ECG600G Advanced 6Channel Medical E

GoldHealth Medical presents an advanced Electrocardiograph designed to redefine precision and efficiency in cardiac diagnostics.

This state-of-the-art device captures 12-lead ECG signals and delivers exceptional waveform printing through a high-resolution thermal printing system. Engineered for both AUTO and Manual modes, it offers seamless recording, automatic parameter analysis, and intuitive alerts for "Lead off" and "Lack of paper." With a user-friendly multi-language interface and robust case database management, it is tailored for diverse medical environments.

Key Features

• High-Resolution Thermal Printing: Achieves 8 dots/mm resolution without requiring adjustments. Recording frequency extends up to 150Hz for unparalleled clarity.
• Real-Time Waveform Recording: Delivers precise ECG waveforms and annotations, including lead marks, sensitivity, paper speed, and filter status.
• Advanced Digital Filtering: Eliminates baseline drift, AC interference, and EMG noise, ensuring clean and accurate readings.
• Automatic Baseline Adjustment: Optimizes print settings and rhythm lead configurations for enhanced usability.
• Efficient AUTO Mode: Simplifies workflow with one-touch recording, significantly boosting operational efficiency.
• Digital Signal Processing: Employs power frequency, baseline, and EMG filters to produce high-quality ECG waveforms.
• Automated Analysis: Provides auto-measurement, auto-analysis, and auto-diagnosis of routine ECG parameters, reducing clinician workload.
• Flexible Printing Formats: Supports multiple formats, including 2×6+1, 3×4, 4×3+1, 6×2+1, and various rhythm leads, catering to diverse diagnostic needs.
• Comprehensive Display: Simultaneously shows 3/6/12-lead ECG waveforms, "Lead off," and "Lack of paper" alerts on a single screen. Includes an ECG DEMO mode for training purposes.
• Customizable Time Print: Configurable intervals of 1/2/3/5/10/20/30/60 minutes for automated time-stamped recordings.
• Versatile Print Settings: Options include "Print and save," "Print no save," and "Save no print" for tailored workflows.
• Reliable Power System: Operates on AC/DC with a built-in rechargeable lithium battery, featuring auto-protection and power-off functionality during idle periods.
• Extensive Case Storage: Stores over 1000 cases for easy review and statistical analysis.
• Multi-Language Support: Offers interfaces and reports in multiple languages, including English, French, Spanish, German, and more.

Technical Specifications

• Input Mode: Floating with defibrillation protection.
• Frequency Response: 0.05Hz ~ 150Hz (-3dB ~ +0.4dB).
• CMRR: >60dB, >100dB with filter.
• Time Constant: ≥ 3.2s.
• Patient Leak Current: <10µA.
• Calibration Voltage: 1mV.
• Sensitivity: 2.5, 5, 10, 20, 40 mm/mV ±5%; standard sensitivity: 10mm/mV ±2%.
• Noise Level: <15µVp-p.
• Input Circuit Current: ≤50nA.
• Input Impedance: ≥50MΩ.
• Sampling Accuracy: 12-bit.
• Safety Classification: Class I, Type CF, defibrillation-proof applied part.
• Recording Modes: Thermal printing system with AUTO, Rhythm, and Manual options.
• Measurement Parameters: HR, P-R interval, P Duration, QRS Duration, T Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1).
• Paper Size: 80mm(W) × 20m(L).
• Power Frequency Filter: AC 50Hz/60Hz (-20dB).
• Sampling Frequency: 1000Hz.
• EMG Interference Filter: 25Hz/35Hz (-3dB).
• Paper Speed: AUTO, Rhythm, and Manual modes support speeds of 5, 6.25, 10, 12.5, 25, 50, 100mm/s (±5%).
