BIOBASE Portable Class N 23L Vertical Dental Autoclave
Reference: 1601365176542Sterilization Equipment
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Sterilizer Series
The GoldHealth Medical sterilizer series is an advanced N-level sterilizer designed to deliver exceptional performance. Utilizing gravity displacement, it efficiently removes cold air from the sterilization chamber, saturates the internal steam, and achieves the desired pressure and temperature to ensure thorough sterilization of items. This makes it ideal for use in dental, ophthalmology, beauty, and operating room environments. It is particularly suited for sterilizing glassware, bare metal utensils, and unencapsulated solid instruments.
Key Features
- Premium Material: The sterilization chamber is crafted from high-quality S30408 stainless steel with electropolished finishing, ensuring durability and resistance to corrosion.
- Efficient Steam Generation: The unit generates steam internally through its main heating system, eliminating the need for an external steam source.
- Intuitive Interface: A 3.5-inch capacitive color display provides real-time information on pressure, temperature, time, and alarm codes, enabling effortless monitoring. A buzzer alerts users upon completion of the sterilization cycle.
- Comprehensive Record-Keeping: Equipped with a standard USB interface and optional printer, the system allows for seamless recording of program data.
- Optimized Storage Design: The innovative storage rack maximizes the utilization of the sterilization chamber, offering greater flexibility for varying sterilization loads.
- Smart Control System: Powered by a microcontroller, the system automates heating, sterilization, and exhaust processes, minimizing manual intervention.
- User-Friendly Operation: A one-touch start feature with mechanical keys ensures reliability, supporting over 100,000 actions.
- Advanced Safety Protections: Includes over-temperature automatic protection, anti-dry protection for heating elements, safety interlock mechanisms, dual over-voltage protection, over-current and leakage safety protection, and door detection safeguards.
Technical Specifications
- Capacity: 18L / 23L
- Door Type: Manual
- Designed Pressure: 0.28Mpa
- Working Pressure: 0.23Mpa
- Working Temperature: 121°C / 134°C
- Chamber Material: S30408 Stainless Steel
- Power Supply: AC220±10%, 50/60Hz (Standard); 110V, 60Hz (Optional)
- Power Consumption: 1.8KW
- Altitude Compatibility: ≤2500m
- Chamber Dimensions (φ*L): φ250350mm / φ250450mm
- Standard Accessories: Tray, USB Port
- Optional Accessories: Printer
- External Dimensions (WDH): 650495410mm / 700495410mm
- Package Dimensions (WDH): 810610590mm
- Net Weight: 32kg / 36kg
- Gross Weight: 47kg / 50kg
Why Choose GoldHealth Medical?
GoldHealth Medical is a leader in innovative medical and laboratory equipment, specializing in high-tech solutions that redefine precision and reliability. Our sterilizers are engineered to meet the rigorous demands of modern healthcare environments, ensuring safety, efficiency, and ease of use. With a commitment to quality and sustainability, we deliver products that exceed industry standards while prioritizing user experience.
Applications
- Dental clinics
- Ophthalmology centers
- Beauty salons
- Operating rooms
- Research laboratories
- Hospitals and rehabilitation centers
GoldHealth Medical’s sterilizer series combines cutting-edge technology with robust design, making it the ideal choice for professionals seeking uncompromising quality and performance.
