Ophthalmic OCT Scanner Pro
Reference: 1600951589080Medical Optical Instruments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Revolutionizing Eye Care with Precision and Simplicity
GoldHealth Medical presents an advanced Spectral Domain OCT system, engineered to deliver unparalleled precision and ease of use for eye care professionals. Designed with cutting-edge technology, this device redefines optical coherence tomography with its compact design and powerful internal computing capabilities.
Key Features
- Compact All-in-One Design: The entire system is housed within a sleek, self-contained unit. No external computer is required—simply plug in the power cable, and you’re ready to begin.
- Integrated Computing Power: Equipped with an internal PC for seamless data acquisition and processing. Data can be transferred via Ethernet or external hard drive, with ports available for connecting peripherals like keyboards or printers.
- Effortless Installation: Minimal setup and no complex connections. Its compact form factor fits effortlessly into any workspace, even in limited spaces.
Technical Specifications
- Axial Resolution: ≤ 6 µm (in tissue)
- Transverse Resolution: ≤ 20 µm (in tissue)
- Scan Depth: ≥ 2.5 mm (in air)
- Scan Range: ≥ 6 mm
- Scan Speed: ≥ 24,000 A-scans/sec, up to 36,000 A-scans/sec
- Scan Modes: 30, including Raster, Circle, Fundus image, and OCT en face
- Focus Adjustment: -150 to +150
- Pupil Diameter: ≥ 3 mm
- OCT Light Source: 840 nm SLD
- Optical Power: 750 µW (at cornea)
- Operation: 13.3” touch screen with optional external mouse or keyboard
- Power Supply: 100-240 V, 50/60 Hz
- Dimensions: 497 mm × 395 mm × 490 mm (L× W × H)
- Weight: 34 kg (75 lbs)
Why GoldHealth Medical Stands Out
GoldHealth Medical combines over a decade of expertise in the medical device industry with a commitment to delivering high-quality, affordable solutions. Our mission is to empower healthcare providers in developing regions and underserved areas with advanced medical technologies.
- Proven Track Record: Successfully completed projects funded by global organizations such as the World Bank, WHO, and Rotary Club.
- Comprehensive Expertise: A professional team with rich experience in medical equipment and project management.
- Customization Options: Tailored solutions through OEM/ODM services to meet unique client needs.
GoldHealth Medical’s OCT system is more than just a diagnostic tool—it’s a gateway to enhanced patient care, streamlined workflows, and superior outcomes.
Applications
Ideal for hospitals, clinics, research institutions, and rehabilitation centers, this OCT system supports a wide range of applications, from routine diagnostics to advanced research. Its versatility makes it equally suitable for specialized labs and home healthcare environments.
Experience the future of eye care with GoldHealth Medical’s OCT technology—where precision meets simplicity.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: OCT Machine by GoldHealth Medical
Type: Ophthalmic Optical Equipment
Key Features and Benefits
- Advanced Imaging Technology: Utilizes Spectral Domain OCT for unparalleled precision in capturing detailed cross-sectional images of the retina.
- Dual Imaging Capability: Combines OCT en face and fundus imaging for comprehensive diagnostic insights.
- Wide Focus Adjustment Range: Adjustable from -15D to +15D, accommodating diverse patient needs with ease.
- Optimized Light Source: Equipped with an 840nm SLD light source for enhanced clarity and minimal patient discomfort.
- Versatile Applications: Ideal for hospitals, clinics, research institutions, and rehabilitation centers, ensuring adaptability across medical environments.
Technical Specifications
- Instrument Classification: Class II
- Power Source: Electric (AC100-240V, 50/60Hz)
- Shelf Life: 3 years
- Materials Used: High-grade acrylic, metal, plastic, and steel for durability and reliability.
- Safety Standard Compliance: Meets GB/T18830-2009 requirements.
- Quality Certifications: CE Approved
Packaging and Delivery Details
- Packaging Options: Carton box, wooden case, or customized solutions for secure transportation.
- Single Package Dimensions: 40 x 50 x 60 cm
- Single Gross Weight: 30.000 kg
- Ports of Delivery: Shenzhen, Beijing, Shanghai, Nanjing, Guangzhou
Support and Warranty
- Warranty Period: Over 5 years, ensuring long-term reliability and performance.
- After-Sales Service: Comprehensive online technical support tailored to meet your needs.
- Customization Options: OEM services available to align with specific requirements.
GoldHealth Medical’s OCT Machine is engineered to deliver exceptional accuracy, durability, and ease of use, empowering healthcare professionals with cutting-edge diagnostic tools.
