CONTEC8000S USB PC ECG Stress Test System
Reference: 60822455614Medical Laser Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Stress ECG Analysis System
The GoldHealth Medical Stress ECG Analysis System is a cutting-edge solution designed for precision and reliability in cardiac diagnostics. This system integrates advanced sampling hardware, specialized software, and exercise equipment to deliver unparalleled insights into heart function during physical activity.
Key Features
- Real-Time ECG Waveform Printing: Capture and save ECG data throughout the entire exercise process, ensuring no critical detail is missed.
- ST Segment Monitoring: Observe real-time changes in the ST segment with an enlarged display of user-selected leads and automatic ST data calculations.
- Advanced Anti-Interference Technology: Ensures stable baselines by minimizing the impact of EMG interference, baseline drift, and AC interference.
- Customizable Exercise Protocols: Supports both standard and user-defined exercise schemes with automated alerts for printing and blood pressure measurements.
- Event Marking and Comparison: Mark events during exercise for later review, comparison, and printing, enhancing diagnostic accuracy.
- Comprehensive Trend Analysis: Display and print trend charts for HR, BP, METS, HR*BP, ST segment, and more, providing a holistic view of patient performance.
- Dynamic/Static Review: Post-exercise review functionality allows for a detailed representation of the entire testing process.
- Efficient Case Management: Import/export cases with compression for reduced storage space, simplifying data management.
- Extensive System Settings: Customize language, waveform display formats, background color, print settings, and more to suit your preferences.
- Device Management Tools: Utilize multiple functional tools for device management, case statistics, and other operations.
- Wireless Data Sampling: Enhances anti-interference capabilities for more reliable data collection.
- Compatibility with Various Exercise Equipment: Ensures versatility and adaptability in different clinical settings.
Performance Specifications
- Patient Leak Current: <10Β΅A
- Input Impedance: β₯50MΞ©
- Frequency Response: 0.05Hz~150Hz (-3dB~+0.4dB)
- Time Constant: β₯3.2s
- Common Mode Rejection Ratio (CMRR): >60dB, >100dB (filter on)
- Calibration Voltage: 1mV
- Sampling Frequency: Max. 1000 Hz
- Sampling Accuracy: Max. 24 bits
- Input Loop Current: β€50nA
- Polarization Resistance Voltage: Β±500mV
- Noise Level: β€15Β΅Vp-p
- Safety Type: Internally powered equipment, type BF
Physical Characteristics
- Dimensions: 94mm(L) * 66mm(W) * 31mm(H)
- Weight: Approximately 94.6g (without battery)
GoldHealth Medical's Stress ECG Analysis System stands out with its precision engineering and user-centric design, making it an indispensable tool for healthcare professionals. Whether in hospitals, clinics, or research labs, this system provides reliable data to support accurate diagnoses and effective treatment plans.
