ICU Pro 121 Multiparameter Monitor
Reference: 1600986774493Examination Therapy Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical: Revolutionizing Patient Monitoring with Advanced Technology
Introducing the GoldHealth Medical Multifunctional Patient Monitor
Experience precision and versatility with our state-of-the-art multifunctional patient monitor, designed to meet the demands of modern healthcare environments. Featuring a sleek 12.1-inch TFT display, this portable device is engineered for intuitive operation and exceptional performance. Its sophisticated design and advanced functionality make it ideal for post-anesthesia care, ambulatory surgery, emergency rooms, and more.
Key Features and Benefits
- Crystal-Clear Display: Simultaneously view up to 6 waveforms on a vibrant 12.1-inch TFT screen with a wide viewing angle. Each parameter is color-coded for effortless readability, even from a distance.
- Portability Redefined: Lightweight at just 6.5 kg and equipped with a built-in rechargeable battery, this compact monitor ensures uninterrupted patient monitoring during transport or in areas with limited power supply.
- User-Friendly Interface: Operate seamlessly with an intuitive mouse-controlled interface, designed for ease and precision.
- Comprehensive Monitoring: Track vital parameters including ECG, respiration, SpO2, NIBP, pulse rate, and temperature.
- Advanced Data Management: Store up to 150 hours of trend data for all monitored parameters, with ECG playback functionality.
- Customizable Options: Choose from seven display interfaces and optional built-in recorder for enhanced flexibility.
Technical Specifications
- ECG:
- Connection Mode: Five-lead electrocardiograph input (R, L, F, N, C)
- Display Waveforms: Up to 7
- Gain Options: 0.25mm/mV to 4mm/mV, Auto
- Input Impedance: ≥5MΩ
- Frequency Response: 0.5–40Hz (±3dB)
- Defibrillation Protection: Isolated up to 4000 VAC
- Alarm for Electrode Disconnection: Yes
- Heart Rate:
- Measuring Range: 0–300 bpm
Accuracy: ±1 bpm
Non-Invasive Blood Pressure (NIBP):
- Measuring Method: Self-oscillation
- Measuring Range: Adult (0–300 mmHg), Child (0–200 mmHg)
Pressure Unit: mmHg/Kpa
Temperature:
- Measurement Range: 0–50°C
Resolution: 0.1°C
SpO2:
- Measurement Range: 0–100%
- Accuracy: ±2% (70–100%)
Pulse Rate Range: 0–300 bpm
Respiration:
- Measurement Range: 0–120 breaths/minute
Accuracy: ±2 breaths/minute
Display and Power:
- Screen: 12.1-inch LCD with 800×600 resolution
- Trend Storage: 150 hours
- Power Supply: AC220V±22V, 50Hz±1Hz
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering cutting-edge medical solutions that empower healthcare professionals. Our patient monitor combines precision engineering, portability, and advanced features to ensure reliable performance in any setting. Whether in hospitals, clinics, or home care environments, our products are designed to enhance patient outcomes and streamline workflows.
Compact and Lightweight Design
With dimensions of 320mm x 160mm x 270mm (H x W x D), this monitor is perfect for spaces where every inch counts. Its lightweight design ensures effortless mobility without compromising on functionality.
Uninterrupted Monitoring
Equipped with a rechargeable battery, this monitor guarantees continuous operation even during power interruptions, making it indispensable in critical care scenarios.
GoldHealth Medical: Elevating Healthcare Standards
Our patient monitor is more than just a device—it’s a testament to our dedication to innovation and excellence. Choose GoldHealth Medical for a monitoring solution that meets the highest standards of quality and reliability.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical Patient Monitor
A cutting-edge patient monitoring solution designed for precision, reliability, and versatility across diverse healthcare environments.
Product Highlights
- Advanced Display: Equipped with a 12.1-inch real-color TFT screen for clear, detailed visualization of patient data.
- Comprehensive Monitoring: Standard parameters include ECG, SpO2, NIBP, RESP, TEMP, PR, and HR, ensuring holistic patient assessment.
- Optional Parameters: Expand functionality with IBP, CO2, and Nellco SpO2 modules tailored to specific clinical needs.
- Universal Application: Suitable for adult, pediatric, and neonatal care, making it an ideal choice for multi-purpose medical facilities.
- Trend Data Storage: Capable of storing up to 150 hours of trend data for enhanced patient monitoring and analysis.
Technical Specifications
- Power Source: Electric, with an optional lithium-ion battery for uninterrupted performance.
- Instrument Classification: Class II medical device, ensuring safety and reliability.
- Safety Standards: Compliant with EN 149-2001+A1-2009 for respiratory protective devices.
- Weight: Lightweight at 6.5 kg, ensuring portability and ease of use.
- Recorder: Optional integrated recorder for seamless documentation.
- Central Monitoring: Optional central monitoring capability for synchronized data management.
Quality Assurance
- Certifications: CE-certified, guaranteeing adherence to international quality and safety standards.
- Warranty: Backed by a 1-year warranty for peace of mind.
- After-Sale Support: Access to online technical support for prompt resolution of queries.
Packaging and Delivery
- Packaging Details: Securely packed in a robust box with dimensions of 38x35x30 cm.
- Gross Weight: 5.000 kg per unit.
- Supply Capacity: Up to 100 sets available per month to meet high-demand requirements.
GoldHealth Medical’s Patient Monitor is engineered to deliver unparalleled accuracy, adaptability, and durability, empowering healthcare providers to deliver exceptional patient care.
