Research Institutions
- Rehabilitation Centers
- Home Healthcare
- Emergency Medical Services
This device is more than just an ECG machine—it’s a gateway to smarter, faster, and more reliable cardiac care.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name:
Medical Digital Portable EKG Electrocardiogram by GoldHealth Medical
Key Features and Benefits:
- Precision Redefined: Equipped with a 12-bit resolution and a sampling rate of 1000Hz, this portable EKG delivers highly accurate and detailed electrocardiogram readings, ensuring reliable diagnostics for healthcare professionals.
- Advanced Filtering Technology: Features an Anti-Drift System, AC filter, EMG filter, and drift filter to eliminate noise and interference, providing crystal-clear signals even in challenging environments.
- Flexible Operation Modes: Choose between Manual and Auto modes to suit your workflow, offering both control and convenience during examinations.
- Robust Input Circuit: Floating input circuit design ensures patient safety and minimizes signal distortion, with a voltage tolerance of ±500mV for enhanced reliability.
- Compact and Portable Design: Lightweight at just 4kg and housed in a compact package (442mm x 207mm x 388mm), this device is perfect for use in clinics, hospitals, laboratories, and even home care settings.
Technical Specifications:
- Instrument Classification: Class II medical device
- Power Source: Electricity
- Time Constant: > 3.2 seconds
- Resolution: 12-bit / 1000Hz
- Voltage Tolerance: ±500mV
- Shelf Life: 1 year
- Package Dimensions: 45cm x 21cm x 39cm
- Gross Weight: 4.000 kg
Quality Assurance:
- Backed by GoldHealth Medical’s commitment to excellence, this EKG device is CE-certified, guaranteeing compliance with international safety and performance standards.
After-Sale Support:
- Enjoy peace of mind with a 1-year warranty and access to online technical support, ensuring uninterrupted performance and assistance whenever you need it.
Ideal For:
Hospitals, clinics, research institutions, rehabilitation centers, and home healthcare providers seeking a dependable, portable, and high-performance EKG solution.
GoldHealth Medical: Empowering healthcare professionals with cutting-edge diagnostic tools designed to elevate patient care.
