FarmaSino FSDM7000 AED Def
Reference: 60246594444Emergency & Clinics Apparatuses
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Defibrillator Machine
Product Description
GoldHealth Medical presents a cutting-edge defibrillator machine designed for precision and reliability in critical care environments. This device combines advanced monitoring capabilities with user-friendly features, ensuring optimal performance for healthcare professionals.
Key Features and Specifications
Monitor/Display
- Input Options: Compatible with 3-lead, 5-lead patient cables, paddles, or multi-purpose hands-free adapters.
- Display Size: 6.5 inches (16.5 cm) diagonal, non-fade.
- Display Type: High-quality color TFT.
- Resolution: 800 x 600 pixels.
- Sweep Speed: Adjustable at 12.5mm/s, 25mm/s, 50mm/s.
- Lead Selections: Paddles (Pads), I, II, III, AVR, AVL, AVF, V.
- Frequency Response: User-selectable modes:
- Limited mode: 2 to 20 Hz
- Monitor mode: 1 to 40 Hz (pre-Rev. T8/U8)
- Diagnostic mode: 0.05 to 150 Hz
- AED mode: 0.5 to 30 Hz
- Common Mode Rejection: Compliant with AAMI EC13-1992, section 3.1.2.1c for 1.2 mV, T-wave (1.0 mV with diagnostic response) and 1mV QRS.
- Diagnostic Signals: Leads off / active noise suppression sensing circuit < 0.1mA DC.
Heart Rate Meter
- Range: 20 to 300 BPM.
- Alarms: Fully user-selectable.
- Size Settings: 0.125, 0.25, 0.5, 1, 2, 4 cm/mv and auto-ranging.
- Aspect Ratio: 0.5, 0.1, 0.4, 0.8, 1.6 respectively.
- ECG Output: 1 V/mV.
- Response Time: Meets AAMI EC13-1992, section 4.1.2.1.e.
- Irregular Rhythm Response:
- Ventricular Bigeminy: 80 BPM (expected)
- Slow Alternating Ventricular Bigeminy: 60 BPM (expected)
- Rapid Alternating Ventricular Bigeminy: 120 BPM (expected)
- Bidirectional Systole: 45 BPM (expected)
Alarms
- Types: Heart Rate, BP, SpO2, Resp & Temp Alarm, Lead Fault Alarm, Physiological Alarms (SpO2).
- Audible Alerts: See Heart Rate Alarm.
- Mute Duration: 90 seconds.
Recorder
- Type: High-resolution thermal array.
- Annotation: Time, date, ECG lead, ECG gain, heart rate, defibrillation, and treatment summary ACLS events.
- Paper Width: 50 mm.
- Paper Speed: 25 mm/sec, 50 mm/sec, 50 mm/sec.
- Delay: 6 seconds.
- Frequency Response: Automatically set to monitor's frequency response.
- Treatment Summary: 7 switches to record key ACLS events (IV, INTUB, EPI, LIDO, ATROP, etc.).
- Automatic Logging: Type of event, time, and ECG sample.
- Tx Summary Log: 28 ECG events or 300 non-ECG events.
- Record Modes: Manual and automatic (User-configurable).
Battery
- Standard Type: NiCad 12 volt - SmartPak Plus.
- Capacity: Up to 2 hours ECG monitoring or 60 full-energy discharges or 1.5 hours combined ECG, SpO2, and BP monitoring while pacing.
- Self-Test: Bi-color LED indicates battery charge state (Green = usable, Red = requires charging).
- Low Battery Indicator: Flashing low battery icon on display and flashing LED on battery.
- Recharge Rate: 80% in 3.5 hours, 100% in 4.5 hours.
- High Capacity Type: NiMH 12 volt - SuperPac.
- Recharge Rate: 80% in 7.5 hours, 100% in 9.5 hours.
- Multiple Paired Contacts: Ensures quick, error-free insertion and backup reliability
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical AED Defibrillator
Revolutionizing emergency care with precision, reliability, and advanced technology. Designed for hospitals, clinics, research institutions, and home users, this state-of-the-art device ensures life-saving performance in critical moments.
Product Highlights
- Application: Emergency life-saving interventions with rapid response capabilities.
- Heart Rate Meter: Accurate monitoring from 20 to 300 BPM.
- ECG Output: High-resolution output at 1 V/mV for precise diagnostics.
- Sweep Speed: Adjustable settings of 12.5mm/s, 25mm/s, and 50mm/s for optimal visualization.
- Mute Duration: 90 seconds of silent operation during critical procedures.
- Battery Life: Delivers up to 60 defibrillator discharges on a single charge, ensuring uninterrupted performance.
- Display/Monitor: Compatible with 3-lead and 5-lead patient cables for comprehensive monitoring.
- Alarms: Advanced alerts for heart rate, blood pressure (BP), oxygen saturation (SpO2), respiration (Resp), and temperature (Temp).
Technical Specifications
- Instrument Classification: Class I medical device for professional and home use.
- Power Source: Electrically powered for consistent performance.
- Shelf Life: 3 years, ensuring long-term usability.
- Materials: Durable construction using high-quality plastic and steel.
- Quality Certifications: Compliant with CE and ISO standards for safety and reliability.
Packaging and Delivery
- Packaging Details: Secure carton packing for safe transportation.
- Package Dimensions: 50 x 80 x 50 cm.
- Gross Weight: 30.000 kg.
- Port Options: Shanghai or Guangzhou for global shipping.
Supply and Support
- Supply Ability: Up to 1,000 sets per month to meet high demand.
- Warranty: Comprehensive 3-year warranty for peace of mind.
- After-Sale Service: Dedicated online technical support to ensure seamless operation.
GoldHealth Medical’s AED Defibrillator combines cutting-edge technology with user-centric design, empowering healthcare professionals and caregivers to act decisively in emergencies. Choose reliability, choose GoldHealth Medical.
