MT MEDICAL 64Slice Vet CT Scanner
Reference: 1601216827132Medical MRI Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical High-Resolution CT Scanner
Revolutionize diagnostic imaging with GoldHealth Medical's advanced 64-slice CT scanner, designed to deliver unparalleled precision and versatility for a wide range of medical applications.
Product Highlights
- Flexible Configurations: Choose between two distinct hardware setups, allowing seamless adaptation to varying budgets without compromising performance.
- Optimized Workflow: A robust hardware platform enhances patient throughput and boosts operational efficiency, ensuring faster results with minimal downtime.
- Intuitive Interface: A user-guided interface combined with auto-positioning presets simplifies procedures from routine scans of the head, chest, and abdomen to intricate cardiac imaging.
- Superior Image Quality: Achieve exceptional clarity with high-resolution imaging (22lp/cm@0%MTF, 1024x1024), empowering clinicians with greater diagnostic confidence.
- Expanded Clinical Applications: The 76cm gantry design supports tumor biopsy and simulation, significantly broadening the scope of potential clinical uses.
Product Specifications
Power Requirements
- Input Voltage: Single phase AC220V
- Supply Frequency: 50Hz
- Power Capacity: Not less than 3.5 kVA
Mechanical Specifications
- Bed Size: Length: 1850mm, Width: 550mm, Height: 730mm (±5% deviation)
- Scanning Frame Size: Length: 1670mm, Width: 810mm, Height: 1600mm (±5% deviation)
- Bed Surface Translation Range: 0–800mm (±5% deviation)
- Bed Lifting Range: 0–150mm (±5% deviation)
- Bearing Capacity: 50kg
Electrical Power
- Maximum Pulse Fluoroscopic Output: 1.875kW (15mA, 125kV, 10s)
- Maximum Continuous Fluoroscopic Output: 1.5kW (12mA, 125kV, 20s)
- Standard Pulse Fluoroscopy Output: 1.6kW (16mA, 100kV, 10s)
- Maximum Continuous Fluoroscopic Output: 1.4kW (14mA, 100kV, 20s)
Loading Factors and Control
- Tube Voltage: 50kV–125kV (adjustable in 1kV steps, ≤±10% deviation)
- Tube Current: 1mA–16mA (adjustable in 1mA steps, accuracy ±1mA)
- Loading Time: 24s (based on external trigger loading time)
Imaging Performance
- Imaging Size: 307.2mm × 245.7mm
- Spatial Resolution: ≥1.7lp/mm
- Imaging Time: ≤40s
Environmental Requirements
- Operating Conditions:
- Ambient Temperature: 10°C–40°C
- Relative Humidity: 30%–75%
- Atmospheric Pressure: 70kPa–106kPa
- Transportation and Storage:
- Ambient Temperature: -20°C–55°C
- Relative Humidity: 30%–93%
- Atmospheric Pressure: 70kPa–106kPa
Advanced Imaging Capabilities
- Coronary CTA Clinical Case: Achieve precise imaging even with challenging cases (e.g., heart rate: 70bpm with premature beats). Parameters: 120kVp, 620mAs, 0.39s rotation speed, scan range 125mm, scan time 11s, slice thickness 0.625mm.
- VR Skeletal Reconstruction: Generate 3D, intuitive representations of bone structures, invaluable for orthopedic and plastic surgery planning, especially in complex anatomical scenarios.
- Curved Planar Reformation (CPR): Utilize this post-processing tool to create panoramic 2D images from 3D volumetric data, ideal for dental evaluations and visualizing curved anatomical structures.
GoldHealth Medical’s CT scanner is engineered to meet the demands of modern healthcare facilities, offering precision, versatility, and reliability for enhanced patient care.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
Introducing the GoldHealth Medical 64-Slice CT Scanner, a cutting-edge diagnostic solution designed to deliver unparalleled precision and efficiency. Engineered for modern healthcare environments, this advanced imaging system is ideal for hospitals, clinics, research institutions, and rehabilitation centers. With its sleek design and robust performance, it sets a new benchmark in medical imaging technology.
Key Features and Specifications
- Imaging Excellence: Achieve exceptional clarity with a slice thickness of just 0.625mm, enabling highly detailed and accurate diagnostics.
- Powerful Performance: Equipped with an 80kW generator and an 8.0MHU tube, ensuring consistent and reliable operation even during demanding scans.
- Speed and Precision: A rotation speed of 0.39 seconds and a scan time of 11 seconds allow for rapid imaging without compromising quality.
- Wide Scan Range: Cover up to 125mm in a single scan, making it versatile for a variety of clinical applications.
- Durable Construction: Built with high-quality metal materials, ensuring long-lasting durability and stability.
Certifications and Compliance
- Certified with CE, guaranteeing adherence to international safety and quality standards.
- Classified as a Class I medical instrument, reflecting its reliability and safety for professional use.
Operational Details
- Electric Power Source: Designed for seamless integration into modern healthcare facilities.
- Shelf Life: Components are engineered to maintain optimal performance for up to 3 years.
After-Sales Support
- Comprehensive 1-year warranty for peace of mind.
- Access to online technical support, ensuring quick resolution of any operational queries.
Logistics and Packaging
- Each unit is securely packaged with dimensions of 800x700x900 cm and a gross weight of 600 kg.
- Available for order with a minimum quantity of 1 piece (MOQ).
Why Choose GoldHealth Medical?
The GoldHealth Medical 64-Slice CT Scanner combines innovative engineering, precision, and reliability to meet the evolving needs of healthcare professionals. Whether for clinical diagnostics, research, or patient care, this system is designed to elevate your facility’s imaging capabilities.
Experience the future of medical imaging with GoldHealth Medical.
