ECG 600G Portable 12Channel E
Reference: 1600703132122Clinical Analytical Instruments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical ECG Device
Product Overview
GoldHealth Medical presents an advanced ECG device designed to deliver unparalleled precision and efficiency in cardiac diagnostics. Engineered with cutting-edge technology, this device ensures superior performance for medical professionals and institutions.
Key Features
- High-Resolution Thermal Printing: Utilizes an 8 dot/mm thermal printing system for sharp, maintenance-free output. Recording frequency reaches up to 150Hz.
- Real-Time ECG Monitoring: Captures clear and accurate ECG waveforms with annotations, including lead marks, sensitivity, paper speed, and filter status.
- Advanced Digital Filtering: Equipped with a full-digital filter design to resist baseline drift, AC, and EMG interference.
- Automatic Baseline Adjustment: Optimizes print settings and rhythm leads automatically for consistent results.
- Efficient AUTO Mode: Simplifies operation with one-touch recording, enhancing workflow efficiency.
- Digital Signal Processing: Delivers high-quality ECG waveforms through power frequency, baseline, and EMG filters.
- Automated Analysis: Features auto-measurement, auto-analysis, and auto-diagnosis for routine ECG parameters, reducing physician workload.
- 12-Lead Sync Collection: Supports multiple printing formats, including 2Γ6+1, 3Γ4, 4Γ3+1, and more, for comprehensive ECG documentation.
- Multi-View Display: Displays 3/6/12-lead ECG, "Lead off," and "Lack of paper" notifications on a single screen, with an ECG DEMO mode for training.
- Customizable Time Print: Configurable intervals of 1/2/3/5/10/20/30/60 minutes for timed printing.
- Flexible Print Settings: Options include "Print and save," "Print no save," and "Save no print" for tailored workflows.
- Dual Power Supply: Operates on AC/DC with a built-in rechargeable lithium battery and auto-protection circuitry.
- Extensive Storage: Stores over 1000 cases for easy review and statistical analysis.
- Multi-Language Support: Offers interfaces and reports in multiple languages, including English, French, Spanish, and more.
Technical Specifications
- Input Mode: Floating with defibrillation protection
- Frequency Response: 0.05Hz ~ 150Hz (-3dB~+0.4dB)
- CMRR: >60dB, >100dB with filter
- Time Constant: β₯ 3.2s
- Patient Leak Current: <10Β΅A
- Calibration Voltage: 1mV
- Sensitivity: 5, 10, 20 mm/mV Β±5%, standard: 10mm/mVΒ±2%
- Noise Level: β€15Β΅Vp-p
- Input Circuit Current: β€50nA
- Input Impedance: β₯50MΞ©
- Sampling Accuracy: 12-bit
- Safety Classification: Class I, type CF, defibrillation-proof
- Recording Modes: Auto, rhythm, and manual record with customizable formats
- Paper Size: 80mm(W)Γ20m(L)
- Sampling Frequency: 1000Hz
- EMG Interference Filter: 35Hz (-3dB)
- Power Frequency Filter: AC 50Hz/60Hz (-20dB)
- Paper Speed: Auto, rhythm, and manual modes with speeds of 5, 6.25, 10, 12.5, 25, 50, 100mm/s Β±5%
- Power Supply: AC: 100V~240V (50/60Hz), DC: 7.4V/2000mAh rechargeable lithium battery
- Fuse Specification: Two AC time lag fuses (Ο5Γ20mm), T1.6AL250V
- Waterproof Degree: IPX0
- Working Mode: Continuous operation
Unique Selling Points
- Precision and Reliability: High-resolution thermal printing and advanced digital filtering ensure accurate and interference-free ECG waveforms.
- User-Friendly Design: Intuitive AUTO mode and customizable settings streamline operations, saving time and effort.
- Comprehensive Data Management: Extensive storage and multi-language support cater to diverse professional needs.
- Versatile Applications: Suitable for hospitals, clinics, research labs, and home healthcare environments.
GoldHealth Medicalβs ECG device is a testament to innovation and excellence, empowering healthcare providers with the tools they need to deliver exceptional patient
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Company: GoldHealth Medical
Product Introduction:
Experience the next generation of precision and reliability with our advanced medical instrument. Designed to meet the rigorous demands of modern healthcare, this Class II medical device is engineered for accuracy, durability, and ease of use. Whether in a hospital, clinic, or home setting, it delivers unparalleled performance to support better patient outcomes.
Key Features and Specifications:
- Warranty: Comprehensive 1-year warranty for peace of mind
- After-Sales Support: Dedicated online technical support to ensure uninterrupted operation
- Classification: Class II medical instrument, ensuring safety and precision
- Place of Origin: Proudly crafted in China with globally sourced components
- Packaging Details:
- Selling Units: Single item
- Single Package Size: 15 x 30 x 25 cm (compact and secure packaging)
- Single Gross Weight: 6.000 kg (lightweight yet robust design)
Why Choose GoldHealth Medical?
Our commitment to innovation and quality ensures that every product is built to exceed industry standards. With meticulous attention to detail and a focus on user-centric design, this instrument is an ideal choice for healthcare professionals and institutions seeking reliable, cutting-edge solutions.
Unique Selling Points:
- Precision-engineered for consistent, accurate results
- Ergonomic and intuitive design for seamless integration into workflows
- Backed by a trusted brand with a reputation for excellence in medical technology
GoldHealth Medical: Empowering healthcare, one innovation at a time.
