Multiparameter Touch Screen Patient Monitor for Human Vital Signs Monitoring
Reference: 1601344849798Examination Therapy Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Advanced Patient Monitoring Solution
GoldHealth Medical presents a cutting-edge patient monitor designed to deliver precision, reliability, and ease of use in diverse medical environments. Engineered with advanced technology and user-centric design, this device is the ideal choice for hospitals, clinics, research institutions, and home care.
Key Features
- Intuitive Touch-Screen Interface: Simplifies operation with a responsive and user-friendly design.
- High-Resolution Display: A 12.1-inch color TFT screen ensures clarity and precision in visualizing patient data.
- Seamless Connectivity: USB interfaces enable effortless software updates and efficient data transfer.
- Central Monitoring Integration: Fully compatible with Central Monitoring Systems (CMS) for enhanced workflow.
- Versatile Operating Modes: Three distinct modes—Monitoring, Surgery, and Diagnosis—tailored to specific clinical needs.
- Customizable Display Options: Multiple display modes, including Standard Interface, Large Font, ECG Full Display, OXY, Trend Table, and BP Trend, adapt to various applications.
- Extended Battery Life: Built-in high-capacity battery supports up to 3 hours of continuous operation, ensuring uninterrupted monitoring.
- External Display Support: VGA output allows connection to external monitors for enhanced visibility.
Monitoring Parameters
Standard Parameters
- ECG: Comprehensive 5-lead monitoring with advanced ST measurement and diagnostic bandwidth.
- RESP: Impedance-based respiratory rate monitoring for adults, pediatrics, and neonates.
- TEMP: Precise temperature measurement with a range of 0°C to 50°C.
- NIBP: Oscillometric blood pressure monitoring with manual, auto, and STAT modes.
- SpO2: Accurate oxygen saturation and pulse rate tracking.
- PR: Reliable pulse rate monitoring with high resolution.
Optional Parameters
- Built-in recorder (printer)
- Dual invasive blood pressure (IBP)
- End-tidal CO2 (EtCO2) monitoring
- 12-lead ECG
- Nellcor SpO2 integration
- SunTech NIBP compatibility
Standard Configuration
- Main Unit
- 5-lead ECG cable
- Disposable ECG electrodes (5 pieces)
- Adult SpO2 probe
- Adult NIBP cuff
- NIBP extension tube
- Temperature probe
- Power cable
- User manual
- Fuses (3 pieces)
Technical Specifications
ECG
- Lead Modes: 5 leads (I, II, III, aVR, aVL, aVF, V)
- Gain Settings: 2.5mm/mV, 5.0mm/mV, 10mm/mV, 20mm/mV
- Heart Rate Range: 15-300 BPM (adult), 15-350 BPM (neonatal)
- ST Measurement: -2.0~+2.0 mV with ±0.02mV or ±10% accuracy
- Sweep Speeds: 12.5 mm/s, 25 mm/s, 50 mm/s
- Bandwidth: Diagnostic (0.05~130 Hz), Monitor (0.5~40 Hz), Surgery (1~20 Hz)
SpO2
- Measuring Range: 0~100%
- Accuracy: ±2% (70%~100% range)
- Pulse Rate: 20-250 BPM with ±3 BPM accuracy
TEMP
- Range: 0~50°C
- Accuracy: ±0.1°C
RESP
- Measurement Range: Adult (10~120 BrPM), Neonatal/Pediatric (7~150 BrPM)
- Accuracy: ±2 BrPM
NIBP
- Modes: Manual, Auto, STAT
- Accuracy: ±5 mmHg
- Measurement Ranges:
- Adult: SYS 40~280 mmHg, DIA 10~225 mmHg, MEAN 20~240 mmHg
- Pediatric: SYS 40~220 mmHg, DIA 10~160 mmHg, MEAN 20~170 mmHg
- Neonatal: SYS 40~135 mmHg, DIA 10~100 mmHg, MEAN 20~110 mmHg
Why Choose GoldHealth Medical?
GoldHealth Medical’s patient monitor stands out with its advanced engineering, versatile functionality, and commitment to precision.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical: Revolutionizing Patient Monitoring with Precision and Reliability
- Instrument Classification: Class II medical device, engineered for accuracy and safety in diverse healthcare environments.
- Place of Origin: Proudly designed and manufactured in Guangdong, China, adhering to the highest global quality standards.
- Power Source: Electric-powered with a built-in high-capacity battery, ensuring uninterrupted performance for up to 3 hours during critical procedures or transport.
- Shelf Life: Reliable functionality assured for 1 year from the date of production.
- Quality Certification: CE-certified, guaranteeing compliance with stringent international safety and performance benchmarks.
Standard Parameters
- ECG: Advanced 5-lead ECG monitoring for comprehensive cardiac assessment.
- RESP: Precise respiratory rate measurement with a range of 10–120 BrPM for adults.
- TEMP: Temperature monitoring and alarm range of 0–50°C, ensuring accurate thermal regulation tracking.
- NIBP: Utilizes oscillometric technology for non-invasive blood pressure measurement, delivering consistent and reliable readings.
- SpO2: Measures oxygen saturation levels across a 0–100% range, critical for assessing respiratory health.
- PR: Real-time pulse rate monitoring for immediate insights into cardiovascular status.
Display and Interface
- Touch Screen: A 12.1-inch high-resolution color TFT display provides crystal-clear visualization of patient data, enhancing usability in fast-paced clinical settings.
Optional Parameters
- Central Monitoring System: Seamlessly integrates with centralized systems for enhanced oversight in multi-patient environments.
- Dual IBP: Offers dual invasive blood pressure monitoring for advanced hemodynamic assessment.
- EtCO2: Capnography capabilities for precise end-tidal carbon dioxide monitoring during anesthesia and critical care.
- 12-Lead ECG: Expands diagnostic capabilities with comprehensive 12-lead ECG functionality.
Working Modes
- Monitoring Mode: Continuous tracking of vital signs for general patient care.
- Surgery Mode: Optimized for intraoperative use, ensuring precision during surgical procedures.
- Diagnosis Mode: Tailored for detailed diagnostic evaluations, supporting clinical decision-making.
Warranty and Support
- Warranty: Backed by a 1-year warranty, reflecting our confidence in product durability and performance.
- After-Sale Service: Access to online technical support, ensuring prompt resolution of queries and uninterrupted device operation.
GoldHealth Medical’s patient monitoring solution combines cutting-edge technology with user-centric design, empowering healthcare professionals to deliver exceptional care with confidence.
