EG12 6Channel ECG Machine
Reference: 1601236190447Pathological Analysis Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
Advanced 6-Channel ECG Machine by GoldHealth Medical
GoldHealth Medical introduces a cutting-edge 6-channel ECG machine, designed to redefine precision and efficiency in cardiac diagnostics. Engineered with advanced technologies, this device ensures unparalleled accuracy and ease of use, making it indispensable for modern healthcare environments.
Key Features and Benefits
- Sleek Design, Lightweight, and Compact: Combining modern aesthetics with portability, this ECG machine is perfect for both stationary and mobile use.
- 12-Lead Acquisition with 6-Channel Display: Simultaneous acquisition of all 12 leads with a full-screen display of six ECG waveforms for comprehensive analysis.
- 7-Inch High-Resolution Touch Screen: Intuitive touch interface with physical buttons for seamless operation.
- Advanced Signal Processing: Equipped with sensitive ADS, HUM, and EMG filters to ensure crystal-clear waveforms.
- Automated Analysis and Diagnostics: Reduces physician workload with automatic measurement, waveform freezing, and diagnostic insights, enhancing clinical efficiency.
- Optimal Baseline Adjustment: Ensures precise recordings by automatically adjusting the baseline for clarity.
- Integrated Thermal Printer: High-speed synchronization printing with 80mm thermal paper for instant results.
- Smart Detection Systems: Alerts for lead disconnection and paper shortages to prevent interruptions during use.
- Long-Lasting Battery Life: Built-in rechargeable lithium-ion battery (11.1V/4000mAh) with AC/DC power compatibility for uninterrupted performance.
- Universal Power Supply: Adapts to 100-240V, 50/60Hz AC power, ensuring global usability.
- Data Management Capabilities: Stores over 400 ECG reports in its internal memory, with options to review, print, and transfer data via USB flash disk or SD card.
- Energy-Saving Sleep Mode: Extends LCD lifespan while conserving energy during idle periods.
- Continuous Real-Time Recording: Captures exact 12-channel ECG waveforms with annotations, including lead signs, sensitivity, paper speed, and filter status.
Why Choose This ECG Machine?
The importance of regular ECG monitoring cannot be overstated. According to data from STROKESTOP published in Swedish Circulation 2015, daily self-monitoring significantly increases risk detection rates by four times and identifies 70% of new-onset cardiac conditions, effectively reducing the risk of sudden heart attacks.
Technical Specifications
- Display: 7-inch color touch screen with intuitive controls.
- Waveform Channels: 6-channel display with 12-lead acquisition.
- Filters: Advanced ADS, HUM, and EMG filters for noise-free signals.
- Printing: Integrated thermal printer with 80mm paper.
- Power: Rechargeable lithium-ion battery (11.1V/4000mAh), AC/DC adaptable.
- Memory: Stores over 400 ECG reports internally.
- Connectivity: USB and SD card support for data transfer and analysis on PC.
- Certifications: ISO 13485 and CE compliant for safety and reliability.
Applications
This ECG machine is ideal for: - Hospitals and clinics - Medical centers and laboratories - Research institutions - Rehabilitation and long-term care facilities - Home healthcare settings
Unmatched Versatility and Precision
GoldHealth Medical’s 6-channel ECG machine is not just a diagnostic tool but a partner in delivering exceptional patient care. Its advanced features, combined with user-friendly design, make it an essential addition to any healthcare facility or home setting. Whether you’re diagnosing heart conditions or conducting routine check-ups, this device ensures accuracy, efficiency, and peace of mind.
Customization Options
For distributors, GoldHealth Medical offers branding opportunities, allowing customization with your logo to align with your business identity.
GoldHealth Medical is committed to delivering innovative solutions that empower healthcare professionals and enhance patient outcomes. Experience the future of cardiac diagnostics today.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical: Elevating Precision in Cardiac Monitoring
Product Overview:
Engineered for unparalleled accuracy and reliability, this advanced cardiac monitoring device is designed to meet the rigorous demands of modern healthcare environments. With its cutting-edge technology and user-centric design, it ensures exceptional performance for both clinical and home-based applications.Key Features and Specifications:
- Material: Durable metal construction for long-lasting use
- Instrument Classification: Class II medical device, ensuring safety and efficacy
- Safety Standard Compliance: Meets GB2626-2006 standards for optimal protection
- Place of Origin: Proudly crafted in Guangdong, China
- Power Source: Electric, offering consistent and reliable operation
- Shelf Life: 1 year from the date of manufacture
Quality Certification: CE-certified, guaranteeing adherence to international quality benchmarks
Technical Excellence:
- Input Mode: Floating and defibrillation protection for enhanced safety
- Sampling Rate: 1000Hz for precise and detailed signal capture
- Input Impedance: ≥50MΩ (at 10Hz), ensuring minimal signal distortion
- Frequency Response: 0.05-160Hz (-3dB) for accurate waveform representation
- CMRR (Common Mode Rejection Ratio): ≥100dB with AC filter, minimizing interference
- Lead Configuration: Standard 12 leads for comprehensive cardiac analysis
- Input Circuit Current: ≤0.05μA, ensuring patient safety during operation
- A/D Converter: 24-bit resolution for superior signal clarity
- Acquisition Mode: Simultaneous 12-lead acquisition for real-time monitoring
Operation Modes: Manual, Auto, and Rhythm modes, including 1-channel recording for up to 1 minute
Packaging Details:
- Selling Unit: Single item
- Package Dimensions: 50 x 35 x 35 cm
Gross Weight: 3.000 kg
Warranty and Support:
- Warranty Period: 1 year, reflecting our confidence in product durability
- After-Sale Service: Dedicated online technical support to address your needs promptly
GoldHealth Medical’s cardiac monitoring solution combines precision engineering with user-friendly functionality, making it an indispensable tool for healthcare professionals and caregivers alike.
