Mobile Digital Veterinary Xray Machine 5kw8kw High Frequency Dr
Reference: 1600967878375Medical X-ray Equipments & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Revolutionizing Diagnostic Radiology
Introducing the High Frequency Digital X-Ray System
GoldHealth Medical presents a cutting-edge High Frequency Digital X-Ray System, designed for unparalleled versatility and precision in medical diagnostics. This portable system is engineered to deliver exceptional performance in diverse environments, from remote locations and battlefields to pet clinics and emergency rescue operations.
Key Applications
- Human Limbs Diagnostics: Ideal for checking and diagnosing fractures and injuries.
- Versatile Use Cases: Perfect for fieldwork, sports events, veterinary clinics, and emergency medical services.
Unmatched Features
- Sleek and Compact Design: Combines portability with robust functionality.
- Advanced Digital Display: Equipped with a 6-stage digital LED interface for clear and intuitive operation.
- Comprehensive Preset Options: Offers 48 anatomical memory patterns for precise imaging.
- Precision Control: Dual digital loops ensure accurate regulation of tube voltage and current.
- Self-Diagnostic Capabilities: Integrated failure self-protection and diagnostic systems for reliable performance.
Technical Specifications
- Input Power:
- Voltage: AC220V ± 22V
- Frequency: 50/60Hz ± 1Hz
- Power Capacity: ≥5kVA
- Inner Resistance: ≤0.5Ω
- Output Power:
- Maximum Output: 110kV × 36mA = 4kW
- Nominal Power: 100kV, 40mA, 0.1s, 4kW
- Adjustable Parameters:
- kV Range: 40kV–110kV (Continuous adjustment in 1kV increments)
- mA Range: 36mA–60mA
- mAs Range: 1mAs–190mAs
- Time Range: 0.04s–3.2s
- X-Ray Tube:
- Brand: Toshiba
- Focus: 0.6/1.5mm
- Anode Heat Capacity: 35.5KJ
- Dimensions and Weight:
- Size: 290 × 260 × 230mm
- Weight: 18.8kg
- Standard Accessories:
- Hand Switch
- Remote Control
- Suitcase
- Optional Machine Frame
Why Choose GoldHealth Medical?
GoldHealth Medical stands at the forefront of innovation in diagnostic radiology. Our High Frequency Digital X-Ray System is meticulously crafted to meet the rigorous demands of modern healthcare. With advanced features, precise control mechanisms, and robust build quality, this system ensures accurate diagnostics and reliable performance in any setting.
Recommended Products
- Portable Mobile X-Ray Machine: Lightweight and versatile, perfect for on-the-go diagnostics.
- Stationary Digital X-Ray Machine: Designed for high-precision imaging in clinical environments.
- Mobile Digital C-Arm X-Ray Machine: Ideal for surgical and orthopedic applications in hospitals.
GoldHealth Medical is committed to delivering excellence in medical imaging solutions. Our products are trusted by hospitals, clinics, research institutions, and healthcare professionals worldwide. Experience the future of diagnostic radiology with GoldHealth Medical.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: Portable X-ray Machine by GoldHealth Medical
Properties: Advanced Medical X-ray Equipment
Key Features
- Precision and Mobility: Designed for seamless use in radiography departments, this portable X-ray machine combines precision engineering with effortless mobility, making it ideal for diverse medical environments.
- Rotational Flexibility: Equipped with advanced rotation capabilities, it ensures optimal positioning for accurate imaging, even in challenging clinical scenarios.
- Durable Construction: Crafted with high-grade metal and premium plastic components, this machine is built to withstand the rigors of daily medical use while maintaining exceptional performance.
Technical Specifications
- Instrument Classification: Class II Medical Device
- Power Source: Electricity
- Color: Sleek White Design
- Shelf Life: 1 Year
- Safety Standard Compliance: GB15979-2002
- Quality Certifications: CE, ISO
Applications
- Primary Use: Medical Radiography
- Ideal For: Hospitals, Clinics, Research Labs, Rehabilitation Centers, and Home Healthcare
Support and Assurance
- Warranty: Comprehensive 1-Year Warranty
- After-Sales Service: Access to dedicated online technical support for uninterrupted performance and troubleshooting
Unique Selling Points
- Compact and Portable Design: Engineered for easy transport and setup, enabling efficient imaging in remote or space-constrained environments.
- Advanced Imaging Technology: Delivers high-resolution digital X-ray outputs, ensuring clarity and diagnostic accuracy.
- Trusted Quality: Backed by rigorous international certifications, including CE and ISO standards, guaranteeing safety and reliability.
Place of Origin
- Jiangsu, China
GoldHealth Medical’s Portable X-ray Machine is more than just equipment—it’s a reliable partner in delivering exceptional patient care. Whether in a bustling hospital or a quiet home setting, its innovative design and robust functionality make it an indispensable tool for modern medical professionals.
