Medical LCD XRay Film Viewer Lightbox
Reference: 1333237786Radiology Equipment & Accessories
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical LED Medical Film Viewer
GoldHealth Medical proudly presents the LED Medical Film Viewer, a cutting-edge solution designed for precise and efficient radiographic film observation. Engineered to meet the rigorous standards of YY/T0610-2007, this viewer is an indispensable tool for medical imaging professionals.
Key Features:
- Advanced LED Light Source: Equipped with a durable LED light source offering a lifespan of 100,000 hours. Unlike CCFL, it eliminates temperature-related issues and provides instant illumination upon activation.
- Uniform Illumination: Features an evenly spaced LED layout ensuring over 90% luminance uniformity for consistent brightness across the viewing area.
- Brightness Control: Offers 10 digital levels of adjustable brightness, with a maximum output of 5000cd/m², catering to various medical film densities.
- Automatic Operation: Each bank operates independently, automatically turning on when a film is inserted and off when removed, enhancing workflow efficiency.
- Vision Comfort: With a light frequency exceeding 50KHz, it significantly reduces eye fatigue during prolonged use.
- Superior Viewing Screen: Utilizes Mitsubishi viewing screens for brighter, softer light that resists yellowing and deformation over time.
- Enhanced Film Clamping: Incorporates an advanced clamping system suitable for films of varying thicknesses, overcoming the limitations of traditional rolling mechanisms.
Specifications:
- Single-Bank Viewer
- Dimensions (Frame): 500 x 510 x 45 mm
- Viewing Area: 14 x 17 inches
- Power Consumption: 25W
- Light Source: 1 LED Lamp
Brightness: >10,000 LUX
Dual-Bank Viewer
- Dimensions (Frame): 850 x 510 x 45 mm
- Viewing Area: 28 x 17 inches
- Power Consumption: 50W
- Light Source: 2 LED Lamps
Brightness: >10,000 LUX
Triple-Bank Viewer
- Dimensions (Frame): 1200 x 510 x 45 mm
- Viewing Area: 42 x 17 inches
- Power Consumption: 75W
- Light Source: 3 LED Lamps
Brightness: >10,000 LUX
Quad-Bank Viewer
- Dimensions (Frame): 1570 x 510 x 45 mm
- Viewing Area: 56 x 17 inches
- Power Consumption: 100W
- Light Source: 4 LED Lamps
- Brightness: >10,000 LUX
GoldHealth Medical’s LED Medical Film Viewer combines innovative technology with user-centric design, delivering unparalleled performance and reliability for medical imaging applications.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical - Revolutionizing Medical Imaging Solutions
Product Overview:
GoldHealth Medical presents a cutting-edge medical imaging solution designed to deliver precision, reliability, and exceptional performance. Engineered for versatility, this product is ideal for hospitals, clinics, research labs, and home healthcare environments. Its sleek design and advanced functionality make it a standout choice for medical professionals seeking efficiency and accuracy.Key Features:
- Light Source: High-performance LED technology with an impressive lifespan of 100,000 hours, ensuring consistent brightness and minimal maintenance.
- Brightness: Exceeds industry standards with a high luminance of over 4500 cd/m², providing unparalleled clarity for detailed diagnostics.
- Color Temperature: Optimized at 9600K for true-to-life imaging, enhancing diagnostic accuracy.
Versatile Installation: Can be mounted on walls or placed on desks, offering flexibility to suit various clinical settings.
Technical Specifications:
- Power Source: AC100-220V/50Hz, compatible with global electrical standards.
- Material: Durable construction using premium acrylic, plastic, and steel for long-lasting performance.
Film Compatibility: Supports single, double, triple, and quadruple film configurations, catering to diverse imaging needs.
Safety and Compliance:
- Instrument Classification: Class I medical device, ensuring the highest level of safety and reliability.
Certifications: Compliant with EN 149-2001+A1-2009 and CE standards, guaranteeing adherence to international safety protocols.
Warranty and Support:
- Warranty: Comprehensive 3-year warranty for peace of mind.
After-Sale Service: Access to online technical support, ensuring seamless operation and quick resolution of queries.
Packaging and Logistics:
- Packaging Details:
- Inner layer: Polybag and foam for secure protection.
- Outer layer: Carton and case for robust transportation.
Origin: Proudly manufactured in Hunan, China, ensuring quality craftsmanship.
Supply Capability:
- Monthly production capacity of 100,000 units, ensuring timely delivery and scalability to meet global demands.
GoldHealth Medical is committed to delivering innovative solutions that empower healthcare providers with precision tools, enabling better patient outcomes and operational efficiency.
