ICEN 4KW Portable XRay Machine for Hospitals
Reference: 1600207654366
High-Energy-Ray Medical Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Portable X-Ray Machine for Advanced Medical Diagnosis
Experience the future of medical imaging with GoldHealth Medical's portable high-frequency X-ray machine, designed for exceptional versatility and precision. This state-of-the-art device is tailored for human limb examinations and diagnostic applications, making it indispensable in dynamic environments such as remote locations, emergency zones, sports fields, veterinary clinics, and rescue operations.
Key Features
- Compact and Intuitive Design: Engineered for effortless mobility and ease of use in any setting.
- Advanced Digital Display: Equipped with a 6-stage digital LED interface for clear and precise operation.
- Preprogrammed Anatomical Memory: Offers 48 preset anatomical patterns for seamless adaptability to diverse diagnostic needs.
- Dual Digital Control Loops: Ensures unparalleled accuracy in both simulation and operational control.
- Precision Voltage and Current Management: Delivers exact control over tube voltage and current for consistent imaging quality.
- Self-Diagnostic Protection: Built-in failure detection and self-protection mechanisms for enhanced reliability.
Technical Specifications
- Input Power
- Voltage: AC220V ± 22V
- Frequency: 50/60 Hz ± 1Hz
- Power Capacity: ≥5kVA
-
Inner Resistance: ≤0.5Ω
-
Performance Metrics
- Maximum Output Power: 110kV × 36mA = 4kW
- Nominal Power: 100kV, 40mA, 0.1s, 4kW
-
Frequency: ≥40kHz
-
Adjustable Parameters
- KV Range: 40kV–110kV (1 kV increments)
- mA Range: 36mA–60mA
- mAs Range: 1mAs–190mAs (shifted adjustment)
-
S Range: 0.04s–3.2s
-
X-Ray Tube
-
Toshiba Tube with Dual Focus: 0.5mm / 1.6mm
-
Dimensions and Weight
- Size: 290 × 260 × 230 mm
-
Weight: 18.8kg
-
Included Accessories
- Remote Control
- Aluminum Case
Why Choose GoldHealth Medical?
GoldHealth Medical is a trusted innovator in the medical equipment industry, renowned for delivering cutting-edge solutions with a commitment to excellence. Our portable X-ray machine stands out for its robust engineering, user-centric design, and adaptability to diverse clinical and field environments.
Applications
- Emergency medical services
- Sports injury diagnostics
- Veterinary care
- Remote and mobile healthcare
- Battlefield and disaster response
Commitment to Excellence
- Superior Quality: Rigorous quality control ensures unmatched performance and reliability.
- Exceptional Support: We prioritize long-term partnerships and treat every client as a valued collaborator.
- Customization Options: Tailor the product to your brand with custom logo printing.
- Competitive Pricing: High performance at an unbeatable value.
- Timely Delivery: Streamlined logistics to meet your deadlines.
- Comprehensive Warranty: One-year warranty for peace of mind.
GoldHealth Medical is dedicated to empowering healthcare providers worldwide with innovative tools that elevate patient care. Let us be your trusted partner in advancing medical diagnostics.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical: Revolutionizing Medical Imaging with Precision and Reliability
-
Product Overview:
GoldHealth Medical presents a cutting-edge Class I medical X-ray equipment designed for unparalleled performance in diagnostic imaging. Engineered with precision and reliability, this device is ideal for hospitals, clinics, research institutions, and rehabilitation centers. Its advanced technology ensures accurate imaging while maintaining safety and efficiency. -
Key Features and Technical Specifications:
-
Power and Performance:
- Nominal Power: 100kV, 40mA, 0.1s, 4kW
- Frequency: ≥40kHz
- Power Supply: AC 220V±22V, 50Hz
-
Adjustable Parameters for Optimal Imaging:
- KV Adjusting Range: 40kV~110kV (step adjustment of 1 kV)
- S Adjusting Range: 0.04s~3.2s
- mA Adjusting Range: 36mA~60mA
-
Certifications and Compliance:
- Quality Certifications: CE, ISO
- Instrument Classification: Class I
-
Durability and Design:
- Constructed with high-quality materials, including metal and plastic, ensuring long-lasting durability and stability.
- Shelf Life: 1 year
-
Warranty and Support:
- Comprehensive 1-Year Warranty
- Dedicated online technical support for seamless operation
- Hassle-free return and replacement policy
-
Packaging and Delivery:
- Secure packaging in cartons or wooden cases to ensure safe transportation of the X-ray machine.
- Port of Origin: Guangzhou
- Supply Ability: 200 sets per month
GoldHealth Medical is committed to delivering innovative solutions that empower healthcare professionals with reliable, high-performance diagnostic tools. Elevate your imaging capabilities with our state-of-the-art X-ray equipment.
