BIOBASE BK9622 Elisa Microplate Washer with
Reference: 1600745350158Blood Testing Equipments
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical - Elisa Microplate Washer
Revolutionize your laboratory processes with the Elisa Microplate Washer from GoldHealth Medical. Designed for precision and ease of use, this advanced microplate washer is engineered to deliver consistent, reliable results while minimizing manual intervention.
Key Features
- Intelligent Microcomputer Control: Automatically executes plate washing operations with precision, ensuring optimal performance without constant oversight.
- Advanced Liquid Level Sensing: Equipped with automatic detection of liquid levels, the system alerts users when cleaning fluid is low or when waste liquid is at risk of overflowing, ensuring uninterrupted operation.
- Customizable Operating System: Tailor every aspect of the washing process to your specific needs. Adjust parameters such as plate type, number of washes, wash solution volume, washing methods, suction points, soaking duration, and shaking time.
- Self-Balancing Wash Head: Features two-point aspiration and bottom flushing for thorough cleaning. The innovative design ensures even distribution and efficient washing.
- Dual Washing Modes: Choose between automatic washing with soaking and shaking functions to minimize interference adsorption during reactions. Both modes offer adjustable timing for maximum flexibility.
Technical Specifications
- Cleaning Head Options:
- 8 channels and 12 channels
- 96 pins with single-row control
- Microplate Compatibility:
- Four types: flat bottom, U bottom, V bottom, round bottom
- Average Residue per Well:
- Less than 1μl (per hole)
- Less than 0.7μl (per hole)
- Suction Time: Adjustable from 0.1 to 999.9 seconds in 0.1-second increments
- Line Flush Time: Adjustable from 0 to 240 seconds
- Washing Programs: Supports up to 200 customizable programs
- Display: 7-inch touch screen for intuitive control
- Liquid Injection Channels: 3 channels (2 for lotion, 1 for distilled water)
- Cleaning Needle Positions: 6 options (horizontal, left, middle, right, bottom, hole spacing)
- Power Consumption:
- 80W
- 350W
- Power Supply:
- AC220V ±10%, 50/60Hz
- 110V ±10%, 60Hz
- Packing Dimensions (WDH):
- 690490400mm
- 740675562mm
- Gross Weight:
- 22kg
- 42kg
Why Choose GoldHealth Medical?
GoldHealth Medical is committed to delivering cutting-edge solutions for laboratories, clinics, and research institutions worldwide. Our products are designed with precision engineering and user-centric features to meet the demands of modern healthcare and scientific research.
- Global Reach: With a presence in over 130 countries, we ensure reliable access to our innovative products.
- Dedicated Support: Our team of knowledgeable after-sales professionals provides 24/7 assistance to address any technical or operational concerns.
- Eco-Friendly Packaging: We prioritize sustainability with professional, environmentally conscious packaging solutions to safeguard your equipment during transit.
Experience unparalleled efficiency and accuracy with the Elisa Microplate Washer from GoldHealth Medical. Elevate your laboratory’s capabilities today.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Name: Elisa Microplate Washer by GoldHealth Medical
Key Features and Benefits:
- Advanced Cleaning Technology: Equipped with 8-channel and 12-channel cleaning heads, ensuring precision and efficiency in every wash cycle.
- Ultra-Low Residue: Achieves an average residue of less than 1μl per well, delivering unparalleled cleanliness for reliable results.
- Customizable Washing Programs: Store and execute up to 200 unique washing programs, tailored to meet diverse laboratory requirements.
- Intuitive Interface: A 7-inch touch display provides effortless navigation and real-time monitoring for enhanced user experience.
- Adjustable Line Flush Time: Flush times range from 0 to 240 seconds, offering flexibility for different experimental needs.
Technical Specifications:
- Instrument Classification: Class II medical device, designed for safety and reliability.
- Power Source: AC220V±10%, 50/60Hz or 110V±10%, 60Hz, ensuring compatibility across global standards.
- Energy Consumption: Efficient operation at just 80W.
- Packing Dimensions: 690 x 490 x 400mm (WDH).
- Gross Weight: 22kg.
- Shelf Life: 1 year from the date of manufacture.
Materials and Build Quality:
- Constructed with high-grade plastic, combining durability with lightweight portability.
Packaging and Delivery:
- Ships in standard international export packaging, ensuring safe transit.
- Available for dispatch from major ports, including Qingdao, Shanghai, and Shenzhen.
Supply Capability:
- Monthly production capacity of up to 1000 units, ensuring timely delivery for bulk orders.
After-Sale Support:
- Comprehensive 1-year warranty for peace of mind.
- Access to online technical support, providing expert assistance whenever needed.
Why Choose GoldHealth Medical?
GoldHealth Medical’s Elisa Microplate Washer is engineered to deliver precision, reliability, and ease of use, making it an indispensable tool for laboratories, research institutions, and healthcare facilities worldwide. With customizable features, advanced technology, and robust build quality, this washer sets a new benchmark in microplate cleaning solutions.
